Motorola Pro3100 Detailed Service Manual

Section 7: 4-92 Low Band Range 3 (42–50 MHz) PCBs, Schematics, and Parts Lists
6881091C63-F
C1611 2113743E26 CAP CHIP .10 UF 10%
C1612 2113741F33 CAP CHIP CL2 X7R REEL
2200
C1613 2113740F54 CAP CHIP REEL CL1 +/-30
130
C1614 2113741F24 CAP CHIP CL2 X7R REEL
910
C1616 2113740F40 CAP CHIP REEL CL1 +/-30
36
C1618 2113743A23 CAP CHIP .220 UF 10% X7R
C1619 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C1620 2113741F25 CAP CHIP CL2 X7R REEL
1000
C1622 2113743E26 CAP CHIP .10 UF 10%
C1623 2113740F60 CAP CHIP REEL CL1 +/-130
240
C1624 2113741F37 CAP CHIP CL2 X7R REEL
3300
C1625 2113740F29 CAP CHIP REEL CL1 +/-30
12
C1626 2113740F59 CAP CHIP REEL CL1 +/-30
220
C1627 2113743A23 CAP CHIP .220 UF 10% X7R
C1628 2113743E26 CAP CHIP .10 UF 10%
C1629 2113740F39 CAP CHIP REEL CL1 +/-30
33
C1631 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C1632 2113743E26 CAP CHIP .10 UF 10%
C1633 2113743A23 CAP CHIP .220 UF 10% X7R
C1634 2113741A45 CHIP CAPACITORS 10000PF
+-5%
CR1201 4862824C03 DIODE VARACTOR
CR1202 4802233J09 DIODE TRIPLE SOT25-RH
CR1302 4805649Q14 DIODE VARACTOR
CR1306 4880154K03 DIODE DUAL SCHOTTKY
MIXER
CR1310 4805649Q14 DIODE VARACTOR
CR1314 4880154K03 DIODE DUAL SCHOTTKY
MIXER
D0101 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
D0151 4813833C02 DIODE DUAL 70V 5B COMM
CATH
D0179 4813833C02 DIODE DUAL 70V 5B COMM
CATH
D0621 4813833C02 DIODE DUAL 70V 5B COMM
CATH
D0651 4813833C02 DIODE DUAL 70V 5B COMM
CATH
Circuit
Ref
Motorola
Part No.
Description
D0660 4813833C02 DIODE DUAL 70V 5B COMM
CATH
D0661 4813833C02 DIODE DUAL 70V 5B COMM
CATH
D1001 4880154K03 DIODE DUAL SCHOTTKY
MIXER
D1101 4880154K03 DIODE DUAL SCHOTTKY
MIXER
D1401 4808379X02 MA-COM MA4P1450 SMD
PINDIODE
D1402 4808379X02 MA-COM MA4P1450 SMD
PINDIODE
D1501 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
D1502 4813833C02 DIODE DUAL 70V 5B COMM
CATH
D1503 4813833C02 DIODE DUAL 70V 5B COMM
CATH
D1601 4880154K03 DIODE DUAL SCHOTTKY
MIXER
E0271 2484657R01 INDUCTOR BEAD CHIP
E0272 2484657R01 INDUCTOR BEAD CHIP
E0631 2484657R01 INDUCTOR BEAD CHIP
E1401 2408380X02 FAIR-RITE 2773037447L
BEAD
E1403 2408380X02 FAIR-RITE 2773037447L
BEAD
F0401 6515076H01 FUSE CHIP SMT TR/1608FF
3A
FL1101 9180656U03 10.7MHZ CERAMIC FILTER
FL1102 9180022M09 FLTR 4 POLE 10.7MHZ
FL1104 9180468V04 SMD455KHZ 4 ELEMENT
CER FLTR
FL1105 9180468V05 SMD455KHZ 4 ELEMENT
CER FLTR
FL1106 9180469V04 SMD455KHZ 6 ELEMENT
CER FLTR
FL1107 9180469V05 SMD455KHZ 6 ELEMENT
CER FLTR
J0401 0902636Y02 12 POS. FLEX CONNECTOR
J0451 0902636Y01 “CONNECTOR,FLEX,SIDE
ENTRY”
J0501 0986105B01 “20 POS. 0,64 SQ CONNEC-
TOR”
J0551 0915064H03 “CONNECTOR, ZIF (40
PINS)”
J0552 0915064H01 ZIF (18 PINS)
J0601 0986165B04 DC POWER CONNECTOR
J1401 0986166B02 MOBILE RF CONNECTOR
(MINI UHF)
Circuit
Ref
Motorola
Part No.
Description
L1001 2408382A11 COILCRAFT SMD 11T 130NH
2%
L1002 2408382C11 COILCRAFT SMD 11T 130NH
2%X8371-A
L1003 2408382A11 COILCRAFT SMD 11T 130NH
2%
L1004 2408382C11 COILCRAFT SMD 11T 130NH
2%X8371-A
L1005 2408382A11 COILCRAFT SMD 11T 130NH
2%
L1006 2408382A11 COILCRAFT SMD 11T 130NH
2%
L1007 2408382C11 COILCRAFT SMD 11T 130NH
2%X8371-A
L1008 2408382A11 COILCRAFT SMD 11T 130NH
2%
L1009 2408382C11 COILCRAFT SMD 11T 130NH
2%X8371-A
L1010 2408382A11 COILCRAFT SMD 11T 130NH
2%
L1011 2462587N68 CHIP IND 1000 NH 20%
L1012 2462587N57 CHIP IND 220 NH 5%
L1013 2462587N59 CHIP IND 330NH 5%
L1014 2462587N57 CHIP IND 220 NH 5%
L1101 2462587N33 CHIP IND 1800 NH 10%
L1102 2408383X07 “SHIELDED SMT COIL,3.3
UH”
L1103 2462587N33 CHIP IND 1800 NH 10%
L1104 2480289M10 COIL IF 22UH 1611 CS 223
L1105 2480289M10 COIL IF 22UH 1611 CS 223
L1106 2462587N33 CHIP IND 1800 NH 10%
L1107 2480289M09 COIL IF 22UH 1611 CS 223
L1108 NOT PLACED –
L1109 NOT PLACED –
L1110 2480289M18 COIL IF 22UH 1611 CS 223
L1111 2408383X07 “SHIELDED SMT COIL,3.3
UH”
L1112 2483411T35 INDUCTOR CHIP SHIELDED
L1201 2480289M17 COIL IF 22UH 1611 CS 223
L1202 2462587Q20 “IND CHIP 2,200 NH 20%”
L1205 2462587N59 CHIP IND 330NH 5%
L1206 2480289M17 COIL IF 22UH 1611 CS 223
L1302 2408382D19 COILCRAFT SMD 19T 491NH
2%X8370-A
L1303 2480289M15 COIL IF 22UH 1611 CS 223
L1304 2462587N66 CHIP IND 820 NH 5%
L1305 2480289M15 COIL IF 22UH 1611 CS 223
L1306 2480289M15 COIL IF 22UH 1611 CS 223
L1307 2480289M15 COIL IF 22UH 1611 CS 223
L1309 2480289M15 COIL IF 22UH 1611 CS 223
L1310 2462587N60 CHIP IND 390 NH 5%
Circuit
Ref
Motorola
Part No.
Description
L1311 2480289M15 COIL IF 22UH 1611 CS 223
L1313 2408382D19 COILCRAFT SMD 19T 491NH
2%X8370-A
L1314 2480289M17 COIL IF 22UH 1611 CS 223
L1315 2462587N66 CHIP IND 820 NH 5%
L1316 2480289M17 COIL IF 22UH 1611 CS 223
L1317 2480289M17 COIL IF 22UH 1611 CS 223
L1318 2480289M17 COIL IF 22UH 1611 CS 223
L1321 2462587N58 CHIP IND 270 NH 5%
L1322 2480289M17 COIL IF 22UH 1611 CS 223
L1324 2480289M17 COIL IF 22UH 1611 CS 223
L1402 2462587U09 “CHIP IND 4,700NH 10%”
L1403 2462587U09 “CHIP IND 4,700NH 10%”
L1404 2462587N56 CHIP IND 180 NH 5%
L1406 2408381X36 ROUND AIR CORE 9T
251NH
L1408 2408384A10 120NH 5% COILCRAFT
1812SMS-R12J
L1413 2408381X17 ROUND AIR CORE 5T
88.5NH
L1414 2408381X17 ROUND AIR CORE 5T
88.5NH
L1415 2485873L01 ENCAPSULATED AIR
WOUND COIL
L1416 2485873L01 ENCAPSULATED AIR
WOUND COIL
L1417 2485873L01 ENCAPSULATED AIR
WOUND COIL
L1418 2408381X12 ROUND AIR CORE 5T
66.4NH
L1419 2480289M17 COIL IF 22UH 1611 CS 223
L1420 2408381X29 ROUND AIR CORE 7T
173NH
L1421 2408381X25 ROUND AIR CORE 6T
138NH
L1422 2408381X22 ROUND AIR CORE 6T 116NH
L1423 2408381X16 ROUND AIR CORE 5T
81.9NH
L1425 2485873L01 ENCAPSULATED AIR
WOUND COIL
L1426 2485873L01 ENCAPSULATED AIR
WOUND COIL
L1601 2483411T45 INDUCTOR CHIP SHIELDED
L1602 2483411T45 INDUCTOR CHIP SHIELDED
L1603 2483411T73 INDUCTOR CHIP SHIELDED
L1604 2483411T45 INDUCTOR CHIP SHIELDED
L1605 2483411T41 INDUCTOR CHIP SHIELDED
L1606 2462587T30 IND CHIP 1000NH 5% LOW
PRO
L1607 2462587T30 IND CHIP 1000NH 5% LOW
PRO
Circuit
Ref
Motorola
Part No.
Description
