Motorola Pro3100 Detailed Service Manual

Section 7: 4-64 Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists
6881091C63-F
R0212 0613958D85 RES, 7500
R0221 0613952J10 RES, 24K
R0222 0613952J10 RES, 24K
R0223 0613952J12 RES, 30K
R0224 0613952H95 RES, 8200
R0228 0613952G67 RES, 0
R0229 0613952H25 RES, 10
R0241 0613952J17 RES, 47K
R0242 0613952G67 RES, 0
R0251 0613952J17 RES, 47K
R0252 0613952J19 RES, 56K
R0253 0613952J25 RES, 100K
R0254 0613952J01 RES, 10K
R0255 0613952J01 RES, 10K
R0256 0613952J25 RES, 100K
R0257 0613952H81 RES, 2200
R0261 0613952J01 RES, 10K
R0262 0613952J35 RES, 270K
R0265 0613952J10 RES, 24K
R0267 0613952J17 RES, 47K
R0268 0613952J01 RES, 10K
R0269 0613952H65 RES, 470
R0273 0613952J10 RES, 24K
R0275 0613952J01 RES, 10K
R0276 0613952J05 RES, 15K
R0401 0613952H57 RES, 220
R0407 0613952Q25 RES, 10
R0408 0613952H49 RES, 100
R0409 0613952Q25 RES, 10
R0412 0613952G67 RES, 0
R0441 0613952G67 RES, 0
R0442 0613952H73 RES, 1000
R0467 0613952Q25 RES, 10
R0468 0613952J25 RES, 100K
R0481 0613952G67 RES, 0
R0482 0613952G67 RES, 0
R0508 0613952H65 RES, 470
R0509 0613952G67 RES, 0
R0510 0613952H89 RES, 4700
R0511 0613952J25 RES, 100K
R0512 0613952J05 RES, 15K
R0525 0613952J25 RES, 100K
R0529 0613952J17 RES, 47K
R0530 0613952J09 RES, 22K
R0531 0613952H67 RES, 560
R0533 0613952G67 RES, 0
R0535 0613952H73 RES, 1000
R0537 0613952H57 RES, 220
R0538 0613952H57 RES, 220
R0539 0613952H89 RES, 4700
R0541 0613952J11 RES, 27K
Circuit
Ref
Motorola
Part No.
Description
R0543 0613952J25 RES, 100K
R0555 0613952H49 RES, 100
R0556 0613952H49 RES, 100
R0591 0613952J10 RES, 24K
R0592 0613952H25 RES, 10
R0593 0613952J25 RES, 100K
R0611 0613952J19 RES, 56K
R0612 0613952H89 RES, 4700
R0621 0613952J10 RES, 24K
R0641 0613952J01 RES, 10K
R0642 0613958D85 RES, 7500
R0643 0613958D09 RES, 1200
R0651 0613952H25 RES, 10
R0652 0613952H25 RES, 10
R0661 0613952H73 RES, 1000
R0662 0613952J29 RES, 150K
R0671 0613952J12 RES, 30K
R0672 0613952J01 RES, 10K
R0681 0613952J07 RES, 18K
R0682 0613952J21 RES, 68K
R1001 0613952H25 RES, 10
R1002 0613952H29 RES, 15
R1003 0613952H65 RES, 470
R1004 0613952H83 RES, 2700
R1005 0613952H55 RES, 180
R1006 0613952J01 RES, 10K
R1007 0613952H95 RES, 8200
R1008 0613952H89 RES, 4700
R1101 0613952H42 RES, 51
R1102 0613952J06 RES, 16K
R1103 0613952H63 RES, 390
R1104 0613952H95 RES, 8200
R1106 0613952H49 RES, 100
R1107 0613952H92 RES, 6200
R1108 0613952H85 RES, 3300
R1109 0613952H61 RES, 330
R1110 0613952H49 RES, 100
R1111 0613952H41 RES, 47
R1113 0613952H88 RES, 4300
R1114 0613952H88 RES, 4300
R1115 0613952J03 RES, 12K
R1116 NOT PLACED
R1117 0613952H61 RES, 330
R1118 0613952H80 RES, 2000
R1119 0613952J11 RES, 27K
R1120 0613952H42 RES, 51
R1121 0613952H89 RES, 4700
R1122 0613952J01 RES, 10K
R1123 0613952H75 RES, 1200
R1124 NOT PLACED
R1125 NOT PLACED
Circuit
Ref
Motorola
Part No.
Description
R1126 NOT PLACED
R1127 NOT PLACED
R1128 0613952J01 RES, 10K
R1129 0613952J01 RES, 10K
R1130 0613952J01 RES, 10K
R1131 0613952J05 RES, 15K
R1132 0613952H82 RES, 2400
R1133 0613952H85 RES, 3300
R1134 0613952H29 RES, 15
R1135 0613952H44 RES, 62
R1136 0613952H69 RES, 680
R1137 0613952J03 RES, 12K
R1138 0613952H25 RES, 10
R1139 0613958S11 RES, 2.7
R1140 0613952H63 RES, 390
R1141 0613952H79 RES, 1800
R1201 0613952G67 RES, 0
R1203 0613952J17 RES, 47K
R1204 0613952G67 RES, 0
R1205 0613952H69 RES, 680
R1206 0613952H65 RES, 470
R1208 0613952H42 RES, 51
R1209 0613952H85 RES, 3300
R1210 0613952H57 RES, 220
R1211 0613952J41 RES, 470K
R1212 0613952H49 RES, 100
R1213 0613952H69 RES, 680
R1214 0613952H78 RES, 1600
R1215 0613952H45 RES, 68
R1216 0613952H42 RES, 51
R1217 0613952H49 RES, 100
R1218 0613952H41 RES, 47
R1219 0613952H41 RES, 47
R1220 0613952H41 RES, 47
R1221 0613952G67 RES, 0
R1222 0613952H49 RES, 100
R1306 0613952G67 RES, 0
R1307 0613952H43 RES, 56
R1308 0613952H43 RES, 56
R1309 0613952H65 RES, 470
R1311 0613952J01 RES, 10K
R1312 0613952H75 RES, 1200
R1313 0613952H75 RES, 1200
R1314 0613952H61 RES, 330
R1315 0613952H85 RES, 3300
R1316 0613952H69 RES, 680
R1317 0613952H37 RES, 33
R1318 0613952H65 RES, 470
R1319 0613952H25 RES, 10
R1320 0613952H65 RES, 470
R1325 0613952G67 RES, 0
Circuit
Ref
Motorola
Part No.
Description
R1326 0613952H43 RES, 56
R1327 0613952H43 RES, 56
R1328 0613952H65 RES, 470
R1330 0613952J01 RES, 10K
R1331 0613952H75 RES, 1200
R1332 0613952H75 RES, 1200
R1333 0613952H61 RES, 330
R1334 0613952H85 RES, 3300
R1335 0613952H71 RES, 820
R1336 0613952H33 RES, 22
R1337 0613952H46 RES, 75
R1338 0613952H51 RES, 120
R1339 0613952H46 RES, 75
R1340 0613952H73 RES, 1000
R1341 0613952H49 RES, 100
R1342 0613952H49 RES, 100
R1343 0613958H53 RES, 150
R1344 0613952H73 RES, 1000
R1345 0613952H49 RES, 100
R1346 0613952H49 RES, 100
R1347 0613958H53 RES, 150
R1376 0613952H89 RES, 4700
R1402 0613958H63 RES, 390
R1404 0613959Y42 RES, 51
R1405 0613959Y42 RES, 51
R1406 0613952J01 RES, 10K
R1407 0613952J01 RES, 10K
R1409 0671463L01 RES, .01
R1410 0613959Y52 RES, 130
R1411 0613958J01 RES, 10K
R1413 0613959Y25 RES, 10
R1414 0613959Y25 RES, 10
R1416 0613959Y25 RES, 10
R1417 0613959Y25 RES, 10
R1418 0613959Y25 RES, 10
R1419 0613959Y25 RES, 10
R1420 0613959Y25 RES, 10
R1421 0613959Y25 RES, 10
R1422 0613959Y25 RES, 10
R1423 0613959Y25 RES, 10
R1424 0613958J11 RES, 27K
R1425 0613958J11 RES, 27K
R1440 0613952H49 RES, 100
R1442 0613952G67 RES, 0
R1443 0613952H73 RES, 1000
R1444 0613952H57 RES, 220
R1445 0613952H92 RES, 6200
R1447 0613952G67 RES, 0
R1449 0613958H63 RES, 390
R1450 0613959Y71 RES, 820
R1453 0613959G55 RES, 180
Circuit
Ref
Motorola
Part No.
Description
