Motorola Pro3100 Detailed Service Manual

Section 3: 3-38 Controller T11 Schematics and Parts Lists
6881091C63-F
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not field-replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
R0117 0662057A63 RES, 3.9K
R0121 0662057A97 RES, 100K
R0131 0662057B46 RES, 10MEG
R0132 0662057B10 RES, 330K
R0151 0662057A82 RES, 24K
R0152 0662057A82 RES, 24K
R0170 0662057A73 RES, 10K
R0171 0662057A65 RES, 4.7K
R0172 0662057A73 RES, 10K
R0173 0662057A65 RES, 4.7K
R0174 0662057A73 RES, 10K
R0175 0662057A73 RES, 10K
R0176 0662057A84 RES, 30K
R0177 0662057A65 RES, 4.7K
R0178 0662057A89 RES, 47K
R0179 0662057A89 RES, 47K
R0181 0662057A65 RES, 4.7K
R0182 0662057A89 RES, 47K
R0183 0662057A65 RES, 4.7K
R0184 0662057A89 RES, 47K
R0185 0662057A65 RES, 4.7K
R0186 0662057A89 RES, 47K
R0201 0662057A25 RES, 100
R0202 0662057A43 RES, 560
R0203 0662057A25 RES, 100
R0204 0662057A43 RES, 560
R0205 0662057A73 RES, 10K
R0206 0662057A73 RES, 10K
R0207 0662057A57 RES, 2.2K
R0208 0662057A57 RES, 2.2K
R0211 0660076E70 RES, 7.5K
R0212 0660076E70 RES, 7.5K
R0221 0662057A82 RES, 24K
R0222 0662057A82 RES, 24K
R0223 0662057A84 RES, 30K
R0224 0662057A71 RES, 8.2K
R0228 0662057B47 RES, 0
R0229 0662057A01 RES, 10
R0241 0662057A89 RES, 47K
R0242 0662057B47 RES, 0
R0251 0662057A89 RES, 47K
R0252 0662057A91 RES, 56K
R0253 0662057A97 RES, 100K
R0254 0662057A73 RES, 10K
Circuit
Ref
Motorola
Part No.
Description
R0255 0662057A73 RES, 10K
R0256 0662057A97 RES, 100K
R0257 0662057A57 RES, 2.2K
R0261 0662057A73 RES, 10K
R0262 0662057B08 RES, 270K
R0265 0662057A82 RES, 24K
R0267 0662057A89 RES, 47K
R0268 0662057A73 RES, 10K
R0269 0662057A41 RES, 470
R0273 0662057A82 RES, 24K
R0275 0662057A73 RES, 10K
R0276 0662057A77 RES, 15K
R0401 0662057A33 RES, 220
R0407 0662057M26 RES, 10
R0408 0662057A25 RES, 100
R0409 0662057M26 RES, 10
R0412 0662057B47 RES, 0
R0441 0662057B47 RES, 0
R0442 0662057A49 RES, 1K
R0467 0662057M26 RES, 10
R0468 0662057A97 RES, 100K
R0481 0662057B47 RES, 0
R0482 0662057B47 RES, 0
R0508 0662057A41 RES, 470
R0509 0662057B47 RES, 0
R0510 0662057A65 RES, 4.7K
R0511 0662057A97 RES, 100K
R0512 0662057A77 RES, 15K
R0525 0662057A97 RES, 100K
R0529 0662057A89 RES, 47K
R0530 0662057A81 RES, 22K
R0531 0662057A43 RES, 560
R0533 0662057B47 RES, 0
R0535 0662057A49 RES, 1K
R0537 0662057A33 RES, 220
R0538 0662057A33 RES, 220
R0539 0662057A65 RES, 4.7K
R0541 0662057A83 RES, 27K
R0543 0662057A97 RES, 100K
R0555 0662057A25 RES, 100
R0556 0662057A25 RES, 100
R0591 0662057A82 RES, 24K
R0592 0662057A01 RES, 10
R0593 0662057A97 RES, 100K
Circuit
Ref
Motorola
Part No.
Description
R0611 0662057A91 RES, 56K
R0612 0662057A65 RES, 4.7K
R0621 0662057A82 RES, 24K
R0641 0662057A73 RES, 10K
R0642 0660076E70 RES, 7.5K
R0643 0660076E51 RES, 1.2K
R0651 0662057A01 RES, 10
R0652 0662057A01 RES, 10
R0661 0662057A49 RES, 1K
R0662 0662057B02 RES, 150K
R0671 0662057A84 RES, 30K
R0672 0662057A73 RES, 10K
R0681 0662057A79 RES, 18K
R0682 0662057A93 RES, 68K
U0101 5102226J56 MC68HC11FL0
U0111 5102463J64 EEPROM
U0121 5186137B01 FLASH ROM
U0122 5185748L01 SRAM
U0141 5113805A30 REMUX
U0211 5183222M49 MC3403
U0221 5185130C53 ASFIC COMPANDER IC
U0251 5184704M60 MUX/DEMUX
U0271 5109699X01 AUDIO PA
U0611 5183308X01 LM2941
U0641 5183308X01 LM2941
U0651 5113816A07 MC78M05
U0652 5113815A02 MC33064
VR0151 4813830A15 MMBZ5232B
VR0501 4805656W09 MMQA20VT1
VR0503 4805656W09 MMQA20VT1
VR0504 4813830A40 MMBZ5257B
VR0505 4805656W09 MMQA20VT1
VR0509 4813830A40 MMBZ5257B
VR0510 4813830A40 MMBZ5257B
VR0537 4813830A15 MMBZ5232B
VR0541 4813830A27 MMBZ5244B
VR0601 4813832C77 TRANSIENT SUPPRES-
SOR
VR0621 4813830A15 MMBZ5232B
Y0131 4880113R19 CRYSTAL, 38.4 KHZ
Circuit
Ref
Motorola
Part No.
Description
