VHF (136–174 MHz) 25–45 W LDMOS PCB 8486140B15, Schematics, and Parts Lists Section 11: 4-11
6881091C63-F
D3402 4813833C02 DUAL 70V '5B' COMM CATH
D3451 4882290T02 SI HOT CARRIER *HSM2802*
D3452 4882290T02 SI HOT CARRIER *HSM2802*
D3471 4802482J02 SMD PIN
D3472 4802482J02 SMD PIN
FL3101 9180112R16 44.85 MHZ CRYSTAL FLTR
FL3102 9180112R16 44.85 MHZ CRYSTAL FLTR
FL3111 9180469V03 SMD455KHZ 6 ELEMENT CER
FLTR
FL3112 9180469V06 SMD455KHZ 6 ELEMENT CER
FLTR
FL3113 9180468V04 SMD455KHZ 4 ELEMENT CER
FLTR
FL3114 9180468V06 SMD455KHZ 4 ELEMENT CER
FLTR
J0401 0902636Y02 FLEX CONNECTOR
J0451 0902636Y01 FLEX CONNECTOR
J0501 0986105B01 ACCESSORY CONNECTOR
J0551 0905505Y04 FLEX CONNECTOR
J0552 0905505Y03 FLEX CONNECTOR
J0601 0986165B01 DC POWER CONNECTOR
J3401 0986166B02 RF CONNECTOR (MINI UHF)
L3002 2462587T23 470NH 5% LOW PRO
L3031 2462587T24 INDUCTOR CHIP 560NH 5%
LOW PRO
L3032 2462587T17 150NH 5% LOW PRO
L3101 2462587T25 620NH 5% LOW PRO
L3111 2462587T25 620NH 5% LOW PRO
L3112 2462587T25 620NH 5% LOW PRO
L3124 2462587N68
NU
1uH 3rd overtone crystal
fundamental crystal
L3201 2462587Q42 390NH 10%
L3231 2462587Q20 2,200NH 20%
L3301 2462587N44 18 NH 5%
L3302 2462587N53 100 NH 5%
L3317 2462587V28 33 NH 5%
L3318 2462587V34 100NH 5%
L3331 2462587V32 68NH 5%
L3332 2462587V15 100 NH 10%
L3333 2462587Q47 1000 NH 10%
L3341 2484562T13 COIL SURFACE MNT AIR
WOUND
L3343 2462587N56 180NH 5%
L3344 2462587N68 1000 NH 5%
L3345 2462587N68 1000 NH 5%
L3346 2484562T18 COIL SURFACE MNT AIR
WOUND
L3351 2462587N68 1000 NH 5%
L3361 2462587N50 56 NH 5%
L3362 2462587N51 68 NH 5%
L3363 2462587N50 56 NH 5%
L3364 2462587N68 1000 NH 5%
L3401 2460591A01 COIL AIR WOUND INDUC 4.22
L3402 2484657R01 INDUCTOR BEAD CHIP
L3403 2462587T13 68NH 5% LOW PRO
L3411 2462587T13 68NH 5% LOW PRO
Circuit
Ref
Motorola
Part No.
Description
L3412 2462587N42 12 NH 5%
L3414 2460591A11 COIL AIR WOUND INDUC 7.66
L3421 2484657R01 INDUCTOR BEAD CHIP
L3422 2460591C23 COIL AIR WOUND INDUC 13.85
L3436 2484657R01 INDUCTOR BEAD CHIP
L3437 2460592A01 COIL AW 2 TURN 17 NH
L3443 2485873L01 ENCAPSULATED AIR WOUND
COIL
L3471 2462587N69 1200 NH 5%
L3500 2462587N42 12 NH 5%
L3510 2462587N69 1200 NH 5%
L3511 2485873L05 ENCAPSULATED AIR WOUND
48NH
L3512 2460592B01 COIL AW 4 TURN 51 NH
L3513 2460592B01 COIL AW 4 TURN 51 NH
L3514 2460592B01 COIL AW 4 TURN 51 NH
L3515 2485873L05 ENCAPSULATED AIR WOUND
48NH
M3421 2686201B01 HEAT SPREADER WM
Q3001 4813827A07 NPN SML SIG MMBR941LT1 7Y
Q3002 4813824A17 XSTR PNP40V .2A
GENPB=100-300
Q3021 4805921T02 XISTOR FMC2 RH
Q3101 4813827A07 NPN SML SIG MMBR941LT1 7Y
Q3102 4813827A07 NPN SML SIG MMBR941LT1 7Y
Q3141 4880214G02 MMBT3904
Q3151 4880048M01 NPN DIG 47K/47K
Q3152 4880048M01 NPN DIG 47K/47K
Q3221 4880048M01 NPN DIG 47K/47K
Q3301 4813827A07 NPN SML SIG MMBR941LT1 7Y
Q3303 4809939C05 DUAL NPN/PNP UMH 5
Q3304 4805218N63 RF TRANS SOT 323 BFQ67W
Q3411 4805921T02 XISTOR FMC2 RH
Q3421* 4886212B01 LDMOS PWR MRF1518
Q3422 4880048M01 NPN DIG 47K/47K
Q3441* 4886136B01 LDMOS SMT 55W 520MHZ 12V
Q3442 4880048M01 NPN DIG 47K/47K
Q3471 4880048M01 NPN DIG 47K/47K
Q3472 4805128M27 SOT TRANS
R3000 0662057A53 1500 OHMS 5%
R3001 0662057A97 100K OHM 5%
R3002 0662057A43 560 OHMS 5%
R3003 0662057A49 1000 OHMS 5%
R3004 0662057A53 1500 OHMS 5%
R3006 0662057A73 10K OHMS 5%
R3009 0662057A97 100K OHM 5%
R3010 0662057A45 680 OHMS 5%
R3011 0662057A65 4700 OHMS 5%
R3012 0662057A49 1000 OHMS 5%
R3013 0662057A61 3300 OHMS 5%
R3014 0662057A18 51 OHMS 5%
R3015 0662057A01 10 OHMS 5%
R3016 0662057A01 10 OHMS 5%
R3018 0662057A33 220 OHMS 5%
R3019 0662057A89 47K OHMS 5%
R3021 0662057A43 560 OHMS 5%
Circuit
Ref
Motorola
Part No.
Description
R3024 0662057A39 390 OHMS 5%
R3025 0662057A53 1500 OHMS 5%
R3026 0662057A73 10K OHMS 5%
R3027 0662057A73 10K OHMS 5%
R3028 0662057A39 390 OHMS 5%
R3031 0662057A18 51 OHMS 5%
R3033 0662057B47 0 OHMS +.050 OHMS
R3101 0662057A75 12K OHMS 5%
R3102 0662057A01 10 OHMS 5%
R3105 0662057A25 100 OHMS 5%
R3106 0662057A83 27K OHMS 5%
R3107 0662057A69 6800 OHM 5 1/8W
R3108 0662057A44 620 OHMS 5%
R3111 0662057A75 12K OHMS 5%
R3112 0662057A01 10 OHMS 5%
R3113 0662057A37 330 OHMS 5%
R3115 0662057A39 390 OHMS 5%
R3116 0662057A37 330 OHMS 5%
R3117 0662057A83 27K OHMS 5%
R3118 0662057A69 6800 OHM 5 1/8W
R3123 NU
0662057B47
3rd overtone crystal
0 fundamental crystal
R3124 0662057A49
NU
1K 3rd overtone crystal
fundamental crystal
R3130 0662057A18 51 OHMS 5%
R3132 0662057A77 15K OHMS 5%
R3133 0662057A71 8200 OHMS 5%
R3134 0662057A73 10K OHMS 5%
R3135 0662057A51 1200 OHMS 5%
R3141 0662057A39 390 OHMS 5%
R3142 0662057A55 1800 OHM 5%
R3144 0662057A58 2400 OHMS 5%
R3145 0662057A61 3300 OHMS 5%
R3146 0662057A45 680 OHMS 5%
R3147 0662057A75 12K OHMS 5%
R3151 0662057A73 10K OHMS 5%
R3152 0662057A73 10K OHMS 5%
R3153 0662057A73 10K OHMS 5%
R3154 0662057A73 10K OHMS 5%
R3201 0662057A17 47 OHMS 5%
R3203 0662057A17 47 OHMS 5%
R3204 0662057A17 47 OHMS 5%
R3211 0662057B47 0 OHMS +.050 OHMS
R3221 0662057A39 390 OHMS 5%
R3222 0662057A45 680 OHMS 5%
R3223 0662057A25 100 OHMS 5%
R3224 0662057A89 47K OHMS 5%
R3225 0662057A89 47K OHMS 5%
R3227 0662057A97 100K OHM 5%
R3241 0662057A25 100 OHMS 5%
R3242 0662057B47 0 OHMS +.050 OHMS
R3251 0662057B04 180K OHMS 5%
R3252 0662057B10 330K OHMS 5%
R3261 0662057A89 47K OHMS 5%
R3263 0662057A65 4700 OHMS 5%
R3265 0662057B47 0 OHMS +.050 OHMS
Circuit
Ref
Motorola
Part No.
Description
R3301 0662057A22 75 OHMS 5%
R3302 0662057A25 100 OHMS 5%
R3303 0662057A57 2200 OHMS 5%
R3304 0662057A49 1000 OHMS 5%
R3308 0662057B47 0 OHMS +.050 OHMS
R3311 0662057A25 100 OHMS 5%
R3316 0662057B47 0 OHMS +.050 OHMS
R3318 0662057A09 22 OHMS 5%
R3321 0662057A73 10K OHMS 5%
R3323 0662057A49 1000 OHMS 5%
R3331 0662057A17 47 OHMS 5%
R3335 0662057A13 33 OHMS 5%
R3336 0662057A77 15K OHMS 5%
R3341 0662057A33 220 OHMS 5%
R3342 0662057A15 39 OHMS 5%
R3343 0662057A25 100 OHMS 5%
R3351 0662057A80 20K OHMS 5%
R3352 0662057A75 12K OHMS 5%
R3353 0662057A97 100K OHM 5%
R3354 0662057B02 150K OHMS 5%
R3355 0662057A80 20K OHMS 5%
R3356 0662057A75 12K OHMS 5%
R3361 0662057A33 220 OHMS 5%
R3362 0662057A17 47 OHMS 5%
R3364 0662057A89 47K OHMS 5%
R3400 0662057A41 470 OHMS 5%
R3401 0662057A36 300 OHMS 5%
R3402 0662057A05 15 OHMS 5%
R3403 0662057A36 300 OHMS 5%
R3404 0662057A89 47K OHMS 5%
R3405 0662057A25 100 OHMS 5%
R3406 0662057A97 100K OHM 5%
R3412 0662057A67 5600 OHMS 5%
R3413 0662057A61 3300 OHMS 5%
R3414 0683962T51 120 5-1
R3415 0662057A14 36 OHM 5 1/8W
R3416 0662057A14 36 OHM 5 1/8W
R3417 0662057A49 1000 OHMS 5%
R3418 0662057A81 22K OHMS 5%
R3421 0662057A87 39K OHMS 5%
R3422 0662057A57 2200 OHMS 5%
R3423 0662057A87 39K OHMS 5%
R3424 0662057C13 2.7 OHMS 5%
R3425 0662057C13 2.7 OHMS 5%
R3426 0662057C13 2.7 OHMS 5%
R3427 0662057C13 2.7 OHMS 5%
R3428 0662057A58 2400 OHMS 5%
R3431 0680194M18 51 OHMS 5% 1W
R3432 0680194M18 51 OHMS 5% 1W
R3441 0662057A87 39K OHMS 5%
R3442 0662057A57 2200 OHMS 5%
R3443 0662057A87 39K OHMS 5%
R3444 0662057C13 2.7 OHMS 5%
R3445 0662057A58 2400 OHMS 5%
R3446 0662057B47 0 OHMS +.050 OHMS
R3450 0683962T51 120 5-1
Circuit
Ref
Motorola
Part No.
Description
