Motorola Pro3100 Detailed Service Manual

Section 5: 4-6 UHF Band 1 (403–470 MHz) 1–25 W LDMOS PCB 8471224L03, Schematics, and Parts Lists
6881091C63-F
UHF B1 25–40 W PCB 8471224L03 Parts List
†
Circuit
Ref
Motorola
Part No.
Description
C3101 2113944C80 20pF
C3102 2113944C32 15pF
C3103 2113944C36 33pF
C3104 2113945C31 .1uF
C3110 2113944C61 5pF
C3111 2113945C31 .1uF
C3112 2113944C36 33pF
C3113 2113944C75 8.2pF
C3114 2113944C30 10pF
C3115 2113944C32 15pF
C3116 2113945C31 .1uF
C3121 2113945C31 .1uF
C3122 2113945C26 .039uF
C3123 2113945C26 .039uF
C3124 2113944M30 33pF
C3132 2113945C31 .1uF
C3133 2313960D07 10uF
C3134 2113945C31 .1uF
C3135 2113944M30 33pF
C3136 2113944C34 22pF
C3137 2113945C26 .039uF
C3139 2113945C31 .1uF
C3140 2113945C31 .1uF
C3141 2113945C31 .1uF
C3142 2113945C31 .1uF
C3143 2113944C46 120pF
C3144 2113945C31 .1uF
C3145 2113945C31 .1uF
C3146 2113945L41 4700pF
C3147 2113945C31 .1uF
C3151 2113945L49 .01uF
C3152 2113945L49 .01uF
C4001 2113944C69 1.8pF
C4002 2113944C43 82pF
C4003 2113944C33 18pF
C4004 2113944C36 33pF
C4005 2113944C36 33pF
C4006 2113944C36 33pF
C4007 2113944C82 30pF
C4008 2113945L25 1000pF
C4009 2113944C30 10pF
C4010 2113945L13 330pF
C4011 2113945L37 3300pF
C4012 2113945L13 330pF
C4013 2113945L37 3300pF
C4014 2113944C45 100pF
C4015 2113944C45 100pF
C4017 2113944C69 1.8pF
C4018 2113944C80 20pF
C4019 2113944C71 5.6pF
C4020 2113944C36 33pF
C4021 2113944C36 33pF
C4022 2113944C36 33pF
C4023 2113944C31 12pF
C4024 2113945L25 1000pF
C4026 2113944C69 1.8pF
C4027 2113944C69 1.8pF
C4028 2113945L49 .01uF
C4029 2113944C69 1.8pF
C4030 2113944C69 1.8pF
C4031 2113944C78 13pF
C4051 2113944C30 10pF
C4052 2113944C43 82pF
C4053 2113944C79 16pF
C4054 2113944C79 16pF
C4061 2113944C04 330pF
C4062 2113945C31 .1uF
C4064 2113945C31 .1uF
C4065 2113944C45 100pF
C4067 2113945L37 3300pF
C4068 2113944C45 100pF
C4069 2113945L49 .01uF
C4201 2113944C45 100pF
C4202 2113945L49 .01uF
C4203 2113945L49 .01uF
C4204 2113944C45 100pF
C4205 2113945L49 .01uF
C4206 2313960F01 10uF
C4208 2113945C31 .1uF
C4209 2113945C31 .1uF
C4210 2113946N03 2.2uF
C4211 2113945C31 .1uF
C4213 2313960C78 2.2uF
C4214 2313960C78 2.2uF
C4215 2313960C78 2.2uF
C4217 2113945L49 .01uF
C4221 2113944F13 .01uF
C4222 2189705V01 .1uF
C4223 2115358H25 1uF
C4225 2113945L18 510pF
C4226 2113944M03 2.4pF
C4227 2113944C30 10pF
C4230 2113946N03 2.2uF
C4231 2113945L49 .01uF
C4232 2113945L49 .01uF
C4233 2113946N03 2.2uF
C4234 2113945L49 .01uF
C4235 2113945L49 .01uF
C4236 2113945C27 .047uF
C4242 2113944C45 100pF
Circuit
Ref
Motorola
Part No.
Description
C4243 2113944C45 100pF
C4244 2113944C45 100pF
C4245 2113944C45 100pF
C4246 2113944C45 100pF
C4251 2113945C31 .1uF
C4252 2113945L25 1000pF
C4253 2313960B30 4.7uF
C4254 2113945C31 .1uF
C4255 2113944C45 100pF
C4263 2113945C31 .1uF
C4287 2113944C45 100pF
C4289 2113945C31 .1uF
C4301 2113944C45 100pF
C4302 2113944M16 8.2pF
C4303 2113944M16 8.2pF
C4304 2113944M08 3.9pF
C4306 2113944M01 2pF
C4307 2113944C45 100pF
C4308 2113945C31 .1uF
C4309 2113944C45 100pF
C4311 2113944C45 100pF
C4312 2113944C31 12pF
C4314 2113944C67 1.5pF
C4315 2113944C45 100pF
C4316 2189705V01 .1uF
C4318 2113945C31 .1uF
C4321 2113944C63 1pF
C4324 2113944M03 2.4pF
C4325 2313960B30 4.7uF
C4331 2113944M14 6.8pF
C4335 2113944C45 100pF
C4336 2113945C04 2200pF
C4337 2113944C85 51pF
C4338 2113944C85 51pF
C4351 2113944C45 100pF
C4352 2113945C31 .1uF
C4353 2113945C31 .1uF
C4354 2113946N03 2.2uF
C4355 2113946N03 2.2uF
C4361 2113945L25 1000pF
C4364 2113944C71 5.6pF
C4365 2113944C67 1.5pF
C4371 2113945C31 .1uF
C4400 2113944C06 470pF
C4401 2113944C45 100pF
C4402 2113945L37 3300pF
C4403 2113944C73 6.8pF
C4404 2113944C45 100pF
C4405 2113944C45 100pF
C4406 2113944C45 100pF
C4407 2113944C45 100pF
Circuit
Ref
Motorola
Part No.
Description
C4408 2113944C45 100pF
C4411 2113945L37 3300pF
C4412 2113944C45 100pF
C4414 2113944C45 100pF
C4415 2113945C04 2200pF
C4416 2113944C45 100pF
C4417 2113944C82 30pF
C4419 2113944C33 18pF
C4420 2113944C77 11pF
C4421 2113945G57 .033uF
C4422 2113944F01 100pF
C4423 2313960C26 1uF
C4425 2113945L49 .01uF
C4426 2113944C45 100pF
C4427 2113945L25 1000pF
C4428 2113945L33 2200pF
C4431 2111078B23 24pF
C4434 2113945C25 .033uF
C4435 2113944F01 100pF
C4436 2113955E37 10uF
C4437 2113945G57 .033uF
C4439 2111078B42 100pF
C4440 2113945L25 1000pF
C4441 2111078B18 15pF
C4446 2111078B10 7.5pF
C4448 2111078B25 27pF
C4449 2111078B31 36pF
C4451 2113945L25 1000pF
C4452 2113944C78 13pF
C4453 2113944C45 100pF
C4455 2111078B12 9.1pF
C4457 2111078B27 30pF
C4458 2111078B32 39pF
C4459 2113944C45 100pF
C4471 2113944C45 100pF
C4472 2111078B31 36pF
C4473 2111078B31 36pF
C4474 2113944C45 100pF
C4475 2113944C71 5.6pF
C4491 2111078B12 9.1pF
C4492 2111078B32 39pF
C4496 2111078B09 6.8pF
C4497 2111078B07 5.6pF
C4501 2113945L33 2200pF
C4502 2113945L33 2200pF
C4503 2113944C06 470pF
C4504 2113945L49 .01uF
C4505 2313960B01 1uF
C4506 2113945L33 2200pF
C4507 2113944C45 100pF
C4508 2113944C45 100pF
Circuit
Ref
Motorola
Part No.
Description
