Motorola Pro3100 Detailed Service Manual

UHF Band 2 (450–512/527 MHz) 1–25 W PCB 8485671Z03, Schematics, and Parts Lists Section 6: 4-11
6881091C63-F
C5032 2113740F25 8.2pF
C5033 2113740F51 100pF
C5034 2113740F51 100pF
C5052 2113740F49 82pF
C5053 2113740F23 6.8pF
C5054 2113740F32 16pF
C5061 2113740F63 330pF
C5062 2113743E20 0.1uF
C5064 2113743E20 0.1uF
C5065 2113740F51 100pF
C5067 2113741F37 3300pF
C5068 2113740F51 100pF
C5069 2113741F49 10nF
C5201 2113740F51 100pF
C5202 2113741F49 10nF
C5203 2113741F49 10nF
C5204 2113740F51 100pF
C5205 2113741F49 10nF
C5206 2311049J25 10uF
C5208 2113743E20 0.1uF
C5209 2113743E20 0.1uF
C5210 2104993J02 2.2uF
C5211 2113743E20 0.1uF
C5213 2311049A09 2.2uF
C5214 2311049A09 2.2uF
C5215 2311049A09 2.2uF
C5217 2113741F49 10nF
C5221 2109720D01 0.01uF
C5222 2109720D14 0.1uF
C5224 0882422W23 1uF
C5225 2113741F18 510pF
C5227 2113740F27 10pF
C5230 2104993J02 2.2uF
C5231 2113741F49 10nF
C5232 2113741F49 10nF
C5233 2104993J02 2.2uF
C5234 2113741F49 10nF
C5235 2113741F49 10nF
C5236 2113743E12 0.047uF
C5242 2113740F51 100pF
C5243 2113740F51 100pF
C5244 2113740F51 100pF
C5245 2113740F51 100pF
C5246 2113740F51 100pF
C5251 2113743E20 0.1uF
C5252 2113741F25 1000pF
C5253 2311049A56 4.7uF
C5254 2113743E20 0.1uF
C5255 2113740F51 100pF
C5263 2113743E20 0.1uF
C5287 2113740F51 100pF
Circuit
Ref
Motorola
Part No.
Description
C5289 2113743E20 0.1uF
C5301 2113740F51 100pF
C5302 2113740L09 4.3pF
C5303 2113740L09 4.3pF
C5304 2113740L12 5.6pF
C5306 2113740L01 2pF
C5307 2113740F51 100pF
C5308 2113743E20 0.1uF
C5309 2113740F51 100pF
C5311 2113740F51 100pF
C5312 2113740F33 18pF
C5314 2113740L01 2pF
C5315 2113740F51 100pF
C5316 2109720D14 0.1uF
C5318 2113743E20 0.1uF
C5321 2113740F03 1pF
C5324 2113740F07 1.5pF
C5325 2311049A56 4.7uF
C5331 2113740L12 5.6pF
C5335 2113740F51 100pF
C5336 2113743E07 0.022uF
C5337 2113740F44 51pF
C5338 2113740F44 51pF
C5351 2113740F51 100pF
C5352 2113743E20 0.1uF
C5353 2113743E20 0.1uF
C5354 2104993J02 2.2uF
C5355 2104993J02 2.2uF
C5361 2113740F51 100pF
C5364 0662057B47 0
C5371 2113743E20 0.1uF
C5381 2113743E20 0.1uF
C5400 2113740F57 180pF
C5401 2113740F51 100pF
C5402 2113743E07 0.022uF
C5403 2113740F23 6.8pF
C5404 2113740F51 100pF
C5405 2113740F51 100pF
C5406 2113740F51 100pF
C5407 2113740F51 100pF
C5411 2113743E07 0.022uF
C5412 2113740F51 100pF
C5413 2113743E07 0.022uF
C5414 2113740F51 100pF
C5415 2113743E07 0.022uF
C5416 2113740F51 100pF
C5417 2113740F51 100pF
C5420 2113740F36 24pF
C5421 2113741A57 0.033uF
C5422 2113740A55 100pF
C5423 2311049A08 1uF
Circuit
Ref
Motorola
Part No.
Description
C5424 2113740F27 10pF
C5425 2113743E20 0.1uF
C5426 2113740F51 100pF
C5427 2113741F37 3300pF
C5428 2113741F33 2200pF
C5431 2111078B25 27pF
C5432 2111078B29 33pF
C5434 2113743E20 0.1uF
C5435 2113740A55 100pF
C5436 2311049A45 10uF
C5437 2113741A57 0.033uF
C5438 2311049A08 1uF
C5439 2111078B42 100pF
C5440 2113741F25 1000pF
C5441 2111078B05 4.7pF
C5442 2111078B19 16pF
C5448 2111078B29 33pF
C5449 2111078B29 33pF
C5451 2113741F25 1000pF
C5452 2113740F28 11pF
C5453 2113740F51 100pF
C5454 2111078B01 3.3pF
C5455 2111078B19 16pF
C5457 2111078B34 47pF
C5458 2111078B35 51pF
C5461 2111078B11 8.2pF
C5471 2113740F51 100pF
C5472 2111078B27 30pF
C5473 2111078B27 30pF
C5474 2113740F18 4.3pF
C5475 2113740F10 2pF
C5481 2113741A57 0.033uF
C5482 2113740F38 30pF
C5483 2113741A57 0.033uF
C5491 2111078B09 6.8pF
C5492 2111078B42 100pF
C5496 2111078B05 4.7pF
C5497 2111078B01 3.3pF
C5498 2111078B01 3.3pF
C5501 2113741F33 2200pF
C5502 2113741F33 2200pF
C5503 2113741F33 2200pF
C5504 2113741F46 7500pF
C5505 2311049A07 1uF
C5506 2113741F33 2200pF
C5507 2113740F51 100pF
C5508 2113740F51 100pF
C5510 2113740F51 100pF
CR5301 4805649Q13 DIODE VCTR ISV 228
CR5302 4862824C01 DIODE VARACTOR
CR5303 4862824C01 DIODE VARACTOR
Circuit
Ref
Motorola
Part No.
Description
CR5311 4862824C01 DIODE VARACTOR
CR5321 4802245J22 DIODE, VARACTOR
D0101 4813825A05 DIODE
D0151 4813833C02 DIODE, DUAL 70V
D0179 4813833C02 DIODE, DUAL 70V
D0301 4802245J47 DIODE, SCHOTTKY
D0621 4813833C02 DIODE, DUAL 70V
D0651 4813833C02 DIODE, DUAL 70V
D0660 4813833C02 DIODE, DUAL 70V
D0661 4813833C02 DIODE, DUAL 70V
D3101 4880154K03 DIODE DUAL SCHOTTKY
D5001 4862824C01 DIODE VARACTOR
D5002 4862824C01 DIODE VARACTOR
D5003 4880154K03 DIODE DUAL SCHOTTKY
D5004 4862824C01 DIODE VARACTOR
D5005 4862824C01 DIODE VARACTOR
D5006 4880142L01 DIODE
D5007 4813833C02 DIODE, DUAL 70V
D5051 4886143B01 DIODE, MIXER
D5201 4802233J09 DIODE, TRIPLE
D5221 4813825A05 DIODE
D5401 4813833C02 DIODE, DUAL 70V
D5451 4813825A05 DIODE
D5471 4802482J02 DIODE, SMD PIN
D5472 4802482J02 DIODE, SMD PIN
E0271 2484657R01 FERRITE BEAD
E0272 2484657R01 FERRITE BEAD
E0631 2484657R01 FERRITE BEAD
F0401 6580542Z01 FUSE 3A
FL3101 9180112R16 2 POLE 44.85 MHZ CRYSTAL
FILTER
FL3102 9180112R16 2 POLE 44.85 MHZ CRYSTAL
FILTER
FL3111 9180469V03 CERAMIC FILTER, 455KHz
FL3112 9180469V06 CERAMIC FILTER, 455KHz
FL3114 9180468V06 CERAMIC FILTER, 455KHz
FL3115 9180469V04 CERAMIC FILTER, 455KHz
J0401 0902636Y02 FLEX CONNECTOR
J0451 0902636Y01 FLEX CONNECTOR
J0501 0986105B01 ACCESSORY CONNECTOR
J0551 0905505Y04 FLEX CONNECTOR
J0552 0905505Y03 FLEX CONNECTOR
J0601 0986165B01 DC POWER CONNECTOR
J5401 0986166B02 RF CONNECTOR (MINI-UHF)
L3101 2462587T25 620nH
L3111 2462587T25 620nH
L3112 2462587T25 620nH
L3124 2462587N68
NU
1uH 3rd overtone crystal
fundamental crystal
L5003 2462587T20 270nH
L5006 2462587V24 15nH
Circuit
Ref
Motorola
Part No.
Description
