Motorola Pro3100 Detailed Service Manual

Technical Specifications Section 13: 1-3
6881091C63-F
*Availability subject to the laws and regulations of individual countries.
Transmitter UHF
*Frequencies – Full Bandsplit
UHF 450–512 MHz (CDM)
UHF 450
–520 MHz (PRO)
Channel Spacing 12.5/20/25 kHz
Frequency Stability
(-30°C to +60°C, +25° Ref.)
±1.5 ppm
±2.0 ppm
Power 25-40 W
Modulation Limiting
±2.5 @ 12.5 kHz
±4.0 @ 20 kHz
±5.0 @ 25 kHz
FM Hum & Noise
-40 dB @ 12.5 kHz
-45 dB @ 20/25 kHz
Conducted/Radiated Emission
-36 dBm <1 GHz
-30 dBm >1 GHz
Adjacent Channel Power
-60 dB @ 12.5 kHz
-70 dB @ 25 kHz
Audio Response
(300
– 3000 Hz @ 20/25 kHz)
(300
– 2550 Hz @ 12.5 kHz)
+1 to -3 dB TIA/EIA box
Audio Distortion
@1000 Hz, 60%
Rated Maximum Deviation
<3% typical
Receiver UHF
*Frequencies – Full Bandsplit
UHF 450–512 MHz (CDM)
UHF 450
–520 MHz (PRO)
Channel Spacing 12.5/20/25 kHz
Sensitivity (12 dB SINAD) 0.30 µV (0.22 µV typical)
Intermodulation
>65 dB (ETS)
75 dB (TIA)
Adjacent Channel Selectivity
65 dB @ 12.5 kHz
70 dB @ 20 kHz
75 dB @ 25 kHz
Spurious Rejection
70 dB @ 12.5 kHz
75 dB @ 20/25 kHz
Rated Audio
3 W Internal
7.5 W External
13 W External
Audio Distortion @ Rated Audio <3% typical
Hum & Noise
-40 dB @ 12.5 kHz
-45 dB @ 20/25 kHz
Audio Response
(300
– 3000 Hz @ 20/25 kHz)
(300
– 2550 Hz @ 12.5 kHz)
+1 to -3 dB TIA/EIA box
Conducted Spurious Emission
-57 dBm <1 GHz
-47 dBm >1 GHz

Motorola Pro3100 Specifications

General

Brand	Motorola
Model	Pro3100
Category	Two-Way Radio
Language	English
