Section 5: 4-36 UHF Band 1 (403–470 MHz) 1–25 W PCB 8471224L04, Schematics, and Parts Lists
6881091C63-F
UHF 1–25 W PCB 8471224L04 Parts Lists
†
Circuit
Ref
Motorola
Part No.
Description
C3101 2113944C80 CAP,FXD,20PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C3102 2113944C32 CAP CER CHP 15.0PF 50V 5%
C3103 2113944C36 CAP CER CHP 33.0PF 50V 5%
C3104 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3110 2113944C61 CAP,FXD,.5PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,P
C3111 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3112 2113944C36 CAP CER CHP 33.0PF 50V 5%
C3113 2113944C75 CAP,FXD,8.2PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3114 2113944C30 CAP CER CHP 10.0PF 50V +/-
0.5PF
C3115 2113944C32 CAP CER CHP 15.0PF 50V 5%
C3116 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3121 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3122 2113945C26 CAP,FXD,.039UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C3123 2113945C26 CAP,FXD,.039UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C3124 2113944M30 CAP,FXD,33PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C3132 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3133 2313960D07 CAP,FXD,10UF,+10%,-10%,16V-
DC,SM,-55DEG CMIN,125DEG
CMAX,174MA
C3134 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3135 2113944M30 CAP,FXD,33PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C3136 2113944C34 CAP CER CHP 22.0PF 50V 5%
C3137 2113945C26 CAP,FXD,.039UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C3139 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3140 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3141 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3142 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3143 2113944C46 CAP CER CHP 120.0PF 50V 5%
C3144 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3145 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3146 2113945L41 CAP,FXD,4700PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3147 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C3151 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3152 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C3153 NOTPLACED 64AM DUMMY PART NUMBER
C3154 NOTPLACED 64AM DUMMY PART NUMBER
C3155 NOTPLACED 64AM DUMMY PART NUMBER
C3156 NOTPLACED 64AM DUMMY PART NUMBER
C3157 NOTPLACED 64AM DUMMY PART NUMBER
C3158 NOTPLACED 64AM DUMMY PART NUMBER
C3159 NOTPLACED 64AM DUMMY PART NUMBER
C3160 NOTPLACED 64AM DUMMY PART NUMBER
C3161 NOTPLACED 64AM DUMMY PART NUMBER
C4001 2113944C69 CAP,FXD,1.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4002 2113944C43 CAP CER CHP 82.0PF 50V 5%
C4003 2113944C33 CAP CER CHP 18.0PF 50V 5%
C4004 2113944C36 CAP CER CHP 33.0PF 50V 5%
C4005 2113944C36 CAP CER CHP 33.0PF 50V 5%
C4006 2113944C36 CAP CER CHP 33.0PF 50V 5%
C4007 2113944C82 CAP,FXD,30PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4008 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4009 2113944C30 CAP CER CHP 10.0PF 50V +/-
0.5PF
Circuit
Ref
Motorola
Part No.
Description
C4010 2113945L13 CAP,FXD,330PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4011 2113945L37 CAP,FXD,3300PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4012 2113945L13 CAP,FXD,330PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4013 2113945L37 CAP,FXD,3300PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4014 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4015 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4017 2113944C69 CAP,FXD,1.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4018 2113944C80 CAP,FXD,20PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4019 2113944C71 CAP,FXD,5.6PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4020 2113944C36 CAP CER CHP 33.0PF 50V 5%
C4021 2113944C36 CAP CER CHP 33.0PF 50V 5%
C4022 2113944C36 CAP CER CHP 33.0PF 50V 5%
C4023 2113944C31 CAP CER CHP 12.0PF 50V 5%
C4024 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4026 2113944C69 CAP,FXD,1.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4027 2113944C69 CAP,FXD,1.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4028 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4029 2113944C69 CAP,FXD,1.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4030 2113944C69 CAP,FXD,1.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4031 2113944C78 CAP,FXD,13PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4051 2113944C30 CAP CER CHP 10.0PF 50V +/-
0.5PF
C4052 2113944C43 CAP CER CHP 82.0PF 50V 5%
C4053 2113944C79 CAP,FXD,16PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
Circuit
Ref
Motorola
Part No.
Description
C4054 2113944C79 CAP,FXD,16PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4061 2113944C04 CAP CER CHP 330.0PF 50V 5%
C4062 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4064 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4065 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4067 2113945L37 CAP,FXD,3300PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4068 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4069 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4201 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4202 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4203 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4204 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4205 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4206 2313960F01 CAP,FXD,10UF,+10%,-10%,16V-
DC,SM,-55DEG CMIN,125DEG
CMAX,247MA
C4208 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4209 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4210 2113946N03 CAP CER CHP 2.2UF 16V
C4211 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4213 2313960C78 CAP,FXD,2.2UF,+10%,-10%,20V-
DC,SM,-55DEG CMIN,125DEG
CMAX,156MA
C4214 2313960C78 CAP,FXD,2.2UF,+10%,-10%,20V-
DC,SM,-55DEG CMIN,125DEG
CMAX,156MA
C4215 2313960C78 CAP,FXD,2.2UF,+10%,-10%,20V-
DC,SM,-55DEG CMIN,125DEG
CMAX,156MA
C4217 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
Circuit
Ref
Motorola
Part No.
Description
