UHF Band 1 (403–470 MHz) 1–25 W PCB 8471224L04, Schematics, and Parts Lists Section 5: 4-39
6881091C63-F
R3130 0613952H42 CER CHIP RES 51.0 OHM 5%
0603
R3132 0613952J05 CER CHIP RES 15K OHM 5%
0603
R3133 0613952H89 CER CHIP RES 4700 OHM 5%
0603
R3134 0613952H95 CER CHIP RES 8200 OHM 5 0603
R3135 0613952H75 CER CHIP RES 1200 OHM 5 0603
R3141 0613952H63 CER CHIP RES 390 OHM 5 0603
R3142 0613952H79 CER CHIP RES 1800 OHM 5%
0603
R3144 0613952H82 CER CHIP RES 2400 OHM 5 0603
R3145 0613952H85 CER CHIP RES 3300 OHM 5%
0603
R3146 0613952H69 CER CHIP RES 680 OHM 5 0603
R3147 0613952J03 CER CHIP RES 12K OHM 5%
0603
R3148 2113944C45 CAP CER CHP 100.0PF 50V 5%
R3151 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3152 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3153 0613952J01 CER CHIP RES 10K OHM 5%
0603
R3154 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4001 0613952J25 CER CHIP RES 100K OHM 5%
0603
R4002 0613952H61 CER CHIP RES 330 OHM 5 0603
R4003 0613952H87 CER CHIP RES 3900 OHM 5%
0603
R4004 0613952H83 CER CHIP RES 2700 OHM 5%
0603
R4005 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4007 0613952H49 CER CHIP RES 100 OHM 5%
0603
R4012 0613952J25 CER CHIP RES 100K OHM 5%
0603
R4013 0613952H59 CER CHIP RES 270 OHM 5%
0603
R4014 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R4016 0613952H85 CER CHIP RES 3300 OHM 5%
0603
R4018 0613952H85 CER CHIP RES 3300 OHM 5%
0603
R4022 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R4051 0613952H42 CER CHIP RES 51.0 OHM 5%
0603
R4052 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R4060 0613952J37 CER CHIP RES 330K OHM 5%
0603
R4061 0613952J01 CER CHIP RES 10K OHM 5%
0603
Circuit
Ref
Motorola
Part No.
Description
R4062 0613952H77 CER CHIP RES 1500 OHM 5%
0603
R4063 0613952H63 CER CHIP RES 390 OHM 5 0603
R4064 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R4068 0613952H77 CER CHIP RES 1500 OHM 5%
0603
R4069 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R4070 0613952H63 CER CHIP RES 390 OHM 5 0603
R4071 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4072 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4201 0613952H53 CER CHIP RES 150 OHM 5%
0603
R4203 0613952H41 CER CHIP RES 47.0 OHM 5 0603
R4204 0613952H41 CER CHIP RES 47.0 OHM 5 0603
R4211 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R4221 0613952H53 CER CHIP RES 150 OHM 5%
0603
R4222 0613952H66 CER CHIP RES 510 OHM 5 0603
R4223 0613952H45 CER CHIP RES 68.0 OHM 5%
0603
R4224 0613952J17 CER CHIP RES 47K OHM 5%
0603
R4225 0613952J17 CER CHIP RES 47K OHM 5%
0603
R4228 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4241 0613952H57 CER CHIP RES 220 OHM 5%
0603
R4251 0613952J15 CER CHIP RES 39K OHM 5%
0603
R4252 0613952J12 CER CHIP RES 30K OHM 5 0603
R4261 0613952J17 CER CHIP RES 47K OHM 5%
0603
R4263 0613952H49 CER CHIP RES 100 OHM 5%
0603
R4301 0613952H91 CER CHIP RES 5600 OHM 5 0603
R4302 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4303 0613952H36 CER CHIP RES 30.0 OHM 5 0603
R4304 0613952H55 CER CHIP RES 180 OHM 5%
0603
R4305 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R4311 0613952H94 CER CHIP RES 7500 OHM 5 0603
R4312 0613952H91 CER CHIP RES 5600 OHM 5 0603
R4313 0613952H36 CER CHIP RES 30.0 OHM 5 0603
R4314 0613952H59 CER CHIP RES 270 OHM 5%
0603
R4315 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R4321 0613952J19 CER CHIP RES 56K OHM 5%
0603
R4322 0613952J01 CER CHIP RES 10K OHM 5%
0603
Circuit
Ref
Motorola
Part No.
Description
R4323 0613952J25 CER CHIP RES 100K OHM 5%
0603
R4331 0613952H33 CER CHIP RES 22.0 OHM 5%
0603
R4341 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R4342 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R4343 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R4344 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R4346 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4347 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R4360 0613952H59 CER CHIP RES 270 OHM 5%
0603
R4361 0613952H55 CER CHIP RES 180 OHM 5%
0603
R4362 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R4363 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R4381 0613952H65 CER CHIP RES 470 OHM 5%
0603
R4400 0613952H67 CER CHIP RES 560 OHM 5 0603
R4401 0613952H60 CER CHIP RES 300 OHM 5 0603
R4402 0613952H29 CER CHIP RES 15.0 OHM 5 0603
R4403 0613952H60 CER CHIP RES 300 OHM 5 0603
R4404 0613952J17 CER CHIP RES 47K OHM 5%
0603
R4406 0613952J25 CER CHIP RES 100K OHM 5%
0603
R4412 0613952H93 CER CHIP RES 6800 OHM 5%
0603
R4413 0613952H85 CER CHIP RES 3300 OHM 5%
0603
R4415 0613952H42 CER CHIP RES 51.0 OHM 5%
0603
R4416 0613952H42 CER CHIP RES 51.0 OHM 5%
0603
R4418 0613952H83 CER CHIP RES 2700 OHM 5%
0603
R4421 0613952J29 CER CHIP RES 150K OHM 5%
0603
R4422 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R4423 0613952J15 CER CHIP RES 39K OHM 5%
0603
R4424 0613958H11 CER CHIP RES 2.7 OHM 5% 0805
R4425 0613958H11 CER CHIP RES 2.7 OHM 5% 0805
R4426 0613958H11 CER CHIP RES 2.7 OHM 5% 0805
R4427 0613958H11 CER CHIP RES 2.7 OHM 5% 0805
R4428 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4429 0613952H67 CER CHIP RES 560 OHM 5 0603
R4431 0613959Y42 CER CHIP RES OHM 5% 2512
Circuit
Ref
Motorola
Part No.
Description
R4441 0613952J15 CER CHIP RES 39K OHM 5%
0603
R4442 0613952H81 CER CHIP RES 2200 OHM 5%
0603
R4443 0613952J15 CER CHIP RES 39K OHM 5%
0603
R4445 0613952H82 CER CHIP RES 2400 OHM 5 0603
R4446 0613952G67 CER CHIP RES 0.0 +/-0.050 OHM
R4452 0613952J03 CER CHIP RES 12K OHM 5%
0603
R4454 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4455 0613952J25 CER CHIP RES 100K OHM 5%
0603
R4457 0613959Y51 CER CHIP RES OHM 5% 2512
R4458 0613952H65 CER CHIP RES 470 OHM 5%
0603
R4471 0613952H65 CER CHIP RES 470 OHM 5%
0603
R4473 0613959Y42 CER CHIP RES OHM 5% 2512
R4474 0613959Y42 CER CHIP RES OHM 5% 2512
R4475 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4491 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4501 0613952H93 CER CHIP RES 6800 OHM 5%
0603
R4502 0613952J11 CER CHIP RES 27K OHM 5%
0603
R4504 0613952J01 CER CHIP RES 10K OHM 5%
0603
R4505 0613952J36 CER CHIP RES 300K OHM 5 0603
R4507 0613952J08 CER CHIP RES 20K OHM 5 0603
R4508 0613952J25 CER CHIP RES 100K OHM 5%
0603
R4509 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R4511 0613958H17 CER CHIP RES 4.7 OHM 5% 0805
R4592 2415429H47 CHIP INDUCTOR
SH4301 2602641Y03 SHIELD, ARIANE VCO
SH4302 2602641Y03 SHIELD, ARIANE VCO
T4051 2516149H01 XFMR JEDI MIXER 4:1
T4052 2516148H01 XMFR MIXER 5:1
U3101 5115281H01 FM IF IC SA616 FROM PHILIPS
U3111 5185291Y01 IC,SOIC14
U3115 5185291Y01 IC,SOIC14
U4201 5185177Y01 IC TESTED AT25016 48 PIN W18
U4211 5115026H01 MAX SUPPLY VOL 16V
U4301 5171121L01 CUSTOM LOW VOLTAGE VCO
BUFFER IC
U4401
††
51012101001
VHF/UHF/800/900 MHZ LDMOS
DRIVER IC
U4402 5114005A01 IC,OP AMP,2PER
PKG,GP,SM,SO-8,PB-FREE
U4501 5185765B26 IC PWR CTRL IN MOS20
U4502 5115022H01 IC TEMPERATURE SENSOR
Circuit
Ref
Motorola
Part No.
Description
