Motorola Pro3100 Detailed Service Manual

Section 12: 4-12 UHF Band 1 (403–470 MHz) 25–40 W LDMOS PCB 8486127Z01, Schematics, and Parts Lists
6881091C63-F
J0551 0905505Y04 FLEX CONNECTOR
J0552 0905505Y03 FLEX CONNECTOR
J0601 0986165B01 DC POWER CONNECTOR
J4401 0986166B02 RF CONNECTOR (MINI UHF)
L3101 2462587T25 620nH
L3111 2462587T25 620nH
L3112 2462587T25 620nH
L3124 2462587N68
NU
1uH 3rd overtone crystal
fundamental crystal
L4003 2462587T23 470nH
L4006 2462587V24 15nH
L4008 2462587T23 470nH
L4051 2462587T17 150nH
L4053 2462587N46 27nH
L4054 2462587N43 15nH
L4201 2462587Q42 390nH
L4221 2462587P25 12uH
L4231 2462587Q20 2.2uH
L4301 2462587T22 390nH
L4302 2462587T22 390nH
L4303 2460593C01 RESONATOR
L4304 2462587T22 390nH
L4305 2462587T22 390nH
L4311 2462587T22 390nH
L4312 2460593C01 RESONATOR
L4313 2462587T22 390nH
L4331 2462587T09 33nH
L4333 2462587T22 390nH
L4361 2462587T09 33nH
L4362 2462587T09 33nH
L4371 2462587T13 68nH
L4401 2460591B04 11.03nH
L4402 2484657R01 FERRITE BEAD
L4403 2462587T22 390nH
L4411 2462587T22 390nH
L4421 2484657R01 FERRITE BEAD
L4436 2484657R01 FERRITE BEAD
L4437 2460592A01 17nH
L4438 2460592A01 17nH
L4472 2460592A01 17nH
L4473 2460591N36 43.67nH
L4489 2460591B77 13.9nH
L4490 2460591B77 13.9nH
L4491 2460592A01 17nH
L4492 2460592A01 17nH
L4493 2460592A01 17nH
L4541 2484657R01 FERRITE BEAD
L4543 2460591C23 13.85nH
M3421 2686201B01 HEAT SPREADER
Q0110 4880048M01 NPN
Q0151 4880048M01 NPN
Q0171 4880048M01 NPN
Circuit
Ref
Motorola
Part No.
Description
Q0173 4880052M01 NPN DARLINGTON
Q0177 4880048M01 NPN
Q0181 4880048M01 NPN
Q0183 4880048M01 NPN
Q0185 4880048M01 NPN
Q0271 4880214G02 NPN
Q0641 4880048M01 NPN
Q0661 4805921T02 DUAL NPN/PNP
Q0662 4880214G02 NPN
Q0663 4880048M01 NPN
Q0681 4880052M01 NPN DARLINGTON
Q3101 4813827A07 NPN
Q3102 4813827A07 NPN
Q3141 4880214G02 NPN
Q3151 4880048M01 NPN
Q3152 4880048M01 NPN
Q4002 4813824A17 PNP
Q4003 4813827A07 NPN
Q4004 4805921T02 DUAL NPN/PNP
Q4221 4880048M01 NPN
Q4301 4805218N63 DIODE DUAL SCHOTTKY
Q4332 4813827A07 NPN
Q4333 4809939C05 DUAL NPN/PNP
Q4421 4886212B01 POWER TRANSISTOR -
MRF1518
Q4441 4813828C32 POWER TRANSISTOR -
MRF1570
Q4471 4880048M01 NPN
Q4472 4805128M27 PNP
Q4473 4880214G02 NPN
R0101 0662057A73 10K
R0102 0662057A65 4.7K
R0103 0662057A01 10
R0104 0662057A73 10K
R0106 0662057B47 0
R0108 0662057A57 2.2K
R0111 0662057B47 0
R0113 0662057A73 10K
R0114 0662057A73 10K
R0115 0662057A73 10K
R0117 0662057A63 3.9K
R0121 0662057A97 100K
R0131 0662057B46 10M
R0132 0662057B10 330K
R0151 0662057A82 24K
R0152 0662057A82 24K
R0170 0662057A73 10K
R0171 0662057A65 4.7K
R0172 0662057A73 10K
R0173 0662057A65 4.7K
R0174 0662057A73 10K
R0175 0662057A73 10K
Circuit
Ref
Motorola
Part No.
Description
R0176 0662057A84 30K
R0177 0662057A65 4.7K
R0178 0662057A89 47K
R0179 0662057A89 47K
R0181 0662057A65 4.7K
R0182 0662057A89 47K
R0183 0662057A65 4.7K
R0184 0662057A89 47K
R0185 0662057A65 4.7K
R0186 0662057A89 47K
R0201 0662057A25 100
R0202 0662057A43 560
R0203 0662057A25 100
R0204 0662057A43 560
R0205 0662057A73 10K
R0206 0662057A73 10K
R0207 0662057A57 2.2K
R0208 0662057A57 2.2K
R0211 0660076E70 7.5K
R0212 0660076E70 7.5K
R0221 0662057A82 24K
R0222 0662057A82 24K
R0223 0662057A84 30K
R0224 0662057A71 8.2K
R0228 0662057B47 0
R0229 0662057A01 10
R0241 0662057A89 47K
R0242 0662057B47 0
R0251 0662057A89 47K
R0252 0662057A91 56K
R0253 0662057A97 100K
R0254 0662057A73 10K
R0255 0662057A73 10K
R0256 0662057A97 100K
R0257 0662057A57 2.2K
R0261 0662057A73 10K
R0262 0662057B08 270K
R0265 0662057A82 24K
R0267 0662057A89 47K
R0268 0662057A73 10K
R0269 0662057A41 470
R0273 0662057A82 24K
R0275 0662057A73 10K
R0276 0662057A77 15K
R0323 0662057A79 18K
R0324 0662057A79 18K
R0331 0662057A73 10K
R0332 0662057A73 10K
R0333 0662057A73 10K
R0335 0662057B02 150K
R0341 0662057A73 10K
R0342 0662057A55 1.8K
Circuit
Ref
Motorola
Part No.
Description
R0343 0662057B47 0
R0344 0662057A91 56K
R0345 0662057A66 5.1K
R0346 0662057A89 47K
R0347 0662057A89 47K
R0401 0662057A33 220
R0407 0662057M26 10
R0408 0662057A25 100
R0409 0662057M26 10
R0412 0662057B47 0
R0441 0662057B47 0
R0442 0662057A49 1K
R0467 0662057M26 10
R0468 0662057A97 100K
R0481 0662057B47 0
R0482 0662057B47 0
R0508 0662057A41 470
R0509 0662057B47 0
R0510 0662057A65 4.7K
R0511 0662057A97 100K
R0512 0662057A77 15K
R0525 0662057A97 100K
R0529 0662057A89 47K
R0530 0662057A81 22K
R0531 0662057A43 560
R0533 0662057B47 0
R0535 0662057A49 1K
R0537 0662057A33 220
R0538 0662057A33 220
R0539 0662057A65 4.7K
R0541 0662057A83 27K
R0543 0662057A97 100K
R0555 0662057A25 100
R0556 0662057A25 100
R0591 0662057A82 24K
R0592 0662057A01 10
R0593 0662057A97 100K
R0611 0662057A91 56K
R0612 0662057A65 4.7K
R0621 0662057A82 24K
R0641 0662057A73 10K
R0642 0660076E70 7.5K
R0643 0660076E51 1.2K
R0651 0662057A01 10
R0652 0662057A01 10
R0661 0662057A49 1K
R0662 0662057B02 150K
R0671 0662057A84 30K
R0672 0662057A73 10K
R0681 0662057A79 18K
R0682 0662057A93 68K
R3101 0662057A75 12K
Circuit
Ref
Motorola
Part No.
Description
