Chapter 1
MODEL CHARTS AND TECHNICAL SPECIFICATIONS
1.0 UHF Band 1 (403–470 MHz) 25–40 W Bipolar Model Charts
1.1 CDM Series Model Chart
CDM Series, UHF (403–470 MHz) 25–40 W Bipolar
(Conventional, LTR/PassPort)
Model Description
AAM25RKC9AA1AN CDM750, 403–470 MHz, 25–40 W, 12.5/20/25 kHz
AAM25RKD9AA2AN CDM1250, 403–470 MHz, 25–40 W, 12.5/20/25 kHz
AAM25RKF9AA5AN CDM1550, 403–470 MHz, 25–40 W, 12.5/20/25 kHz
AAM25RKF9DU5AN CDM1550•LS, 403–470 MHz, 25–40 W, 12.5/20/25 kHz
AAM25RKF9DP5AN CDM1550•LS+, 403–470 MHz, 25–40 W, 12.5/20/25 kHz
Item Description
X GCN6112 Control Head, CDM750
X GCN6113 Control Head, CDM1250
XXX GCN6114 Control Head, CDM1550
XXXX IMUE6024 Tanapa, UHF 403–470 MHz, 25–40 W, 12.5/20/25 kHz
X PMUE1756 Tanapa CDM1550•LS+, UHF 403–470 MHz, 25–40 W,
12.5/20/25 kHz
XXXXX HAE4002 Antenna, 403–430 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAE4010 Antenna, 406–420 MHz, 3.5dB Gain Roof Mount (Mini U)
X 6881091C54 User Guide, CDM750
X 6881091C55 User Guide, CDM1250
X 6881091C56 User Guide, CDM1550
X 6881093C32 User Guide, CDM1550•LS
X 6881094C79 User Guide, CDM1550•LS+
NOTE
If you wish to replace a bipolar board, you must replace it with the LDMOS tanapa (same
item number). (See
Section 92, Section 1.0: UHF Band 1 (403–470 MHz) 25–40 W LDMOS
Model Charts.)
