Motorola Pro3100 Detailed Service Manual

UHF Band 1 (403–470 MHz) 25–40 W Bipolar PCB 8480643Z06, Schematics, and Parts Lists Section 9: 4-13
6881091C63-F
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not field replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
†
Replacement boards must be ordered from
RPSO (formerly CCSD and/ or AAD) using the
number shown in the model charts in Section 1.
Boards are not orderable using the 84-prefixed
number.
R3145 0662057A61 3.3K
R3146 0662057A45 680
R3147 0662057A75 12K
R3148 0662057B47 0
R3151 0662057A73 10K
R3152 0662057A73 10K
R3153 0662057A73 10K
R3154 0662057A73 10K
R4001 0662057A97 100K
R4002 0662057A37 330
R4003 0662057A63 3.9K
R4004 0662057A59 2.7K
R4005 0662057A73 10K
R4007 0662057A18 51
R4012 0662057A97 100K
R4013 0662057A35 270
R4014 0662057A01 10
R4016 0662057A61 3.3K
R4018 0662057A61 3.3K
R4022 0662057B47 0
R4051 0662057A18 51
R4052 0662057B47 0
R4060 0662057B10 330K
R4061 0662057A73 10K
R4062 0662057A53 1.5K
R4064 0662057B47 0
R4068 0662057A53 1.5K
R4069 0662057A49 1K
R4070 0662057A39 390
R4071 0662057A73 10K
R4072 0662057A73 10K
R4201 0662057A29 150
R4203 0662057A17 47
R4204 0662057A17 47
R4211 0662057B47 0
R4221 0662057A29 150
R4222 0662057A42 510
R4223 0662057A21 68
R4228 0662057A89 47K
R4241 0662057A33 220
R4251 0662057A87 39K
R4252 0662057A84 30K
R4261 0662057A89 47K
R4263 0662057A25 100
R4301 0662057A67 5.6K
R4302 0662057A73 10K
R4303 0662057A12 30
R4304 0662057A31 180
R4305 0662057A01 10
R4311 0662057A70 7.5K
R4312 0662057A67 5.6K
Circuit
Ref
Motorola
Part No.
Description
R4313 0662057A12 30
R4314 0662057A35 270
R4315 0662057B47 0
R4321 0662057A91 56K
R4322 0662057A73 10K
R4323 0662057A97 100K
R4331 0662057A09 22
R4341 0662057B47 0
R4342 0662057A57 2.2K
R4343 0662057A49 1K
R4344 0662057A01 10
R4346 0662057A73 10K
R4347 0662057B47 0
R4361 0662057A31 180
R4401 0662057A36 300
R4402 0662057A05 15
R4403 0662057A36 300
R4405 0662057A32 200
R4408 0662057A80 20K
R4409 0662057A97 100K
R4412 0662057A67 5.6K
R4415 0662057A25 100
R4416 0662057A25 100
R4421 0680194M01 10
R4422 0611079A69 620
R4423 0611079A69 620
R4424 0611079A69 620
R4425 0611079A69 620
R4427 0662057A73 10K
R4428 0662057A65 4.7K
R4457 0683962T51 120
R4473 0662057A64 4.3K
R4474 0662057A97 100K
R4475 0662057B47 0
R4480 0662057A73 10K
R4482 0662057B09 300K
R4483 0662057A97 100K
R4484 0662057A93 68K
R4485 0662057C53 120
R4486 0662057C53 120
R4487 0662057A97 100K
R4488 0662057A59 2.7K
R4491 0662057A74 11K
R4492 0662057A73 10K
R4495 0680195M18 51
R4496 0680194M23 82
R4497 0680195M18 51
R4501 0662057A67 5.6K
R4502 0662057A93 68K
R4503 0662057A63 3.9K
R4504 0662057A73 10K
Circuit
Ref
Motorola
Part No.
Description
R4506 0662057A73 10K
R4507 0662057A73 10K
R4511 0680194M18 51
R4512 0662057A41 470
R4513 0662057A73 10K
R4514 0662057A61 3.3K
R4600 0662057C19 4.7
R4601 0662057C19 4.7
R4602 0662057C19 4.7
R4631 0662057A49 1K
R4632 0662057A82 24K
SH4301 2602641Y02 SHIELD
SH4302 2602641Y02 SHIELD
T4051 2505515V03 TRANSFORMER 4:1
T4052 2505515V04 TRANSFORMER 5:1
U0101 5102226J56 MICROPROCESSOR
U0111 5102463J64 EEPROM
U0121 5186137B01 IC, FLASH ROM
U0122 5185748L01 SRAM
U0141 5113805A30 REMUX
U0211 5183222M49 IC, QUAD OPAMP
U0221 5185130C53 IC, ASFIC
U0251 5184704M60 IC-CMOS ANALOG
U0271 5109699X01 AUDIO PA
U0301 5109152M01 EEPROM ANALOG
U0331 5186204B01 BUFFER / DRIVER
U0341 5113818A01 LINEAR IC OP-AMP
U0342 5105750U28 IC CMOS SWITCH
U0351 5102463J40 REGULATOR, 3.3V
U0611 5183308X01 ADJUSTABLE VOLTAGE
REGULATOR
U0641 5183308X01 ADJUSTABLE VOLTAGE
REGULATOR
U0651 5113816A07 REGULATOR, 5V
U0652 5113815A02 UNDERVOLT SENSOR
U3101 5186144B01 IC, IF
U3111 5102463J52 QUAD ANALOG SWITCH
U3115 5102463J52 QUAD ANALOG SWITCH
U4201 5185963A27 IC FRACTN
U4211 5185963A33 IC, VOLTAGE REGULATOR
U4301 5105750U54 IC, VCO
U4401 5185130C65 IC LDMOS DRIVER
U4501 5185765B26 IC POWER CONTROL
U4502 5185963A15 IC TEMPERATURE SENSOR
VR0151 4813830A15 DIODE, 5.6V
VR0501 4805656W09 DIODE, ZENER
VR0503 4805656W09 DIODE, ZENER
VR0504 4813830A40 DIODE, ZENER
VR0505 4805656W09 DIODE, ZENER
VR0509 4813830A40 DIODE, ZENER
VR0510 4813830A40 DIODE, ZENER
Circuit
Ref
Motorola
Part No.
Description
VR0537 4813830A15 DIODE, 5.6V
VR0541 4813830A27 DIODE, 14V
VR0601 4813832C77 DIODE
VR0621 4813830A15 DIODE, 5.6V
VR4471 4813830A15 DIODE, 5.6V
VR4473 4813830A15 DIODE, 5.6V
Y0131 4880113R19 CRYSTAL 38.4KHZ
Y3101
4802245J84
4880606B09
2ND OSC XTAL 44.395 MHZ
3rd overtone crystal
fundamental crystal
Y3102 9186145B02 455KHz DISCRIMINATOR
Y4262 4886182B01 TCXO 16.8MHZ
Circuit
Ref
Motorola
Part No.
Description
