Section 7: 4-58 Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists
6881091C63-F
L1604 2483411T45 INDUCTOR CHIP SHIELDED
L1605 2483411T41 INDUCTOR CHIP SHIELDED
L1606 2462587T30 IND CHIP 1000NH 5% LOW
PRO
L1607 2462587T30 IND CHIP 1000NH 5% LOW
PRO
L2000 2415429H47 CHIP INDUCTOR
M1401 2686201B01 COIL AIR WOUND INDUC
72.22
Q0110 4880048M01 TSTR NPN DIG 47K/47K
Q0151 4880048M01 TSTR NPN DIG 47K/47K
Q0171 4880048M01 TSTR NPN DIG 47K/47K
Q0173 4880052M01 TSTR NPN DRLNGTN
MXTA27
Q0177 4880048M01 TSTR NPN DIG 47K/47K
Q0181 4880048M01 TSTR NPN DIG 47K/47K
Q0183 4880048M01 TSTR NPN DIG 47K/47K
Q0185 4880048M01 TSTR NPN DIG 47K/47K
Q0271 4880214G02 TSTR MMBT3904
Q0641 4880048M01 TSTR NPN DIG 47K/47K
Q0661 4805921T02 XISTOR FMC2 RH
Q0662 4880214G02 TSTR MMBT3904
Q0663 4880048M01 TSTR NPN DIG 47K/47K
Q0681 4880052M01 TSTR NPN DRLNGTN
MXTA27
Q1001 4880182D44 TSTR SILICON NPN SOT23
2SC3606
Q1002 4813973A13 XSTR,GEN PURPOSE
SMALL SIG,PNP, MMBT
3906L,TO-236,4, PB-FREE
Q1003 4813973A13 XSTR,GEN PURPOSE
SMALL SIG,PNP,MMBT
3906L,TO-236,4, PB-FREE
Q1101 4802197J95 RF TRANSISTOR PBR941
Q1102 4813823A05 XSTR N-CH RF JFET
MMBFU310LT1
Q1103 4813823A05 XSTR N-CH RF JFET
MMBFU310LT1
Q1104 4813823A05 XSTR N-CH RF JFET
MMBFU310LT1
Q1105 4880048M01 TSTR NPN DIG 47K/47K
Q1106 4802197J95 RF TRANSISTOR PBR941
Q1107 4880214G02 TSTR MMBT3904
Q1201 4813973A13 XSTR,GEN PURPOSE
SMALL SIG,PNP, MMBT
3906L,TO-236,4, PB-FREE
Q1202 4880182D44 TSTR SILICON NPN SOT23
2SC3606
Q1303 4884235R02 TSTR 35R01 SOT TAPED A/
P 1
Circuit
Ref
Motorola
Part No.
Description
Q1304 4880182D44 TSTR SILICON NPN SOT23
2SC3606
Q1305 4880182D44 TSTR SILICON NPN SOT23
2SC3606
Q1306 4884235R02 TSTR 35R01 SOT TAPED A/
P 1
Q1307 4880182D44 TSTR SILICON NPN SOT23
2SC3606
Q1308 4880182D44 TSTR SILICON NPN SOT23
2SC3606
Q1401 4813976A04 FET RF 520MHZ 8W 12.5V
PLD-1.5 T&R
Q1402 4816121H01 LD MOS SMT 55W 175MHZ
12V
Q1403 4816121H01 LD MOS SMT 55W 175MHZ
12V
Q1501 4816023H01 QSTR PNP SOT23 LO
PROFILE TAPE
Q1502 4880214G02 TSTR MMBT3904
Q1503 4880214G02 TSTR MMBT3904
Q1504 4880214G02 TSTR MMBT3904
Q1505 4813973A13 XSTR,GEN PURPOSE
SMALL SIG,PNP,MMBT
3906L,TO-236,4, PB-FREE
Q1506 4880214G02 TSTR MMBT3904
Q1601 4813973A13 XSTR,GEN PURPOSE
SMALL SIG,PNP, MMBT
3906L,TO-236,4, PB-FREE
Q1602 4880048M01 TSTR NPN DIG 47K/47K
Q1603 4880214G02 TSTR MMBT3904
Q1604 4880214G02 TSTR MMBT3904
Q1605 4880214G02 TSTR MMBT3904
Q1606 4813973A13 XSTR,GEN PURPOSE
SMALL SIG,PNP, MMBT
3906L,TO-236,4, PB-FREE
Q1607 4880214G02 TSTR MMBT3904
Q1609 4813973A13 XSTR,GEN PURPOSE
SMALL SIG,PNP, MMBT
3906L,TO-236,4, PB-FREE
Q1610 4805585Q17 TRANS GAAS LDUAL GATE
FET SOT
R0101 0662057A73 CHIP RES 10K OHMS 5%
R0102 0662057A65 CHIP RES 4700 OHMS 5%
R0103 0662057A01 CHIP RES 10 OHMS 5%
R0104 0662057A73 CHIP RES 10K OHMS 5%
R0105 0662057A97 CHIP RES 100K OHMS 5%
R0108 0662057A57 CHIP RES 2200 OHMS 5%
R0111 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R0113 0662057A73 CHIP RES 10K OHMS 5%
R0114 0662057A73 CHIP RES 10K OHMS 5%
Circuit
Ref
Motorola
Part No.
Description
R0115 0662057A73 CHIP RES 10K OHMS 5%
R0117 0662057A63 CHIP RES 3900 OHMS 5%
R0121 0662057A97 CHIP RES 100K OHMS 5%
R0131 0662057B46 CHIP RES 10.0 MEG OHMS
5%
R0132 0662057B10 CHIP RES 330K OHMS 5%
R0151 0662057A82 CHIP RES 24K OHMS 5%
R0152 0662057A82 CHIP RES 24K OHMS 5%
R0170 0662057A73 CHIP RES 10K OHMS 5%
R0171 0662057A65 CHIP RES 4700 OHMS 5%
R0172 0662057A73 CHIP RES 10K OHMS 5%
R0173 0662057A65 CHIP RES 4700 OHMS 5%
R0174 0662057A73 CHIP RES 10K OHMS 5%
R0175 0662057A73 CHIP RES 10K OHMS 5%
R0176 0662057A84 CHIP RES 30K OHMS 5%
R0177 0662057A65 CHIP RES 4700 OHMS 5%
R0178 0662057A89 CHIP RES 47K OHMS 5%
R0179 0662057A89 CHIP RES 47K OHMS 5%
R0181 0662057A65 CHIP RES 4700 OHMS 5%
R0182 0662057A89 CHIP RES 47K OHMS 5%
R0183 0662057A65 CHIP RES 4700 OHMS 5%
R0184 0662057A89 CHIP RES 47K OHMS 5%
R0185 0662057A65 CHIP RES 4700 OHMS 5%
R0186 0662057A89 CHIP RES 47K OHMS 5%
R0201 0662057A25 CHIP RES 100 OHMS 5%
R0202 0662057A43 CHIP RES 560 OHMS 5%
R0203 0662057A25 CHIP RES 100 OHMS 5%
R0204 0662057A43 CHIP RES 560 OHMS 5%
R0205 0662057A73 CHIP RES 10K OHMS 5%
R0206 0662057A73 CHIP RES 10K OHMS 5%
R0207 0662057A57 CHIP RES 2200 OHMS 5%
R0208 0662057A57 CHIP RES 2200 OHMS 5%
R0211 0660076E75 RES CHIP FILM 7500 1 1/8
R0212 0660076E75 RES CHIP FILM 7500 1 1/8
R0221 0662057A82 CHIP RES 24K OHMS 5%
R0222 0662057A82 CHIP RES 24K OHMS 5%
R0223 0662057A84 CHIP RES 30K OHMS 5%
R0224 0662057A71 CHIP RES 8200 OHMS 5%
R0228 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R0229 0662057A01 CHIP RES 10 OHMS 5%
R0241 0662057A89 CHIP RES 47K OHMS 5%
R0242 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R0251 0662057A89 CHIP RES 47K OHMS 5%
R0252 0662057A91 CHIP RES 56K OHMS 5%
R0253 0662057A97 CHIP RES 100K OHMS 5%
R0254 0662057A73 CHIP RES 10K OHMS 5%
R0255 0662057A73 CHIP RES 10K OHMS 5%
R0256 0662057A97 CHIP RES 100K OHMS 5%
R0257 0662057A57 CHIP RES 2200 OHMS 5%
Circuit
Ref
Motorola
Part No.
Description
R0261 0662057A73 CHIP RES 10K OHMS 5%
R0262 0662057B08 CHIP RES 270K OHMS 5%
R0265 0662057A82 CHIP RES 24K OHMS 5%
R0267 0662057A89 CHIP RES 47K OHMS 5%
R0268 0662057A73 CHIP RES 10K OHMS 5%
R0269 0662057A41 CHIP RES 470 OHMS 5%
R0273 0662057A82 CHIP RES 24K OHMS 5%
R0275 0662057A73 CHIP RES 10K OHMS 5%
R0276 0662057A77 CHIP RES 15K OHMS 5%
R0401 0662057A33 CHIP RES 220 OHMS 5%
R0407 0662057M26 RES CHIP 10 5 20X40
R0408 0662057A25 CHIP RES 100 OHMS 5%
R0409 0662057M26 RES CHIP 10 5 20X40
R0412 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R0441 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R0442 0662057A49 CHIP RES 1000 OHMS 5%
R0467 0662057M26 RES CHIP 10 5 20X40
R0468 0662057A97 CHIP RES 100K OHMS 5%
R0481 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R0482 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R0508 0662057A41 CHIP RES 470 OHMS 5%
R0509 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R0510 0662057A65 CHIP RES 4700 OHMS 5%
R0511 0662057A97 CHIP RES 100K OHMS 5%
R0512 0662057A77 CHIP RES 15K OHMS 5%
R0525 0662057A97 CHIP RES 100K OHMS 5%
R0529 0662057A89 CHIP RES 47K OHMS 5%
R0530 0662057A81 CHIP RES 22K OHMS 5%
R0531 0662057A43 CHIP RES 560 OHMS 5%
R0533 0662057B47 CHIP RES 0 OHMS +-.0 50
OHMS
R0535 0662057A49 CHIP RES 1000 OHMS 5%
R0537 0662057A33 CHIP RES 220 OHMS 5%
R0538 0662057A33 CHIP RES 220 OHMS 5%
R0539 0662057A65 CHIP RES 4700 OHMS 5%
R0541 0662057A83 CHIP RES 27K OHMS 5%
R0543 0662057A97 CHIP RES 100K OHMS 5%
R0555 0662057A25 CHIP RES 100 OHMS 5%
R0556 0662057A25 CHIP RES 100 OHMS 5%
R0591 0662057A82 CHIP RES 24K OHMS 5%
R0592 0662057A01 CHIP RES 10 OHMS 5%
R0593 0662057A97 CHIP RES 100K OHMS 5%
R0611 0662057A91 CHIP RES 56K OHMS 5%
R0612 0662057A65 CHIP RES 4700 OHMS 5%
R0621 0662057A82 CHIP RES 24K OHMS 5%
R0641 0662057A73 CHIP RES 10K OHMS 5%
Circuit
Ref
Motorola
Part No.
Description
To Next Page
