Section 8: 1-1
Section : 6881091C63-F
Chapter 1
MODEL CHARTS AND TECHNICAL SPECIFICATIONS
1.0 VHF (136–174 MHz) 25–45 W Bipolar Model Charts
1.1 CDM Series Model Chart
CDM Series, VHF (136–174 MHz) 25–45 W Bipolar
Model Description
AAM25KKC9AA1AN CDM750, 136–174 MHz, 25–45 W, 12.5/20/25 kHz
AAM25KKD9AA2AN CDM1250, 136–174 MHz, 25–45 W, 12.5/20/25 kHz
AAM25KKF9AA5AN CDM1550, 136–174 MHz, 25–45 W, 12.5/20/25 kHz
Item Description
X GCN6112 Control Head, CDM750
X GCN6113 Control Head, CDM1250
X GCN6114 Control Head, CDM1550
XXX IMUD6015 Tanapa, VHF 136–174 MHz, 25–45 W, 12.5/20/25 kHz
XXX HAD4006 Antenna, 136–144 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAD4007 Antenna, 146–150.8 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAD4008 Antenna, 150.8–162 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAD4009 Antenna, 162–174 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAD4014 Antenna, 146–172 MHz, 3dB Gain Roof Mount (Mini U)
X 6881091C54 User Guide, CDM750
X 6881091C55 User Guide, CDM1250
X 6881091C56 User Guide, CDM1550
NOTE
If you wish to replace a bipolar board, you must replace it with the LDMOS tanapa (same
item number). (See
Section 81, Section 1.0: VHF (136–174 MHz) 25–45 W LDMOS Model
Charts.)
To Next Page
