Section 2: 3-2
Control Head CDM750 / PRO3100
Troubleshooting Flow Cha
rts
6881091C63-F
1.2
T
roubleshooting Flow Ch
art for Microprocessor
Power up alert tone sounds, but Volu
me knob
does not operate and ind
icator does not
light up
NO
YES
YES
NO
YES
NO
YES
NO
YES
EXTAL
U0831 Pin 31
= 8.00 MHz?
RESET
TP0833
= HIGH?
Check / Replace
C0833 / R0832 /
U0831
Check radio controller
Data Signal
on J0801 Pin 5
BUS+?
Data Signal
on TP0836
SCI_RX?
NO
Data Signal
on TP0837
SCI_TX?
Check / Replace
R0831 / U0833 /
U0831
Check / Replace
R0837 / R0836
Check / Replace
U0831
Check / Replace
D0831 / R0838
Measure with scope while
rotating Volume Pot
39
41
