Motorola Pro3100 Detailed Service Manual

Low Band Range 1 (29.7–36 MHz) PCBs, Schematics, and Parts Lists Section 7: 4-25
6881091C63-F
Q0177 4880048M01 DTC144EKA
Q0181 4880048M01 DTC144EKA
Q0183 4880048M01 DTC144EKA
Q0185 4880048M01 DTC144EKA
Q0271 4880214G02 MMBT3904
Q0641 4880048M01 DTC144EKA
Q0661 4805921T02 FMC2A
Q0662 4880214G02 MMBT3904
Q0663 4880048M01 DTC144EKA
Q0681 4880052M01 RXT-A28
Q1001 4880182D44 MMBR951
Q1002 4813824A17 MMBT3906
Q1003 4813824A17 MMBT3906
Q1101 4813827A07 MMBR941
Q1102 4813823A05 MMBFU310L
Q1103 4813823A05 MMBFU310L
Q1104 4813823A05 MMBFU310L
Q1105 4880048M01 DTC144EKA
Q1106 4813827A07 MMBR941
Q1107 4880214G02 MMBT3904
Q1201 4813824A17 MMBT3906
Q1202 4880182D44 MMBR951
Q1303 4884235R02 MMBFU310
Q1304 4880182D44 MMBR951
Q1305 4880182D44 MMBR951
Q1306 4884235R02 MMBFU310
Q1307 4880182D44 MMBR951
Q1308 4880182D44 MMBR951
Q1401 4886212B01 MRF1518
Q1402 4886136B01 MRF1550
Q1403 4886136B01 MRF1550
Q1404 NOTPLACED -
Q1501 4880141L03 BCW68G
Q1502 4880214G02 MMBT3904
Q1503 4880214G02 MMBT3904
Q1504 4880214G02 MMBT3904
Q1505 4813824A17 MMBT3906
Q1506 4880214G02 MMBT3904
Q1601 4813824A17 MMBT3906
Q1602 4880048M01 DTC144EKA
Q1603 4880214G02 MMBT3904
Q1604 4880214G02 MMBT3904
Q1605 4880214G02 MMBT3904
Q1606 4813824A17 MMBT3906
Q1607 4880214G02 MMBT3904
Q1609 4813824A17 MMBT3906
Q1610 4805585Q17 NE25139
R0101 0662057A73 RES, 10K
R0102 0662057A65 RES, 4.7K
R0103 0662057A01 RES, 10
R0104 0662057A73 RES, 10K
Circuit
Ref
Motorola
Part No.
Description
R0105 0662057A97 RES, 100K
R0106 NOTPLACED -
R0107 NOTPLACED -
R0108 0662057A57 RES, 2.2K
R0110 NOTPLACED -
R0111 0662057B47 RES, 0
R0112 NOTPLACED -
R0113 0662057A73 RES, 10K
R0114 0662057A73 RES, 10K
R0115 0662057A73 RES, 10K
R0116 NOTPLACED -
R0117 0662057A63 RES, 3.9K
R0121 0662057A97 RES, 100K
R0131 0662057B46 RES, 10MEG
R0132 0662057B10 RES, 330K
R0151 0662057A82 RES, 24K
R0152 0662057A82 RES, 24K
R0170 0662057A73 RES, 10K
R0171 0662057A65 RES, 4.7K
R0172 0662057A73 RES, 10K
R0173 0662057A65 RES, 4.7K
R0174 0662057A73 RES, 10K
R0175 0662057A73 RES, 10K
R0176 0662057A84 RES, 30K
R0177 0662057A65 RES, 4.7K
R0178 0662057A89 RES, 47K
R0179 0662057A89 RES, 47K
R0181 0662057A65 RES, 4.7K
R0182 0662057A89 RES, 47K
R0183 0662057A65 RES, 4.7K
R0184 0662057A89 RES, 47K
R0185 0662057A65 RES, 4.7K
R0186 0662057A89 RES, 47K
R0201 0662057A25 RES, 100
R0202 0662057A43 RES, 560
R0203 0662057A25 RES, 100
R0204 0662057A43 RES, 560
R0205 0662057A73 RES, 10K
R0206 0662057A73 RES, 10K
R0207 0662057A57 RES, 2.2K
R0208 0662057A57 RES, 2.2K
R0211 0660076E70 RES, 7.5K
R0212 0660076E70 RES, 7.5K
R0220 NOTPLACED -
R0221 0662057A82 RES, 24K
R0222 0662057A82 RES, 24K
R0223 0662057A84 RES, 30K
R0224 0662057A71 RES, 8.2K
R0225 NOTPLACED -
R0226 NOTPLACED -
R0227 NOTPLACED -
Circuit
Ref
Motorola
Part No.
Description
R0228 0662057B47 RES, 0
R0229 0662057A01 RES, 10
R0241 0662057A89 RES, 47K
R0242 0662057B47 RES, 0
R0251 0662057A89 RES, 47K
R0252 0662057A91 RES, 56K
R0253 0662057A97 RES, 100K
R0254 0662057A73 RES, 10K
R0255 0662057A73 RES, 10K
R0256 0662057A97 RES, 100K
R0257 0662057A57 RES, 2.2K
R0261 0662057A73 RES, 10K
R0262 0662057B08 RES, 270K
R0265 0662057A82 RES, 24K
R0266 NOTPLACED -
R0267 0662057A89 RES, 47K
R0268 0662057A73 RES, 10K
R0269 0662057A41 RES, 470
R0273 0662057A82 RES, 24K
R0274 NOTPLACED -
R0275 0662057A73 RES, 10K
R0276 0662057A77 RES, 15K
R0323 NOTPLACED -
R0324 NOTPLACED -
R0331 NOTPLACED -
R0332 NOTPLACED -
R0333 NOTPLACED -
R0335 NOTPLACED -
R0341 NOTPLACED -
R0342 NOTPLACED -
R0343 NOTPLACED -
R0344 NOTPLACED -
R0345 NOTPLACED -
R0346 NOTPLACED -
R0347 NOTPLACED -
R0401 0662057A33 RES, 220
R0407 0662057M26 RES, 10
R0408 0662057A25 RES, 100
R0409 0662057M26 RES, 10
R0412 0662057B47 RES, 0
R0441 0662057B47 RES, 0
R0442 0662057A49 RES, 1K
R0467 0662057M26 RES, 10
R0468 0662057A97 RES, 100K
R0481 0662057B47 RES, 0
R0482 0662057B47 RES, 0
R0508 0662057A41 RES, 470
R0509 0662057B47 RES, 0
R0510 0662057A65 RES, 4.7K
R0511 0662057A97 RES, 100K
R0512 0662057A77 RES, 15K
Circuit
Ref
Motorola
Part No.
Description
R0525 0662057A97 RES, 100K
R0529 0662057A89 RES, 47K
R0530 0662057A81 RES, 22K
R0531 0662057A43 RES, 560
R0533 0662057B47 RES, 0
R0535 0662057A49 RES, 1K
R0537 0662057A33 RES, 220
R0538 0662057A33 RES, 220
R0539 0662057A65 RES, 4.7K
R0541 0662057A83 RES, 27K
R0542 NOTPLACED -
R0543 0662057A97 RES, 100K
R0555 0662057A25 RES, 100
R0556 0662057A25 RES, 100
R0591 0662057A82 RES, 24K
R0592 0662057A01 RES, 10
R0593 0662057A97 RES, 100K
R0611 0662057A91 RES, 56K
R0612 0662057A65 RES, 4.7K
R0621 0662057A82 RES, 24K
R0641 0662057A73 RES, 10K
R0642 0660076E70 RES, 7.5K
R0643 0660076E51 RES, 1.2K
R0651 0662057A01 RES, 10
R0652 0662057A01 RES, 10
R0661 0662057A49 RES, 1K
R0662 0662057B02 RES, 150K
R0671 0662057A84 RES, 30K
R0672 0662057A73 RES, 10K
R0681 0662057A79 RES, 18K
R0682 0662057A93 RES, 68K
R1001 0662057A05 RES, 15
R1002 0662057A05 RES, 15
R1003 0662057A41 RES, 470
R1004 0662057A59 RES, 2.7K
R1005 0662057A31 RES, 180
R1006 0662057A73 RES, 10K
R1007 0662057A71 RES, 8.2K
R1008 0662057A65 RES, 4.7K
R1009 NOTPLACED -
R1010 NOTPLACED -
R1011 NOTPLACED -
R1101 0662057A18 RES, 51
R1102 0662057A78 RES, 16K
R1103 0662057A39 RES, 390
R1104 0662057A71 RES, 8.2K
R1106 0662057A25 RES, 100
R1107 0662057A68 RES, 6.2K
R1108 0662057A61 RES, 3.3K
R1109 0662057A37 RES, 330
R1110 0662057A25 RES, 100
Circuit
Ref
Motorola
Part No.
Description
