Motorola Pro3100 Detailed Service Manual

Section 5: 4-8 UHF Band 1 (403–470 MHz) 1–25 W LDMOS PCB 8471224L03, Schematics, and Parts Lists
6881091C63-F
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not field replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
†
Replacement boards must be ordered from
RPSO (formerly CCSD and/or AAD) using the
number shown in the model charts in Section 1.
Boards are not orderable using the 84-prefixed
number.
††
Parts with Fab IC from Texas
R4424 0613958H11 2.7 Ohm
R4425 0613958H11 2.7 Ohm
R4426 0613958H11 2.7 Ohm
R4427 0613958H11 2.7 Ohm
R4428 0613952J01 10K Ohm
R4429 0613952H67 560 Ohm
R4431 0613959Y42 51 Ohm
R4441 0613952J15 39K Ohm
R4442 0613952H81 2200 Ohm
R4443 0613952J15 39K Ohm
R4445 0613952H82 2400 Ohm
R4446 0613952G67 0.0 Ohm
R4452 0613952J03 12K Ohm
R4454 0613952J01 10K Ohm
R4455 0613952J25 100K Ohm
R4457 0613959Y51 Ohm
R4458 0613952H65 470 Ohm
R4471 0613952H65 470 Ohm
R4473 0613959Y42 51 Ohm
R4474 0613959Y42 51 Ohm
R4475 0613952J01 10K Ohm
R4491 0613952J01 10K Ohm
R4501 0613952H93 6800 Ohm
R4502 0613952J11 27K Ohm
R4504 0613952J01 10K Ohm
R4505 0613952J36 300K Ohm
R4507 0613952J08 20K Ohm
R4508 0613952J25 100K Ohm
R4509 0613952H73 1000 Ohm
R4511 0613958H17 4.7 Ohm
R4592 2415429H47 CHIP INDUCTOR
SH4301 2602641Y03 SHIELD ARIANE VCO
SH4302 2602641Y03 SHIELD ARIANE VCO
T4051 2516149H01 XFMR JEDI MIXER4-1
T4052 2516148H01 XMFR MIXER5-1
U3101 5115281H01 FM IF IC SA616 FROM
PHILIPS
U3111 5185291Y01 QUAD ANALOG SWIITCH
U3115 5185291Y01 QUAD ANALOG SWIITCH
U4201 5185177Y01 FRACN IC
U4211 5115026H01 MAX SUPPLY VOL
U4301 5171121L01 VCO BUFFER IC
U4401 5115678H01/
††
51012101001
LDMOS DRIVER IC
U4402 5114005A01 OP AMP
U4501 5185765B26 IC PWR CTRL IN MOS20
U4502 5115022H01 IC TEMPERATURE SENSOR
VR4471 4813977M11 DIODE
Y3101 4802245J84 XTAL44.395MHZ3RD OT SMD
Y3102 9186145B02 CER.DISCRIMANATOR
Circuit
Ref
Motorola
Part No.
Description
Y4262 4816142H01 REFERENCE OSCILLATOR
8471224L03 WARIS MOBILE U2 25W PCB
Circuit
Ref
Motorola
Part No.
Description
