Motorola Pro3100 Detailed Service Manual

Section 13: 4-12 UHF Band 2 (450–512/520 MHz) 25–40 W LDMOS PCB 8486250Z02, Schematics, and Parts Lists
6881091C63-F
L5053 2462587N43 15nH
L5054 2462587N43 15nH
L5201 2462587Q42 390nH
L5221 2462587P25 12uH
L5231 2462587Q20 2.2uH
L5301 2462587T13 68nH
L5302 2462587T19 220nH
L5303 2460593C03 RESONATOR
L5304 2462587T22 390nH
L5305 2462587T22 390nH
L5311 2462587T22 390nH
L5312 2460593C03 RESONATOR
L5313 2462587T22 390nH
L5331 2462587T09 33nH
L5333 2462587T22 390nH
L5361 2462587T22 390nH
L5362 2462587T38 22nH
L5371 2462587T13 68nH
L5401 2460591B04 11.03nH
L5402 2484657R01 FERRITE BEAD
L5403 2462587T22 390nH
L5411 2462587T22 390nH
L5421 2484657R01 FERRITE BEAD
L5436 2484657R01 FERRITE BEAD
L5437 2460592A01 17nH
L5438 2460592A01 17nH
L5472 2460592A01 17nH
L5473 2460591N36 43.67nH
L5489 2460591A01 4.22nH
L5490 2460591A01 4.22nH
L5491 2460592A01 17nH
L5492 2460592A01 17nH
L5493 2460592A01 17nH
L5541 2484657R01 FERRITE BEAD
L5543 2460591A01 4.22nH
M3421 2686201B01 HEAT SPREADER
Q0110 4880048M01 NPN
Q0151 4880048M01 NPN
Q0171 4880048M01 NPN
Q0173 4880052M01 NPN DARLINGTON
Q0177 4880048M01 NPN
Q0181 4880048M01 NPN
Q0183 4880048M01 NPN
Q0185 4880048M01 NPN
Q0271 4880214G02 NPN
Q0641 4880048M01 NPN
Q0661 4805921T02 DUAL NPN/PNP
Q0662 4880214G02 NPN
Q0663 4880048M01 NPN
Q0681 4880052M01 NPN DARLINGTON
Q3101 4813827A07 NPN
Circuit
Ref
Motorola
Part No.
Description
Q3102 4813827A07 NPN
Q3141 4880214G02 NPN
Q3151 4880048M01 NPN
Q3152 4880048M01 NPN
Q5001 4813827A07 NPN
Q5002 4813824A17 PNP
Q5003 4813827A07 NPN
Q5004 4805921T02 DUAL NPN/PNP
Q5221 4880048M01 NPN
Q5301 4805218N63 DIODE DUAL SCHOTTKY
Q5311 4805218N63 DIODE DUAL SCHOTTKY
Q5332 4813827A07 NPN
Q5333 4809939C05 DUAL NPN/PNP
Q5421 4886212B01 POWER TRANSISTOR -
MRF1518
Q5441 4813828C32 POWER TRANSISTOR -
MRF1570
Q5471 4880048M01 NPN
Q5472 4805128M27 PNP
Q5473 4880214G02 NPN
R0101 0662057A73 10K
R0102 0662057A65 4.7K
R0103 0662057A01 10
R0104 0662057A73 10K
R0105 0662057A97 100K
R0108 0662057A57 2.2K
R0111 0662057B47 0
R0113 0662057A73 10K
R0114 0662057A73 10K
R0115 0662057A73 10K
R0117 0662057A63 3.9K
R0121 0662057A97 100K
R0131 0662057B46 10M
R0132 0662057B10 330K
R0151 0662057A82 24K
R0152 0662057A82 24K
R0170 0662057A73 10K
R0171 0662057A65 4.7K
R0172 0662057A73 10K
R0173 0662057A65 4.7K
R0174 0662057A73 10K
R0175 0662057A73 10K
R0176 0662057A84 30K
R0177 0662057A65 4.7K
R0178 0662057A89 47K
R0179 0662057A89 47K
R0181 0662057A65 4.7K
R0182 0662057A89 47K
R0183 0662057A65 4.7K
R0184 0662057A89 47K
R0185 0662057A65 4.7K
Circuit
Ref
Motorola
Part No.
Description
R0186 0662057A89 47K
R0201 0662057A25 100
R0202 0662057A43 560
R0203 0662057A25 100
R0204 0662057A43 560
R0205 0662057A73 10K
R0206 0662057A73 10K
R0207 0662057A57 2.2K
R0208 0662057A57 2.2K
R0211 0660076E70 7.5K
R0212 0660076E70 7.5K
R0221 0662057A82 24K
R0222 0662057A82 24K
R0223 0662057A84 30K
R0224 0662057A71 8.2K
R0228 0662057B47 0
R0229 0662057A01 10
R0241 0662057A89 47K
R0242 0662057B47 0
R0251 0662057A89 47K
R0252 0662057A91 56K
R0253 0662057A97 100K
R0254 0662057A73 10K
R0255 0662057A73 10K
R0256 0662057A97 100K
R0257 0662057A57 2.2K
R0261 0662057A73 10K
R0262 0662057B08 270K
R0265 0662057A82 24K
R0267 0662057A89 47K
R0268 0662057A73 10K
R0269 0662057A41 470
R0273 0662057A82 24K
R0275 0662057A73 10K
R0276 0662057A77 15K
R0323 0662057A79 18K
R0324 0662057A79 18K
R0331 0662057A73 10K
R0332 0662057A73 10K
R0333 0662057A73 10K
R0335 0662057B02 150K
R0341 0662057A73 10K
R0342 0662057A55 1.8K
R0343 0662057B47 0
R0344 0662057A91 56K
R0345 0662057A66 5.1K
R0346 0662057A89 47K
R0347 0662057A89 47K
R0401 0662057A33 220
R0407 0662057M26 10
R0408 0662057A25 100
Circuit
Ref
Motorola
Part No.
Description
R0409 0662057M26 10
R0412 0662057B47 0
R0441 0662057B47 0
R0442 0662057A49 1K
R0467 0662057M26 10
R0468 0662057A97 100K
R0481 0662057B47 0
R0482 0662057B47 0
R0508 0662057A41 470
R0509 0662057B47 0
R0510 0662057A65 4.7K
R0511 0662057A97 100K
R0512 0662057A77 15K
R0525 0662057A97 100K
R0529 0662057A89 47K
R0530 0662057A81 22K
R0531 0662057A43 560
R0533 0662057B47 0
R0535 0662057A49 1K
R0537 0662057A33 220
R0538 0662057A33 220
R0539 0662057A65 4.7K
R0541 0662057A83 27K
R0543 0662057A97 100K
R0555 0662057A25 100
R0556 0662057A25 100
R0591 0662057A82 24K
R0592 0662057A01 10
R0593 0662057A97 100K
R0611 0662057A91 56K
R0612 0662057A65 4.7K
R0621 0662057A82 24K
R0641 0662057A73 10K
R0642 0660076E70 7.5K
R0643 0660076E51 1.2K
R0651 0662057A01 10
R0652 0662057A01 10
R0661 0662057A49 1K
R0662 0662057B02 150K
R0671 0662057A84 30K
R0672 0662057A73 10K
R0681 0662057A79 18K
R0682 0662057A93 68K
R3101 0662057A75 12K
R3102 0662057A01 10
R3105 0662057A25 100
R3106 0662057A83 27K
R3107 0662057A69 6.8K
R3108 0662057A44 620
R3111 0662057A75 12K
R3112 0662057A01 10
Circuit
Ref
Motorola
Part No.
Description
