VHF (136–174 MHz) 25–45 W Bipolar PCB 8486140B13, Schematics, and Parts Lists Section 8: 4-17
6881091C63-F
C3496 2111078B33 HQ 43pF 5%
C3497 2111078B21 HQ 20pF 5%
C3498 2111078B34 HQ 47pF 5%
C3501 2113741F33 2.2nF 50V
C3502 2113741F33 2.2nF 50V
C3503 2113741F33 2.2nF 50V
C3504 2113741F33 2.2nF 50V
C3505 2311049A07 TANT CP 1uF 10% 16V
C3506 2113741F33 2.2nF 50V
C3507 2113740F51 100pF 5% 50V
C3508 2113741F33 2.2nF 50V
C3509 2113741F33 2.2nF 50V
C3510 2113743E20 100nF 16V
D3000 4813833C02 DUAL SOT MMBD6100
D3001 4805649Q13 VCTR 1SV228 SOT23
D3003 4880154K03 DUAL SCHOTTKY SOT23
D3004 4805649Q13 VCTR 1SV228 SOT23
D3011 4880142L01 PIN
D3031 4886143B01 MIXER DIODE CROSSOVER
D3101 4880154K03 DIODE DUAL SCHOTTKY
D3201 4802233J09 TRIPLE SOT143-RH
D3221 4880236E05 CHIP SCHOTTKY
D3341 4805649Q13 VCTR 1SV228 SOT23
D3361 4805649Q13 VCTR 1SV228 SOT23
D3362 4862824C01 VARACTOR CHIP
D3451 4882290T02 HOT CARRIER HSMS2802
D3452 4882290T02 HOT CARRIER HSMS2802
D3471 4802482J02 PIN MA/COM
D3472 4802482J02 PIN MA/COM
FL3101 9180112R16 44.85 MHZ XSTAL FLTR
80dB
FL3102 9180112R16 44.85 MHZ XSTAL FLTR
80dB
FL3111 9180469V03 CER FLTR 6EL 455 KHZ SMD
FL3112 9180469V06 CER FLTR 6EL 455 KHZ SMD
FL3113 9180468V04 CER FLTR 4EL 455 KHZ SMD
FL3114 9180468V06 CER FLTR 4EL 455 KHZ SMD
J0401 0902636Y02 FLEX CONNECTOR
J0451 0902636Y01 FLEX CONNECTOR
J0501 0986105B01 ACCESSORY CONNECTOR
J0551 0905505Y04 FLEX CONNECTOR
J0552 0905505Y03 FLEX CONNECTOR
J0601 0986165B01 DC POWER CONNECTOR
J3401 0986166B02 RF CONN MINI UHF
L3002 2462587T23 COIL CHIP 470nH
L3031 2462587T24 COIL CHIP 560nH
L3032 2462587T17 COIL CHIP 150nH
L3101 2462587T25 COIL CHIP 620nH
L3111 2462587T25 COIL CHIP 620nH
L3112 2462587T25 COIL CHIP 620nH
Circuit
Ref
Motorola
Part No.
Description
L3124 2462587N68
NU
1uH 3rd overtone crystal
fundamental crystal
L3201 2462587Q42 IND CHIP 390nH 10%
L3231 2462587Q20 IND CHIP 2.2uH 20%
L3301 2462587N44 CHIP IND 18 NH 5%
L3302 2462587N53 CHIP IND 100 nH 5%
L3317 2462587V28 CHIP IND 33 NH 5%
L3318 2462587V34 IND CHIP 100nH 5%
L3331 2462587V32 CHIP IND 68NH 5%
L3332 2462587V15 IND CHIP 100nH 10%
L3333 2462587Q47 IND CHIP 1uH 10%
L3341 2484562T13 MINI-SPRING AW IND
8NH 2%
L3343 2462587N56 COIL CHIP 180nH 5%
L3344 2462587N68 CHIP IND 1 uH 5%
L3345 2462587N68 CHIP IND 1 uH 5%
L3346 2484562T18 MINI-SPRING AW IND
35.5NH 2%
L3351 2462587N68 CHIP IND 1 uH 5%
L3361 2462587N50 CHIP IND 56 nH 5%
L3362 2462587N51 CHIP IND 68 nH 5%
L3363 2462587N50 CHIP IND 56 nH 5%
L3364 2462587N68 CHIP IND 1 uH 5%
L3401 2462587X48 IND CHIP LO-PRO 39nH 5%
L3402 2484657R01 Ferrite Bead
L3403 2462587T13 COIL CHIP 68nH
L3411 2462587T13 COIL CHIP 68nH
L3412 2462587X47 IND CHIP LO-PRO 33.0 N
L3413 2462587X46 IND CHIP LO-PRO 27.0 N
L3414 2460591A01 SQUARE COIL 4.22nH 3T
L3421 2484657R01 Ferrite Bead
L3422 2460591C73 COIL AIRW 16.96nH 10%
5TNS
L3423 2460591B73 SQUARE COIL 12.77nH 10%
L3431 2484657R01 Ferrite Bead
L3432 2460591F77 SQUARE COIL 35.5nH 10%
8T AWG22 U
L3433 2460591B73 SQUARE COIL 12.77nH 10%
L3441 2460591E77 SQUARE COIL 30nH 10% 7T
L3442 2484657R01 Ferrite Bead
L3443 2484657R01 Ferrite Bead
L3444 2460591X03 COIL SQUARE 5 TNS
L3445 2460591X01 COIL SQUARE
L3471 2462587X69 IND CHIP 1.2uH 5%
L3472 2460591X05 COIL SQUARE 48nH 10%
7TNS
L3473 2462587X69 IND CHIP 1.2uH 5%
L3474 2462587N42 CHIP IND 12nH 5%
L3475 2462587N55 CHIP IND 150nH 5%
L3477 2462587X69 IND CHIP 1.2uH 5%
L3491 2460592B01 COIL AW 51nH 4T
Circuit
Ref
Motorola
Part No.
Description
L3492 2460592B01 COIL AW 51nH 4T
L3493 2460592B01 COIL AW 51nH 4T
L3494 2460592B01 COIL AW 51nH 4T
Q3001 4813827A07 NPN SML SIG MMBR9
Q3002 4813824A17 PNP 40V .2A B=100-
Q3021 4805921T02 DUAL ROHM FMC2
Q3101 4813827A07 NPN SML SIG MMBR9
Q3102 4813827A07 NPN SML SIG MMBR9
Q3141 4813824A10 NPN 40V .2A B=50-150
Q3151 4880048M01 NPN DIG 47k/47k
Q3152 4880048M01 NPN DIG 47k/47k
Q3221 4880048M01 NPN DIG 47k/47k
Q3301 4813827A07 NPN SML SIG MMBR9
Q3303 4802245J50 DUAL NPN/PNP UMC5N
Q3304 4805218N63 RF TRANS SOT 323
BFQ67W
Q3421 5105385Y91 LDMOS PWR MODULE
16 CELL
Q3431 4805537W01 MRF5015 MOS1
Q3441 4884411L04 RF PWR TSTR MRF247 75W
Q3471 4880048M01 NPN DIG 47k/47k
Q3472 4805128M27 PNP SOT89 BSR33 LH
Q3501 4813824A17 PNP 40V .2A B=100-
Q3502 4813824A10 NPN 40V .2A B=50-150
R3000 0662057A53 1500 1/16W 5%
R3001 0662057A97 100k 1/16W
R3002 0662057A43 560 1/16W 5%
R3003 0662057A49 1k 1/16W 5%
R3004 0662057A53 1500 1/16W 5%
R3006 0662057A73 10k 1/16W 5%
R3009 0662057A97 100k 1/16W
R3010 0662057A45 680 OHMS 5%
R3011 0662057A65 4700 1/16W 5%
R3012 0662057A49 1k 1/16W 5%
R3013 0662057A61 3300 1/16W 5%
R3014 0662057A18 51 1/16W 5%
R3015 0662057A01 10 1/16W 5%
R3016 0662057A01 10 1/16W 5%
R3018 0662057A33 220 1/16W 5%
R3019 0662057A89 47k 1/16W 5%
R3021 0662057A43 560 1/16W 5%
R3024 0662057A39 390 1/16W 5%
R3025 0662057A53 1500 1/16W 5%
R3026 0662057A73 10k 1/16W 5%
R3027 0662057A73 10k 1/16W 5%
R3028 0662057A39 390 1/16W 5%
R3031 0662057A18 51 1/16W 5%
R3033 0662057B47 0 1/16W
R3101 0662057A75 12k 1/16W 5%
R3102 0662057A01 10 1/16W 5%
R3105 0662057A25 100 1/16W 5%
Circuit
Ref
Motorola
Part No.
Description
R3106 0662057A83 27k 1/16W 5%
R3107 0662057A69 6800 1/16W 5%
R3108 0662057A44 620 OHMS 5%
R3111 0662057A75 12k 1/16W 5%
R3112 0662057A01 10 1/16W 5%
R3113 0662057A37 330 1/16W 5%
R3115 0662057A39 390 1/16W 5%
R3116 0662057A37 330 1/16W 5%
R3117 0662057A83 27k 1/16W 5%
R3118 0662057A69 6800 1/16W 5%
R3123 NU
0662057B47
3rd overtone crystal
0 fundamental crystal
R3124 0662057A49
NU
1K 3rd overtone crystal
fundamental crystal
R3130 0662057A18 51 1/16W 5%
R3132 0662057A77 15k 1/16W 5%
R3133 0662057A71 8200 1/16W 5%
R3134 0662057A73 10k 1/16W 5%
R3135 0662057A51 1200 1/16W 5%
R3141 0662057A39 390 1/16W 5%
R3142 0662057A55 1800 1/16W 5%
R3144 0662057A58 2400 1/16W 5%
R3145 0662057A61 3300 1/16W 5%
R3146 0662057A45 680 OHMS 5%
R3147 0662057A75 12k 1/16W 5%
R3151 0662057A73 10k 1/16W 5%
R3152 0662057A73 10k 1/16W 5%
R3153 0662057A73 10k 1/16W 5%
R3154 0662057A73 10k 1/16W 5%
R3201 0662057A17 47 1/16W 5%
R3203 0662057A17 47 1/16W 5%
R3204 0662057A17 47 1/16W 5%
R3211 0662057B47 0 1/16W
R3221 0662057A39 390 1/16W 5%
R3222 0662057A45 CHIP RES 680 OHMS 5%
R3223 0662057A25 100 1/16W 5%
R3224 0662057A89 47k 1/16W 5%
R3225 0662057A89 47k 1/16W 5%
R3227 0662057A97 100k 1/16W
R3241 0662057A25 100 1/16W 5%
R3242 0662057B47 0 1/16W
R3251 0662057B04 180k 1/16W 5%
R3252 0662057B10 330k 1/16W 5%
R3261 0662057A89 47k 1/16W 5%
R3263 0662057A65 4700 1/16W 5%
R3301 0662057A22 75 1/16W 5%
R3302 0662057A25 100 1/16W 5%
R3303 0662057A57 2200 1/16W 5%
R3304 0662057A49 1k 1/16W 5%
R3308 0662057B47 0 1/16W
R3311 0662057A25 100 1/16W 5%
Circuit
Ref
Motorola
Part No.
Description
