Motorola Pro3100 Detailed Service Manual

Section 13: 1-1
6881091C63-F
Chapter 1
MODEL CHARTS AND TECHNICAL SPECIFICATIONS
1.0 UHF Band 2 (450–512/520 MHz) 25–40 W LDMOS Model Charts
1.1 CDM Series Model Chart
CDM Series, UHF (450–512 MHz) 25–40 W LDMOS
(Conventional, LTR/PassPort)
Model Description
AAM25SKC9AA1AN CDM750, 450–512 MHz, 25–40 W, Conv Pref (LDMOS)
AAM25SKD9AA2AN CDM1250, 450–512 MHz, 25–40 W, Conv Pref (LDMOS)
AAM25SKF9AA5AN CDM1550, 450–512 MHz, 25–40 W, Conv Pref (LDMOS)
AAM25SKF9DU5AN CDM1550•LS, 450–512 MHz, 25–40 W, Conv Pref (LDMOS)
AAM25SKF9DP5AN
CDM1550•LS
+
, 450–512 MHz, 25–40 W, Conv Pref (LDMOS)
AAM25SKC9PW1AN CDM750 450–512 MHz 25–40 W Conv Pref (LDMOS)
AAM25SKD9PW2AN CDM1250 450–512 MHz 25–40 W Conv Pref (LDMOS)
AAM25SKF9PW5AN CDM1550 450–512 MHz 25–40 W Conv Pref (LDMOS)
Item Description
X X GCN6112_ Control Head, CDM750
X X GCN6113_ Control Head, CDM1250
XXX X GCN6114_ Control Head, CDM1550
XXXX IMUE6025 Tanapa, UHF 450–512 MHz, 25–40 W, 12.5/20/25 kHz
XXXX IMUE6025_S Replacement Board, UHF 450–512 MHz, 25–40 W, 12.5/20/25 kHz
X PMUE1757
Tanapa, CDM1550•LS
+
, 450–512 MHz, 25–40 W
X PMUE1757_S
Replacement Board, CDM1550•LS
+
, 450–512 MHz, 25–40 W
X XXPMUE1874_ Tanapa, UHF 450–512 MHz 25–40 W 12.5/20/25 kHz
X X X PMUE1874_S Replacement Board, UHF 450–512 MHz 25–40 W 12.5/20/25 kHz
XXXXXXXXHAE4003_ Antenna, 450–470 MHz, 1/4 Wave Roof Mount (Mini-U)
XXXXXXX X HAE4004_ Antenna, 470–512 MHz, 1/4 Wave Roof Mount (Mini-U)
XXXXXXXXHAE4011_ Antenna, 450–470 MHz, 3.5 dB Gain Roof Mount (Mini-U)
XXXXXXX X HAE4012_ Antenna, 470–494 MHz, 3.5 dB Gain Roof Mount (Mini-U)
XXXXXXXXHAE4013_ Antenna, 494–512 MHz, 5 dB Gain Roof Mount (Mini-U)
X X 6881091C54 User Guide, CDM750
X X 6881091C55 User Guide, CDM1250
X X 6881091C56 User Guide, CDM1550
X 6881093C32 User Guide, CDM1550•LS
X 6881094C79 User Guide, CDM1550•LS+
