Motorola Pro3100 Detailed Service Manual

UHF Band 1 (403–470 MHz) 1–25 W PCB 8485670Z03, Schematics, and Parts Lists Section 5: 4-27
6881091C63-F
C4504 2113741F49 10nF
C4505 2311049A07 1uF
C4506 2113741F33 2200pF
C4507 2113740F51 100pF
C4508 2113740F51 100pF
C4510 2113740F51 100pF
CR4301 4805649Q13 DIODE, VARACTOR
CR4302 4862824C01 DIODE, VARACTOR
CR4303 4862824C01 DIODE, VARACTOR
CR4311 4802245J22 DIODE, VARACTOR
CR4321 4862824C01 DIODE, VARACTOR
D3101 4880154K03 DIODE DUAL SCHOTTKY
D4001 4862824C01 DIODE, VARACTOR
D4002 4862824C01 DIODE, VARACTOR
D4003 4880154K03 DIODE DUAL SCHOTTKY
D4004 4862824C01 DIODE, VARACTOR
D4005 4862824C01 DIODE, VARACTOR
D4006 4880142L01 DIODE
D4007 4813833C02 DIODE, DUAL 70V
D4051 4886143B01 DIODE, MIXER
D4201 4802233J09 DIODE, TRIPLE
D4221 4813825A05 DIODE
D4401 4813833C02 DIODE, DUAL 70V
D4451 4813825A05 DIODE
D4471 4802482J02 DIODE
D4472 4802482J02 DIODE
FL3101 9180112R16 2 POLE 44.85 MHZ CRYSTAL
FILTER
FL3102 9180112R16 2 POLE 44.85 MHZ CRYSTAL
FILTER
FL3111 9180469V03 6 ELEMENT CER FILTER,
455KHz
FL3112 9180469V06 6 ELEMENT CER FILTER,
455KHz
FL3114 9180468V06 4 ELEMENT CER FILTER,
455KHz
FL3115 9180469V04 6 ELEMENT CER FILTER,
455KHz
J0401 0902636Y02 FLEX CONNECTOR
J0451 0902636Y01 FLEX CONNECTOR
J0501 0986105B01 ACCESSORY CONNECTOR
J0551 0905505Y04 FLEX CONNECTOR
J0552 0905505Y03 FLEX CONNECTOR
J0601 0986165B01 DC POWER CONNECTOR
J4401 0986166B02 RF CONNECTOR (MINI-UHF)
L3101 2462587T25 620nH
L3111 2462587T25 620nH
L3112 2462587T25 620nH
L3124 2462587N68
NU
1uH 3rd overtone crystal
fundamental crystal
L4003 2462587T23 470nH
Circuit
Ref
Motorola
Part No.
Description
L4006 2462587V24 15nH
L4008 2462587T23 470nH
L4051 2462587T17 150nH
L4053 2462587N46 27nH
L4054 2462587N43 15nH
L4201 2462587Q42 390nH
L4221 2462587P25 12000nH
L4231 2462587Q20 2200nH
L4301 2462587T22 390nH
L4302 2462587T22 390nH
L4303 2460593C01 RESONATOR
L4304 2462587T22 390nH
L4305 2462587T22 390nH
L4311 2462587T22 390nH
L4312 2460593C01 RESONATOR
L4313 2462587T22 390nH
L4331 2462587T09 33nH
L4333 2462587T22 390nH
L4361 2462587T09 33nH
L4362 2462587T09 33nH
L4371 2462587T13 68nH
L4401 2460591B04 11.03nH
L4402 2484657R01 Ferrite Bead
L4403 2462587N50 56nH
L4411 2462587N44 18nH
L4421 2484657R01 Ferrite Bead
L4422 2460591A01 4.22nH
L4436 2484657R01 Ferrite Bead
L4437 2460592A01 17nH
L4471 2462587T22 390nH
L4472 2460592A01 17nH
L4491 2460592A01 17nH
L4493 2460592A01 17nH
M3421 2686201B01 HEAT SPREADER
Q3101 4813827A07 NPN
Q3102 4813827A07 NPN
Q3141 4880214G02 NPN
Q3151 4880048M01 NPN
Q3152 4880048M01 NPN
Q4002 4813824A17 PNP
Q4003 4813827A07 NPN
Q4004 4805921T02 TRANSISTOR DUAL DIGITAL
NPN/PNP
Q4221 4880048M01 NPN
Q4301 4805218N63 DIODE DUAL SCHOTTKY
Q4332 4813827A07 NPN
Q4333 4802245J50 TRANSISTOR DUAL NPN/PNP
Q4411 4805921T02 TRANSISTOR DUAL DIGITAL
NPN/PNP
Q4421 4886212B01 MRF1518
Q4422 4880048M01 NPN
Circuit
Ref
Motorola
Part No.
Description
Q4441 4886163B01 MRF1535
Q4442 4880048M01 NPN
Q4471 4880048M01 NPN
Q4472 4805128M27 PNP
R3101 0662057A75 12K Ohm
R3102 0662057A01 10 Ohm
R3105 0662057A25 100 Ohm
R3106 0662057A83 27K Ohm
R3107 0662057A69 6800 Ohm
R3108 0662057A44 620 Ohm
R3111 0662057A75 12K Ohm
R3112 0662057A01 10 Ohm
R3113 0662057A37 330 Ohm
R3115 0662057A39 390 Ohm
R3116 0662057A37 330 Ohm
R3117 0662057A83 27K Ohm
R3118 0662057A69 6800 Ohm
R3123 NU
0662057B47
3rd overtone crystal
0 fundamental crystal
R3124 0662057A49
NU
1K 3rd overtone crystal
fundamental crystal
R3130 0662057A18 51 Ohm
R3132 0662057A77 15K Ohm
R3133 0662057A71 8200 Ohm
R3134 0662057A73 10K Ohm
R3135 0662057A51 1200 Ohm
R3141 0662057A39 390 Ohm
R3142 0662057A55 1800 Ohm
R3144 0662057A58 2400 Ohm
R3145 0662057A61 3300 Ohm
R3146 0662057A45 680 Ohm
R3147 0662057A75 12K Ohm
R3148 0662057B47 0 Ohm
R3151 0662057A73 10K Ohm
R3152 0662057A73 10K Ohm
R3153 0662057A73 10K Ohm
R3154 0662057A73 10K Ohm
R4001 0662057A97 100K Ohm
R4002 0662057A37 330 Ohm
R4003 0662057A63 3900 Ohm
R4004 0662057A59 2700 Ohm
R4005 0662057A73 10K Ohm
R4007 0662057A25 100 Ohm
R4012 0662057A97 100K Ohm
R4013 0662057A35 270 Ohm
R4014 0662057A01 10 Ohm
R4016 0662057A61 3300 Ohm
R4018 0662057A61 3300 Ohm
R4022 0662057B47 0 Ohm
R4051 0662057A18 51 Ohm
R4052 0662057B47 0 Ohm
Circuit
Ref
Motorola
Part No.
Description
R4060 0662057B10 330K Ohm
R4061 0662057A73 10K Ohm
R4062 0662057A53 1500 Ohm
R4063 0662057A39 390 Ohm
R4064 0662057B47 0 Ohm
R4068 0662057A53 1500 Ohm
R4069 0662057A49 1000 Ohm
R4070 0662057A39 390 Ohm
R4071 0662057A73 10K Ohm
R4072 0662057A73 10K Ohm
R4201 0662057A29 150 Ohm
R4203 0662057A17 47 Ohm
R4204 0662057A17 47 Ohm
R4211 0662057B47 0 Ohm
R4221 0662057A29 150 Ohm
R4222 0662057A42 510 Ohm
R4223 0662057A21 68 Ohm
R4224 0662057A89 47K Ohm
R4225 0662057A89 47K Ohm
R4228 0662057A73 10K Ohm
R4241 0662057A33 220 Ohm
R4251 0662057A87 39K Ohm
R4252 0662057A84 30K Ohm
R4261 0662057A89 47K Ohm
R4263 0662057A25 100 Ohm
R4301 0662057A67 5600 Ohm
R4302 0662057A73 10K Ohm
R4303 0662057A12 30 Ohm
R4304 0662057A31 180 Ohm
R4305 0662057A01 10 Ohm
R4311 0662057A70 7500 Ohm
R4312 0662057A67 5600 Ohm
R4313 0662057A12 30 Ohm
R4314 0662057A35 270 Ohm
R4315 0662057B47 0 Ohm
R4321 0662057A91 56K Ohm
R4322 0662057A73 10K Ohm
R4323 0662057A97 100K Ohm
R4331 0662057A09 22 Ohm
R4341 0662057B47 0 Ohm
R4342 0662057A57 2200 Ohm
R4343 0662057A49 1000 Ohm
R4344 0662057A01 10 Ohm
R4346 0662057A73 10K Ohm
R4347 0662057B47 0 Ohm
R4360 0662057A35 270 Ohm
R4361 0662057A31 180 Ohm
R4362 0662057A01 10 Ohm
R4363 0662057A49 1000 Ohm
R4381 0662057A41 470 Ohm
R4400 0662057A43 560 Ohm
Circuit
Ref
Motorola
Part No.
Description
