Motorola Pro3100 Detailed Service Manual

Section 3: 3-2 Allocation of Schematics and Circuit Boards
6881091C63-F
Table 3-3 Controller T6/T7/T9 Diagrams and Parts Lists
Controller T6/T7/T9 used on PCB:
T6/7 on 8486206B06 LB1, 40–60 W
T6/7 on 8486207B05 LB2, 40–60 W
T6/7 on 8486140B12 VHF, 25–45 W
T6/7 on 8480643Z06 UHF B1, 25–40 W
T6/7 on 8480645Z04 UHF B2, 25–40 W
T7 on 8486172B07 VHF, 1–25 W
T7 on 8485670Z02 UHF B1, 1–25 W
T9 on 8486172B08 VHF, 1–25 W
T9 on 8486140B13 VHF, 25–45 W
T9 on 8485670Z03 UHF B1, 1–25 W
T9 on 8485671Z03 UHF B2, 1–25 W
T9 on 8485908Z02 LB3, 40–60 W
SCHEMATICS
T6/7/9/11 Controller Overall
T6/7/9 Supply Voltage
T6/7/9 Audio
T6 I/O
T7 I/O
T9 I/O
T6/7 Microprocessor
T9 Microprocessor
T6/7/9 Voice Storage (if fitted)
Page:
3: 3-20
3: 3-21
3: 3-22
3: 3-23
3: 3-24
3: 3-25
3: 3-26
3: 3-27
3: 3-28
T6/7 Parts List
T9 Parts List
3: 3-29
3: 3-31
Table 3-4 Controller T11 Diagrams and Parts Lists
Controller T11 used on PCB:
8486206B08 LB1, 40–60 W
8486207B07 LB2, 40–60 W
8485908Z04 LB3, 40–60 W
SCHEMATICS
Controller Overall
Supply Voltage
Audio
I/O
Microprocessor
Page:
3: 3-20
3: 3-33
3: 3-34
3: 3-35
3: 3-36
Parts List 3: 3-37
Table 3-5 Controller T12 Diagrams and Parts Lists
Controller T12 used on PCB:
8486140B15 VHF, 25–45 W LDMOS
8471234L02 VHF, 25–45 W LDMOS
8486127Z01 UHF B1, 25–40 W LDMOS
8471223L02 UHF B1, 25–45 W LDMOS
8486250Z02 UHF B2, 25–40 W LDMOS
SCHEMATICS
Controller Overall
Supply Voltage
Audio
I/O
Microprocessor
Page:
3: 3-39
3: 3-40
3: 3-41
3: 3-42
3: 3-43
