Motorola Pro3100 Detailed Service Manual

Controller T6/T7/T9 Schematics and Parts Lists Section 3: 3-31
6881091C63-F
Controller T9 Parts List (8471224L01)
Circuit
Ref
Motorola
Part No.
Description
C0101 2113944C45 CAP 100 PF
C0107 2113945L25 CAP 1000 PF
C0112 2113945C31 CAP 0.1 UF
C0121 2113945C31 CAP 0.1 UF
C0122 2113945C31 CAP 0.1 UF
C0131 2113944C34 CAP 22 PF
C0132 2113944C34 CAP 22 PF
C0141 2113945C31 CAP 0.1 UF
C0151 2113945L49 CAP 10000 PF
C0201 2313960D07 CAP 10 UF
C0202 2313960D07 CAP 10 UF
C0204 2113945C31 CAP 0.1 UF
C0212 2313960D07 CAP 10 UF
C0221 2113945C31 CAP 0.1 UF
C0222 2113945C31 CAP 0.1 UF
C0223 0613952G67 0 Ohm (SUB on LS+ Models
Only)
C0224 2113944C45 CAP 100 PF
C0225 2113945C31 CAP 0.1 UF
C0226 2113945C31 CAP 0.1 UF
C0228 2313960B30 CAP 4.7 UF
C0231 2113955D31 CAP 1 UF
C0232 2113945C31 CAP 0.1 UF
C0234 2113945C31 CAP 0.1 UF
C0235 2113945C04 CAP 0.022 UF
C0236 2113945C25 CAP 0.033 UF
C0241 2113945C31 CAP 0.1 UF
C0243 2113944C45 CAP 100 PF
C0244 2113945C31 CAP 0.1 UF
C0245 2113945C31 CAP 0.1 UF
C0246 2113945L49 CAP 10000 PF
C0251 2113945C31 CAP 0.1 UF
C0252 2313960B01 CAP 1 UF
C0254 2113945C31 CAP 0.1 UF
C0255 2113945C31 CAP 0.1 UF
C0256 2113944C45 CAP 100 PF
C0261 2113945C31 CAP 0.1 UF
C0262 2113944C43 CAP 82 PF
C0265 2113945C31 CAP 0.1 UF
C0267 2113945L49 CAP 10000 PF
C0271 2113945L49 CAP 10000 PF
C0272 2113945C31 CAP 0.1 UF
C0273 2113945L37 CAP 3300 PF
C0275 2313960F30 CAP 47 UF
C0276 2113945L25 CAP 1000 PF
C0277 2113945L25 CAP 1000 PF
C0301 2313960B01 CAP 1 UF
C0302 2113945C31 CAP 0.1 UF
C0303 2113944C45 CAP 100 PF
C0304 2113945C31 CAP 0.1 UF
C0305 2113945C31 CAP 0.1 UF
C0324 2113945C31 CAP 0.1 UF
C0331 2113945C31 CAP 0.1 UF
C0341 2313960B01 CAP 1 UF
C0342 2113945C31 CAP 0.1 UF
C0343 2113945C31 CAP 0.1 UF
C0344 2113945C31 CAP 0.1 UF
C0351 2113945C31 CAP 0.1 UF
C0352 2113945C04 CAP 0.022 UF
C0353 2313960F04 CAP 33 UF
C0354 2113945C31 CAP 0.1 UF
C0421 2113944A38 CAP 82 PF
C0422 2113945L17 CAP 470 PF
C0423 2113945L17 CAP 470 PF
C0426 2113945A05 CAP 470 PF
C0427 2113945A05 CAP 470 PF
C0428 2113944A38 CAP 82 PF
C0429 2113945A05 CAP 470 PF
C0430 2113945L17 CAP 470 PF
C0431 2113945L17 CAP 470 PF
C0441 2113945A05 CAP 470 PF
C0442 2113945A05 CAP 470 PF
C0445 2113945A05 CAP 470 PF
C0446 2113945A05 CAP 470 PF
C0447 2113945A05 CAP 470 PF
C0448 2113945A05 CAP 470 PF
C0449 2113945A05 CAP 470 PF
C0470 2113945A05 CAP 470 PF
C0471 2113944A38 CAP 82 PF
C0472 2113944A38 CAP 82 PF
C0473 2113944A38 CAP 82 PF
C0474 2113945A05 CAP 470 PF
C0476 2113945A05 CAP 470 PF
C0477 2113945A05 CAP 470 PF
C0478 2113945A05 CAP 470 PF
C0482 2113945A05 CAP 470 PF
C0483 2113945A05 CAP 470 PF
C0484 2113945L17 CAP 470 PF
C0485 2113945A05 CAP 470 PF
C0486 2113945A05 CAP 470 PF
C0487 2113945A05 CAP 470 PF
C0488 2113945A05 CAP 470 PF
C0490 2113945A05 CAP 470 PF
C0491 2113945A05 CAP 470 PF
C0492 2113945A05 CAP 470 PF
C0493 2113945A05 CAP 470 PF
Circuit
Ref
Motorola
Part No.
Description
C0494 2113945A05 CAP 470 PF
C0495 2113945A05 CAP 470 PF
C0496 2113945A05 CAP 470 PF
C0497 2113945A05 CAP 470 PF
C0499 2113945A05 CAP 470 PF
C0501 2113945L49 CAP 10000 PF
C0502 2113945L17 CAP 470 PF
C0503 2113945L17 CAP 470 PF
C0504 2113945L17 CAP 470 PF
C0505 2113945L17 CAP 470 PF
C0506 2113945L17 CAP 470 PF
C0508 2113945L17 CAP 470 PF
C0509 2113945L17 CAP 470 PF
C0510 2113945L17 CAP 470 PF
C0511 2113945L17 CAP 470 PF
C0512 2113945L17 CAP 470 PF
C0513 2113945L17 CAP 470 PF
C0514 2113945L17 CAP 470 PF
C0515 2113945L17 CAP 470 PF
C0516 2113945L49 CAP 10000 PF
C0517 2113944A38 CAP 82 PF
C0518 2113945L17 CAP 470 PF
C0541 2313960A55 CAP 0.47 UF
C0542 2313960F30 CAP 47 UF
C0560 2113945A09 CAP 1000 PF
C0591 2113945C31 CAP 0.1 UF
C0592 2113945C31 CAP 0.1 UF
C0593 0613958T74 0 Ohm (SUB on LS+ Models
Only)
C0601 2113945L17 CAP 470 PF
C0603 2389289U01 CAP 10 UF
C0611 2314030J28 CAP 22 UF
C0612 2113945C31 CAP 0.1 UF
C0622 2313960F30 CAP 47 UF
C0641 2113945L17 CAP 470 PF
C0644 2313960F04 CAP 33 UF
C0645 2113945C31 CAP 0.1 UF
C0652 2313960F04 CAP 33 UF
C0654 2313960D07 CAP 10 UF
C0655 2113945C31 CAP 0.1 UF
C0661 2314030H05 CAP 47 UF
C0662 2113945L49 CAP 10000 PF
C0663 2113945C31 CAP 0.1 UF
C0671 2113945C31 CAP 0.1 UF
C0681 2113945C31 CAP 0.1 UF
D0101 4813974A05 DIODE MMBD301L
D0151 4813978C02 DIODE DUAL 70V
D0179 4813978C02 DIODE DUAL 70V
Circuit
Ref
Motorola
Part No.
Description
D0301 4885317Y01 DIODE SCHOTTKY
BARRIER
D0621 4813978C02 DIODE DUAL 70V
D0651 4813978C02 DIODE DUAL 70V
D0660 4813978C02 DIODE DUAL 70V
D0661 4813978C02 DIODE DUAL 70V
E0271 2415954H02 INDUCTOR BEAD
E0272 2415954H02 INDUCTOR BEAD
E0631 2415954H02 INDUCTOR BEAD
F0401 6515076H01 FUSE TR/1608FF
J0401 0916162H02 12 POS FLEX
CONNECTOR
J0451 0916162H01 18 POS FLEX
CONNECTOR
J0501 0966512A01 20 POS FLEX
CONNECTOR
J0551 0915064H03 CONN ZIF HORIZONTAL
J0552 0915064H01 CONN ZIF HORIZONTAL
J0601 0986165B02 DC POWER CONNECTOR
Q0110 4813973A42 TRANSISTOR NPN
DIGITAL
Q0151 4813973A42 TRANSISTOR NPN
DIGITAL
Q0171 4813973A42 TRANSISTOR NPN
DIGITAL
Q0173 4816147H01 TTRANSISTOR NPN
MXTA27
Q0177 4813973A42 TRANSISTOR NPN
DIGITAL
Q0181 4813973A42 TRANSISTOR NPN
DIGITAL
Q0183 4813973A42 TRANSISTOR NPN
DIGITAL
Q0185 4813973A42 TRANSISTOR NPN
DIGITAL
Q0271 4813973M07 TRANSISTOR MMBT3904
Q0641 4813973A42 TRANSISTOR NPN
DIGITAL
Q0661 4816097H01 TRANSISTOR FMC2
Q0662 4813973M07 TRANSISTOR MMBT3904
Q0663 4813973A42 TRANSISTOR NPN
DIGITAL
Q0681 4816147H01 TTRANSISTOR NPN
MXTA27
R0101 0613952J01 RES 10K Ohm
R0102 0613952H89 RES 4700 Ohm
R0103 0613952H25 RES 10 Ohm
R0104 0613952J01 RES 10K Ohm
R0105 0613952J25 RES 100K Ohm
R0106 0613952G67 RES 0 Ohm
R0108 0613952H81 RES 2200 Ohm
R0111 0613952G67 RES 0 Ohm
Circuit
Ref
Motorola
Part No.
Description
