Motorola Pro3100 Detailed Service Manual

UHF Band 1 (403–470 MHz) 1–25 W PCB 8471224L04, Schematics, and Parts Lists Section 5: 4-37
6881091C63-F
C4221 2113944F13 CAP,CHIP,.01UF,+5%,-5%,50V-
DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C4222 2189705V01 CAP,CER,.1UF,+5%,-5%,50V-DC,-
55DEG CMIN,85DEG CMAX,PB-
FREE
C4223 2115358H25 PLASTIC FILM CAPACITORS
C4225 2113945L18 CAP,FXD,510PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4226 2113944M03 CAP,FXD,2.4PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4227 2113944C30 CAP CER CHP 10.0PF 50V +/-
0.5PF
C4230 2113946N03 CAP CER CHP 2.2UF 16V
C4231 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4232 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4233 2113946N03 CAP CER CHP 2.2UF 16V
C4234 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4235 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4236 2113945C27 CAP,FXD,.047UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C4242 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4243 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4244 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4245 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4246 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4251 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4252 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4253 2313960B30 CAP,FXD,4.7UF,+10%,-10%,10V-
DC,SM,-55DEG CMIN,125DEG
CMAX,122MA
C4254 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4255 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4263 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4287 2113944C45 CAP CER CHP 100.0PF 50V 5%
Circuit
Ref
Motorola
Part No.
Description
C4289 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4301 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4302 2113944M16 CAP,FXD,8.2PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4303 2113944M16 CAP,FXD,8.2PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4304 2113944M08 CAP,FXD,3.9PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4306 2113944M01 CAP,FXD,2PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4307 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4308 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4309 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4311 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4312 2113944C31 CAP CER CHP 12.0PF 50V 5%
C4314 2113944C67 CAP,FXD,1.5PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4315 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4316 2189705V01 CAP,CER,.1UF,+5%,-5%,50V-DC,-
55DEG CMIN,85DEG CMAX,PB-
FREE
C4318 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4321 2113944C63 CAP,FXD,1PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4324 2113944M03 CAP,FXD,2.4PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4325 2313960B30 CAP,FXD,4.7UF,+10%,-10%,10V-
DC,SM,-55DEG CMIN,125DEG
CMAX,122MA
C4331 2113944M14 CAP,FXD,6.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4335 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4336 2113945C04 CAP CER CHP 22,000PF 50V
10%
C4337 2113944C85 CAP,FXD,51PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4338 2113944C85 CAP,FXD,51PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4351 2113944C45 CAP CER CHP 100.0PF 50V 5%
Circuit
Ref
Motorola
Part No.
Description
C4352 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4353 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4354 2113946N03 CAP CER CHP 2.2UF 16V
C4355 2113946N03 CAP CER CHP 2.2UF 16V
C4361 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4364 2113944C71 CAP,FXD,5.6PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4365 2113944C67 CAP,FXD,1.5PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4371 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4400 2113944C06 CAP CER CHP 470.0PF 50V 5%
C4401 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4402 2113945L37 CAP,FXD,3300PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4403 2113944C73 CAP,FXD,6.8PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4404 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4405 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4406 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4407 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4408 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4411 2113945L37 CAP,FXD,3300PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4412 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4414 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4415 2113945C04 CAP CER CHP 22,000PF 50V
10%
C4416 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4417 2113944C82 CAP,FXD,30PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4419 2113944C33 CAP CER CHP 18.0PF 50V 5%
C4420 2113944C77 CAP,FXD,11PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4421 2113945G57 CAP,FXD,.033UF,+5%,-5%,50V-
DC,0805,X7R,-55DEG
CMIN,125DEG CMAX
C4422 2113944F01 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
Circuit
Ref
Motorola
Part No.
Description
C4423 2313960C26 CAP,FXD,1UF,+10%,-10%,35V-
DC,SM,-55DEG CMIN,125DEG
CMAX,114MA,E
C4425 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C4426 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4427 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4428 2113945L33 CAP,FXD,2200PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4431 2111078B23 CAP CHIP RF 24 5 NPO 100V
C4434 2113945C25 CAP,FXD,.033UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C4435 2113944F01 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C4436 2.11E+43 CAP,FXD,10UF,+10%,-10%,16V-
DC,1210,X7R,-55DEG
CMIN,125DEG CMAX
C4437 2113945G57 CAP,FXD,.033UF,+5%,-5%,50V-
DC,0805,X7R,-55DEG
CMIN,125DEG CMAX
C4439 2111078B42 CAP CHIP RF 100 5 NPO 100V
C4440 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4441 2111078B18 CAP CHIP RF 15 5 NPO 100V
C4446 2111078B10 CAP CHIP RF 7.5 .25 NPO 100V
C4448 2111078B25 CAP CHIP RF 27 5 NPO 100V
C4449 2111078B31 CAP CHIP RF 36 5 NPO 100V
C4451 2113945L25 CAP,FXD,1000PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C4452 2113944C78 CAP,FXD,13PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C4453 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4455 2111078B12 CAP CHIP RF 9.1 .5 NPO 100V
C4457 2111078B27 CAP CHIP RF 30 5 NPO 100V
C4458 2111078B32 CAP CHIP RF 39 5 NPO 100V
C4459 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4471 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4472 2111078B31 CAP CHIP RF 36 5 NPO 100V
C4473 2111078B31 CAP CHIP RF 36 5 NPO 100V
C4474 2113944C45 CAP CER CHP 100.0PF 50V 5%
C4475 2113944C71 CAP,FXD,5.6PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C4491 2111078B12 CAP CHIP RF 9.1 .5 NPO 100V
C4492 2111078B32 CAP CHIP RF 39 5 NPO 100V
C4496 2111078B09 CAP CHIP RF 6.8 .25 NPO 100V
C4497 2111078B07 CAP CHIP RF 5.6 .25 NPO 100V
Circuit
Ref
Motorola
Part No.
Description
