Motorola Pro3100 Detailed Service Manual

Section 7: 4-52 Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists
6881091C63-F
R1114 0662057A64 RES, 4.3K
R1115 0662057A75 RES, 12K
R1116 Not Placed
R1117 0662057A37 RES, 330
R1118 0662057A56 RES, 2K
R1119 0662057A83 RES, 27K
R1120 0662057A18 RES, 51
R1121 0662057A71 RES, 8.2K
R1122 0662057A73 RES, 10K
R1123 0662057A51 RES, 1.2K
R1124 Not Placed
R1125 Not Placed
R1126 Not Placed
R1127 Not Placed
R1128 0662057A73 RES, 10K
R1129 0662057A73 RES, 10K
R1130 0662057A73 RES, 10K
R1131 0662057A77 RES, 15K
R1132 0662057A58 RES, 2.4K
R1133 0662057A61 RES, 3.3K
R1134 0662057A05 RES, 15
R1135 0662057A20 RES, 62
R1136 0662057A45 RES, 680
R1137 0662057A75 RES, 12K
R1138 0662057A01 RES, 10
R1139 0611077A12 RES, 2.7
R1140 0662057A39 RES, 390
R1141 0662057A55 RES, 1.8K
R1201 0662057B47 RES, 0
R1202 Not Placed
R1203 0662057B02 RES, 150K
R1204 0662057B47 RES, 0
R1205 0662057A45 RES, 680
R1206 0662057A41 RES, 470
R1207 Not Placed
R1208 0662057A18 RES, 51
R1209 0662057A61 RES, 3.3K
R1210 0662057A33 RES, 220
R1211 0662057B14 RES, 470K
R1212 0662057A25 RES, 100
R1213 0662057A45 RES, 680
R1214 0662057A54 RES, 1.6K
R1215 0662057A21 RES, 68
R1216 0662057A18 RES, 51
R1217 0662057A25 RES, 100
R1218 0662057A17 RES, 47
R1219 0662057A17 RES, 47
R1220 0662057A17 RES, 47
R1221 0662057B47 RES, 0
R1222 Not Placed
R1306 0662057B47 RES, 0
Circuit
Ref
Motorola
Part No.
Description
R1307 0662057A19 RES, 56
R1308 0662057A19 RES, 56
R1309 0662057A41 RES, 470
R1311 0662057A73 RES, 10K
R1312 0662057A51 RES, 1.2K
R1313 0662057A51 RES, 1.2K
R1314 0662057A37 RES, 330
R1315 0662057A61 RES, 3.3K
R1316 0662057A45 RES, 680
R1317 0662057A09 RES, 22
R1318 0662057A41 RES, 470
R1319 0662057A01 RES, 10
R1320 0662057A41 RES, 470
R1325 0662057B47 RES, 0
R1326 0662057A19 RES, 56
R1327 0662057A19 RES, 56
R1328 0662057A41 RES, 470
R1330 0662057A73 RES, 10K
R1331 0662057A51 RES, 1.2K
R1332 0662057A51 RES, 1.2K
R1333 0662057A37 RES, 330
R1334 0662057A61 RES, 3.3K
R1335 0662057A47 RES, 820
R1336 0662057A09 RES, 22
R1337 0662057A22 RES, 75
R1338 0662057A27 RES, 120
R1339 0662057A22 RES, 75
R1340 0662057A49 RES, 1K
R1341 0662057A25 RES, 100
R1342 0662057A25 RES, 100
R1343 0662057C55 RES, 150
R1344 0662057A49 RES, 1K
R1345 0662057A25 RES, 100
R1346 0662057A25 RES, 100
R1347 0662057C55 RES, 150
R1376 0662057A65 RES, 4.7K
R1402 0611079A64 RES, 390
R1404 0680194M18 RES, 51
R1405 0680194M18 RES, 51
R1406 0662057A73 RES, 10K
R1407 0662057A73 RES, 10K
R1409 0682089V01 RES, .01
R1410 0683962T52 RES, 130
R1411 0662057C99 RES, 10K
R1412 Not Placed
R1413 0680194M01 RES, 10
R1414 0680194M01 RES, 10
R1415 Not Placed
R1416 0680194M01 RES, 10
R1417 0680194M01 RES, 10
R1418 0680194M01 RES, 10
Circuit
Ref
Motorola
Part No.
Description
R1419 0680194M01 RES, 10
R1420 0680194M01 RES, 10
R1421 0680194M01 RES, 10
R1422 0680194M01 RES, 10
R1423 0680194M01 RES, 10
R1424 0662057D10 RES, 27K
R1425 0662057D10 RES, 27K
R1440 0662057A25 RES, 100
R1441 Not Placed
R1442 0662057B47 RES, 0
R1443 0662057A49 RES, 1K
R1444 0662057A33 RES, 220
R1445 0662057A68 RES, 6.2K
R1446 Not Placed
R1447 0662057B47 RES, 0
R1448 Not Placed
R1449 0611079A64 RES, 390
R1450 0683962T71 RES, 820
R1451 Not Placed
R1453 0662057K31 RES, 180
R1454 0662057K31 RES, 180
R1455 0662057K31 RES, 180
R1457 0662057K01 RES, 10
R1458 0611079A64 RES, 390
R1459 0611079A64 RES, 390
R1460 0680106R01 RES, 0.1
R1463 0662057A75 RES, 12K
R1464 0662057A61 RES, 3.3K
R1465 0662057A61 RES, 3.3K
R1466 Not Placed
R1467 Not Placed
R1468 Not Placed
R1469 0662057C01 RES, 0
R1470 Not Placed
R1471 Not Placed
R1472 0662057A73 RES, 10K
R1473 0680194M01 RES, 10
R1474 0680194M01 RES, 10
R1475 0680194M01 RES, 10
R1476 0680194M01 RES, 10
R1477 0662057A61 RES, 3.3K
R1478 0662057A73 RES, 10K
R1479 0662057A61 RES, 3.3K
R1480 0662057D10 RES, 27K
R1482 0662057B47 RES, 0
R1483 0662057A34 RES, 240
R1484 0662057A49 RES, 1K
R1501 0662057A45 RES, 680
R1502 0662057C67 RES, 470
R1503 0662057A61 RES, 3.3K
R1504 0662057A73 RES, 10K
Circuit
Ref
Motorola
Part No.
Description
R1505 0662057A69 RES, 6.8K
R1506 0662057A87 RES, 39K
R1507 0662057A49 RES, 1K
R1508 0662057R17 RES, 43.2
R1509 0662057P95 RES, 100K
R1510 Not Placed
R1511 0662057P95 RES, 100K
R1512 Not Placed
R1513 0662057C76 RES, 1.1K
R1514 0662057A97 RES, 100K
R1515 0662057A49 RES, 1K
R1516 0662057C71 RES, 680
R1517 0662057C71 RES, 680
R1518 0662057A61 RES, 3.3K
R1519 0662057C71 RES, 680
R1522 0662057A73 RES, 10K
R1523 Not Placed
R1524 0662057C71 RES, 680
R1525 Not Placed
R1526 0662057A97 RES, 100K
R1527 0662057A97 RES, 100K
R1528 0662057A80 RES, 20K
R1532 0662057A95 RES, 82K
R1533 0662057A73 RES, 10K
R1535 0662057R16 RES, 39.2
R1539 0662057A53 RES, 1.5K
R1540 0662057A53 RES, 1.5K
R1542 0662057A49 RES, 1K
R1543 0662057A49 RES, 1K
R1544 0662057A90 RES, 51K
R1545 0662057A65 RES, 4.7K
R1601 0662057A73 RES, 10K
R1602 0662057A65 RES, 4.7K
R1604 0662057A49 RES, 1K
R1605 0662057B10 RES, 330K
R1606 0662057B02 RES, 150K
R1607 0662057B19 RES, 750K
R1608 0662057A57 RES, 2.2K
R1609 0662057A73 RES, 10K
R1610 0662057A82 RES, 24K
R1611 0662057A49 RES, 1K
R1612 0662057A25 RES, 100
R1613 0662057A59 RES, 2.7K
R1614 0662057A49 RES, 1K
R1615 0662057A49 RES, 1K
R1616 0662057A33 RES, 220
R1617 0662057A57 RES, 2.2K
R1620 0662057A51 RES, 1.2K
R1621 0662057A68 RES, 6.2K
R1622 0662057A49 RES, 1K
R1626 0662057A18 RES, 51
Circuit
Ref
Motorola
Part No.
Description
