Motorola Pro3100 Detailed Service Manual

Section 2: 4-12 Control Head CDM1250 / PRO5100 / CDM1550 Series / PRO7100 PCB 8486155B06, Schematics, and Parts Lists
6881091C63-F
Control Head PCB 8486155B06 Parts List
†
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not field-replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
†
Replacement boards must be ordered from
RPSO (formerly CCSD and/or AAD) using the
number shown in the model charts in Chapters
4 – 13. Boards are not orderable using the 84-
prefixed number.
Circuit
Ref
Motorola
Part No.
Description
C0803 2113741F17 470pF 50V
C0804 2113741F17 470pF 50V
C0805 2113740F49 82pF 5% 50V NP0
C0807 2113741F17 470pF 50V
C0811 2113741F17 470pF 50V
C0812 2113741F17 470pF 50V
C0813 2113741F17 470pF 50V
C0815 2113741F17 470pF 50V
C0816 2113741F17 470pF 50V
C0817 2113740F49 82pF 5% 50V
C0822 2311049A40 TANT CP 2.2uF 10% 10V
C0823 2113741F49 10nF 50V
C0831 2311049A42 TANT CP 3.3uF 10% 6V
C0832 2113743E20 100nF 16V
C0833 2113743E20 100nF 16V
C0843 2311049A40 TANT CP 2.2uF 10% 10V
C0931 2113743E20 100nF 16V
C0933 2113743E20 100nF 16V
C0971 2311049A07 TANT CP 1uF 10% 16V
C0973 2311049A07 TANT CP 1uF 10% 16V
C0974 2113743E20 100nF 16V
C0975 2113743E20 100nF 16V
C0976 2113743E20 100nF 16V
C0978 2113743E20 100nF 16V
C0980 2113743E20 100nF 16V
C0983 2311049A09 TANT CP 2.2uF 10% 20V
C0984 2113741F49 10nF 50V
C0985 2311049A40 TANT CP 2.2uF 10% 10V
D0821 4813833C02 DIODE DUAL SOT
MMBD6100
D0822 4813833C02 DIODE DUAL SOT
MMBD6100
D0831 4880236E05 DIODE CHIP SCHOTTKY
D0877 4886171B01 LED RED
D0879 4886171B04 LED GREEN
D0880 4886171B03 LED YELLOW
D0951 4886171B02 LED ORANGE
Not used in Control Head B
D0952 4886171B02 LED ORANGE
Not used in Control Head B
D0953 4886171B02 LED ORANGE
Not used in Control Head B
D0954 4886171B02 LED ORANGE
Not used in Control Head B
D0965 4886171B04 LED GREEN
D0966 4886171B04 LED GREEN
D0967 4886171B04 LED GREEN
D0968 4886171B04 LED GREEN
D0969 4886171B04 LED GREEN
D0970 4886171B04 LED GREEN
D0971 4886171B04 LED GREEN
D0972 4886171B04 LED GREEN
D0973 4886171B04 LED GREEN
D0974 4886171B04 LED GREEN
D0975 4886171B04 LED GREEN
D0976 4886171B04 LED GREEN
D0977 4886171B04 LED GREEN
D0978 4886171B04 LED GREEN
D0979 4886171B04 LED GREEN
D0980 4886171B04 LED GREEN
D0981 4886171B04 LED GREEN
Not used in Control Head B
D0982 4886171B04 LED GREEN
Not used in Control Head B
D0983 4886171B04 LED GREEN
Not used in Control Head B
D0984 4886171B04 LED GREEN
Not used in Control Head B
D0985 4886171B04 LED GREEN
D0986 4886171B04 LED GREEN
D0987 4886171B04 LED GREEN
D0988 4886171B04 LED GREEN
J0801 0902636Y02 CONNECTOR FLEX 12 PIN
J0811 2864287B01 CONN TELCO 10 PIN JACK
P0801 2809926G01 CONN 1.25MM 2PIN SUR MT
Q0821 4805921T02 TSTR DUAL ROHM FMC2 RH
Q0822 4880048M01 TSTR NPN DIG 47k/47k
Q0823 4805921T02 TSTR DUAL ROHM FMC2 RH
Q0841 4880048M01 TSTR NPN DIG 47k/47k
Q0843 4880048M01 TSTR NPN DIG 47k/47k
Q0877 4813824A10 TSTR NPN 40V .2A B=50-150
Q0878 4813824A10 TSTR NPN 40V .2A B=50-150
Q0879 4813824A10 TSTR NPN 40V .2A B=50-150
Q0933 4813822A08 TSTR PNP 25V 5AMJD210T4
Q0934 4813824A10 TSTR NPN 40V .2A B=50-150
R0810 0662057A76 13k 1/16W 5%
R0811 0662057A90 51k 1/16W 5%
R0812 0662057A09 22 1/16W 5%
R0813 0662057A01 10 1/16W 5%
R0814 0662057A35 270 1/16W 5%
R0815 0662057A76 13k 1/16W 5%
R0816 0662057A90 51k 1/16W 5%
R0817 0662057A09 22 1/16W 5%
R0821 0662057A73 10k 1/16W 5%
R0822 0662057A76 13k 1/16W 5%
R0823 1805911V02 POT VOL
R0824 0662057A65 4700 1/16W 5%
R0825 0662057A49 1k 1/16W 5%
R0831 0662057B22 1M 1/16W 5%
R0832 0662057A57 2200 1/16W 5%
Circuit
Ref
Motorola
Part No.
Description
R0833 0662057A89 47k 1/16W 5%
R0834 0662057A35 270 1/16W 5%
R0835 0662057A25 100 1/16W 5%
R0836 0662057A73 10k 1/16W 5%
R0837 0662057A85 33k 1/16W 5%
R0838 0662057A73 10k 1/16W 5%
R0841 0662057A73 10k 1/16W 5%
R0842 0662057A89 47k 1/16W 5%
R0843 0662057A57 2.2k 1/16W 5%
R0844 0662057A73 10k 1/16W 5%
R0845 0662057A65 4700 1/16W 5%
R0847 0662057A93 68k 1/16W 5%
R0849 0662057A89 47k 1/16W 5%
R0852 0662057A89 47k 1/16W 5%
Not used in Control Head B
R0853 0662057A89 47k 1/16W 5%
Not used in Control Head C
R0855 0662057A89 47k 1/16W 5%
R0856 0662057A89 47k 1/16W 5%
R0857 0662057A89 47k 1/16W 5%
Not used in Control Head C
R0858 0662057A89 47k 1/16W 5%
Not used in Control Head B
R0859 0662057A89 47k 1/16W 5%
R0860 0662057A97 100k 1/16W
R0861 0662057A97 100k 1/16W
R0862 0662057A97 100k 1/16W
R0863 0662057A65 4700 1/16W 5%
R0864 0662057A65 4700 1/16W 5%
R0865 0662057A65 4700 1/16W 5%
R0877 0660076A35 270 5 1/8
R0878 0660076A35 270 5 1/8
R0879 0660076A35 270 5 1/8
R0901 0662057A90 51k 1/16W 5%
R0902 0662057A76 13k 1/16W 5%
R0903 0662057A81 22k 1/16W 5%
R0904 0662057A88 43k 1/16W 5%
R0906 0662057A90 51k 1/16W 5%
R0907 0662057A76 13k 1/16W 5%
R0908 0662057A81 22k 1/16W 5%
R0909 0662057A88 43k 1/16W 5%
Not used in Control Head B
R0935 0662057A73 10k 1/16W 5%
R0936 0662057A73 10k 1/16W 5%
R0937 0660076A01 10 5 1/8
R0941 0662057A73 10k 1/16W 5%
R0942 0662057A85 33k 1/16W 5%
R0943 0662057A65 4700 1/16W 5%
R0944 0662057A97 100k 1/16W
R0945 0662057A73 10k 1/16W 5%
R0946 0662057A73 10k 1/16W 5%
Circuit
Ref
Motorola
Part No.
Description
R0947 0660076A01 10 5 1/8
R0948 0660076A01 10 5 1/8
R0972 0662057B47 0 1/16W
R0973 0662057B24 1.2M 1/16W 5%
R0974 0662057B28 1.8M 1/16W 5%
R0975 0662057G29 200k 0.1W 1%
R0976 0662057G13 100k 0.1W 1%
*U0831 5113802A24 IC 68HC11 W/SCI,SPI,A/D
U0832 5113815A02 MC33064
UNDER VLTG SENSING
U0833 4886061B01 CER RESONATOR 8MHZ
CSTCC8.00MG
U0834 5185963A15 TEMP SENSOR 1M5
U0931 5113818A03 IC HIGH PERFORMANCE SI
U0971 5186158B01 LCD DRIVER SED1526F0A
VR0812 4813830A15 DIODE 5.6V 5% 225mW
VR0816 4805656W09 DIODE ZENER QUAD
MMQA20VT1
VR0817 4805656W09 DIODE ZENER QUAD
MMQA20VT1
VR0821 4813830A15 DIODE 5.6V 5% 225mW
VR0822 4813830A15 DIODE 5.6V 5% 225mW
Circuit
Ref
Motorola
Part No.
Description
