Motorola Pro3100 Detailed Service Manual

Controller T12 Schematics and Parts Lists Section 3: 3-45
6881091C63-F
R0183 0613952H89 4700
R0184 0613952J17 47K
R0185 0613952H89 4700
R0186 0613952J17 47K
R0201 0613952H49 100
R0202 0613952H67 560
R0203 0613952H49 100
R0204 0613952H71 560
R0205 0613952J01 10K
R0206 0613952J01 10K
R0207 0613952H81 2200
R0208 0613952H81 2200
R0211 0613958D85 7500
R0212 0613958D85 7500
R0221 0613952J10 24K
R0222 0613952J10 24K
R0223 0613952J12 30K
R0224 0613952H95 8200
R0228 0613952G67 0
R0229 0613952H25 10
R0241 0613952J17 47K
R0242 0613952G67 0
R0251 0613952J17 47K
R0252 0613952J19 56K
R0253 0613952J25 100K
R0254 0613952J01 10K
R0255 0613952J01 10K
R0256 0613952J25 100K
R0257 0613952H81 2200
R0261 0613952J01 10K
R0262 0613952J35 270K
R0265 0613952J10 24K
R0267 0613952J17 47K
R0268 0613952J01 10K
R0269 0613952H65 470
R0273 0613952J10 24K
R0275 0613952J01 10K
R0276 0613952J05 15K
R0401 0613952H57 220
R0407 0613952Q25 10
R0408 0613952H49 100
R0409 0613952Q25 10
R0412 0613952G67 0
R0441 0613952G67 0
R0442 0613952H73 1000
R0467 0613952Q25 10
R0468 0613952J25 100K
Circuit
Ref
Motorola
Part No.
Description
R0481 0613952G67 0
R0482 0613952G67 0
R0508 0613952H65 470
R0509 0613952G67 0
R0510 0613952H89 4700
R0511 0613952J25 100K
R0512 0613952J05 15K
R0525 0613952J25 100K
R0529 0613952J17 47K
R0530 0613952J09 22K
R0531 0613952H67 560
R0533 0613952G67 0
R0535 0613952H73 1000
R0537 0613952H57 220
R0538 0613952H57 220
R0539 0613952H89 4700
R0541 0613952J11 27K
R0543 0613952J25 100K
R0555 0613952H49 100
R0556 0613952H49 100
R0591 0613952J10 24K
R0592 0613952H25 10
R0593 0613952J25 100K
R0611 0613952J19 56K
R0612 0613952H89 4700
R0621 0613952J10 24K
R0641 0613952J01 10K
R0642 0613958D85 7500
R0643 0613958D09 1200
R0651 0613952H25 10
R0652 0613952H25 10
R0661 0613952H73 1000
R0662 0613952J29 150K
R0671 0613952J12 30K
R0672 0613952J01 10K
R0681 0613952J07 18K
R0682 0613952J21 68K
U0101 5185143E03 IC MICROPROCESSOR
U0111 5116648H01 128K SERIAL EEPROM
U0121 5115034H01 IC FLASH ROM 4MBIT
U0122 5116096H01 IC 32K X 8 SRAM
U0141 5114000A14 IC DECODER/REMUX
U0211 5114016A18 IC QUAD OP AMP
U0221 5115062H01 IC ASFIC_CMP
U0251 5114002A17 IC-CMOS ANALOG
U0271 5102463J95 AUDIO PA TDA1519C
U0611 5164015H94 IC VOLTAGE RGTR
Circuit
Ref
Motorola
Part No.
Description
U0641 5164015H94 IC VOLTAGE RGTR
U0651 5114014A07 REG 5V
U0652 5114004A02 IC UNDERVOLTAGE SENSOR
VR0151 4813977M11 TSTR 5.6V
VR0501 4813979C11 DIODE QUAD 20 VOLT
VR0503 4813979C11 DIODE QUAD 20 VOLT
VR0504 4813977M36 ZENER DIODE
VR0505 4813979C11 DIODE QUAD 20 VOLT
VR0509 4813977M36 ZENER DIODE
VR0510 4813977M36 ZENER DIODE
VR0537 4813977M11 TSTR 5.6V
VR0541 4813977M23 DIODE 14V
VR0601
4813832C77
TRANSIENT SUPPRESSOR
VR0621 4813977M11 TSTR 5.6V
Y0131 4816169H01 CRYSTAL 38.4KHZ
Circuit
Ref
Motorola
Part No.
Description
