Section 1: 3-4 Recommended Test Equipment

6881091C63-F

S1339_ RF millivoltmeter 100 mV – 3 VRF.

10 kHz – 1.2 GHz

RF level measurements

S1348_ Programmable DC power

supply

0 – 20 VDC, 0 – 5 A, current limited Bench supply for 7.5 V

Table 3-3 Wattmeter Plug-In Elements

Power 25–60 MHz 50–125 MHz 100–250 MHx 200–500 MHz 400-–1000 MHz

5 W – 01-80305F21 01-80305F29 01-80305F38 01-80305F46

10 W – 01-80305F22 01-80305F30 01-80305F39 01-80305F47

25 W 01-80305F15 01-80305F23 01-80305F31 01-80305F40 01-80305F48

50 W 01-80305F16 01-80305F24 01-80305F32 01-80305F41 01-80305F49

100 W 01-80305F17 01-80305F25 01-80305F33 01-80305F42 01-80305F50

250 W 01-80305F18 01-80305F26 01-80305F34 01-80305F43 01-80305F51

500 W 01-80305F19 01-80305F27 01-80305F35 01-80305F44 01-80305F52

1000 W 01-80305F20 01-80305F28 01-80305F36 01-80305F45 01-80305F53

Motorola Part

Number

Description Characteristics Application

Product Safety and RF Exposure Compliance2
Foreword2
Manual Revisions2
Computer Software Copyrights2
Document Copyrights2
Disclaimer2
Trademarks2
Document History3
Section 1: Service Maintainability7
- Introduction9
- Maintenance13
- Service Aids23
  - 1.0 Recommended Service Tools23
  - 2.0 Recommended Test Equipment25
Section 2: Control Head Service Information27
- Overview29
- Theory of Operation31
- Troubleshooting Charts39
  - 1.0 Control Head CDM750 / PRO3100 Troubleshooting Flow Charts39
  - 2.0 Control Head CDM1250 / PRO5100 / CDM1550 Series / PRO7100 Troubleshooting Flow Charts41
- Control Head PCBs, Schematics, and Parts Lists45
Section 3: Controller Service Maintainability57
- Theory of Operation59
  - 1.0 Controller Circuits59
  - 2.0 Controller Board Audio and Signaling Circuits68
- Troubleshooting Charts79
  - 1.0 Troubleshooting Flow Chart for Controller79
- Controller Schematics and Parts Lists81
Section 4: VHF (136–174 MHz) 1–25 W Service Information147
- Model Charts and Technical Specifications149
  - 1.0 VHF (136–174 MHz) 1–25W Model Charts149
  - 2.0 Technical Specifications150
- Theory of Operation153
- Troubleshooting Charts161
- VHF (136–174 MHz) 1–25 W PCBs, Schematics, and Parts Lists169
Section 5: UHF Band 1 (403–470 MHz) 1–25 W Service Information227
- Model Charts and Technical Specifications229
  - 1.0 UHF Band 1 (403–470 MHz) 1–25 W Model Charts229
  - 2.0 Technical Specifications230
- Theory of Operation233
- Troubleshooting Charts243
- UHF Band 1 (403–470 MHz) 1–25 W PCBs, Schematics, and Parts Lists251
Section 6: UHF Band 2 (450–512/527 MHz) 1–25W Service Information291
- Model Charts and Technical Specifications293
  - 1.0 UHF Band 2 (450–512/527 MHz) 1–25 W Model Charts293
  - 2.0 Technical Specifications294
- Theory of Operation297
- Troubleshooting Charts307
- UHF Band 2 (450–512/527 MHz) 1–25 W PCBs, Schematics, and Parts Lists315
  - 1.0 Allocation of Schematics and Circuit Boards315
  - 2.0 UHF Band 2 (450–512/527 MHz) 1–25 W PCB 8485671Z03, Schematics, and Parts Lists317
    - UHF B2 1–25 W PCB 8485671Z03 Parts List†324
Section 7: Low Band Service Information329
- Model Charts and Technical Specifications331
- Theory of Operation337
- Troubleshooting Charts347
- Low Band PCBs, Schematics, and Parts Lists353
Section 8: VHF (136–174 MHz) 25–45 W Bipolar Service Information453
- Model Charts and Technical Specifications455
  - 1.0 VHF (136–174 MHz) 25–45 W Bipolar Model Charts455
  - 2.0 Technical Specifications456
- Theory of Operation459
- Troubleshooting Charts467
- VHF (136–174 MHz) 25–45 W Bipolar PCBs, Schematics, and Parts Lists473
Section 9: UHF Band 1 (403–470 MHz) 25–40 W Bipolar Service Information491
- Model Charts and Technical Specifications493
  - 1.0 UHF Band 1 (403–470 MHz) 25–40 W Bipolar Model Charts493
  - 2.0 Technical Specifications494
- Theory of Operation497
- Troubleshooting Charts505
- UHF Band 1 (403–470 MHz) 25–40 W Bipolar PCBs, Schematics, and Parts Lists511
  - 1.0 Allocation of Schematics and Circuit Boards511
  - 2.0 UHF Band 1 (403–470 MHz) 25–40 W Bipolar PCB 8480643Z06, Schematics, and Parts Lists513
    - UHF B1 25–40 W PCB 8480643Z06 Parts List†520
Section 10: UHF Band 2 (450–512/520 MHz) 25–40W Bipolar Service Information525
- Model Charts and Technical Specifications527
  - 1.0 UHF Band 2 (450–512/520 MHz) 25–40 W Bipolar Model Charts527
  - 2.0 Technical Specifications528
- Theory of Operation531
- Troubleshooting Charts539
- UHF Band 2 (450–512/520 MHz) 25–40 W Bipolar PCBs, Schematics, and Parts Lists545
  - 1.0 Allocation of Schematics and Circuit Boards545
  - 2.0 UHF Band 2 (450–512/520 MHz) 25–40 W Bipolar PCB 8480645Z04, Schematics, and Parts Lists547
    - UHF B2 25–40 W PCB 8480645Z04 Parts List†554
Section 11: VHF (136–174 MHz) 25–45 W LDMOS Service Information559
- Model Charts and Technical Specifications561
  - 1.0 VHF (136–174 MHz) 25–45 W LDMOS Model Charts561
  - 2.0 Technical Specifications562
- Theory of Operation565
- Troubleshooting Charts573
- VHF (136–174 MHz) 25–45 W LDMOS PCBs, Schematics, and Parts Lists581
Section 12: UHF Band 1 (403–470 MHz) 25–40 W LDMOS Service Information603
- Model Charts and Technical Specifications605
  - 1.0 UHF Band 1 (403–470 MHz) 25–40 W LDMOS Model Charts605
  - 2.0 Technical Specifications606
- Theory of Operation609
- Troubleshooting Charts617
- UHF Band 1 (403–470 MHz) 25–40 W LDMOS PCBs, Schematics, and Parts Lists625
Section 13: UHF Band 2 (450–512/520 MHz) 25–40 W LDMOS Service Information649
- Model Charts and Technical Specifications651
  - 1.0 UHF Band 2 (450–512/520 MHz) 25–40 W LDMOS Model Charts651
  - 2.0 Technical Specifications652
- Theory of Operation655
- Troubleshooting Charts665
- UHF Band 2 (450–512/520 MHz) 25–40 W LDMOS PCBs, Schematics, and Parts Lists671
