Motorola Pro3100 Detailed Service Manual

Controller T2 Schematics and Parts Lists Section 3: 3-11
6881091C63-F
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components which are not field-replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
R0102 0662057A65 4.7K
R0104 0662057A73 10K
R0105 0662057A97 100K
R0108 0662057A57 2.2K
R0111 0662057B47 0
R0113 0662057A73 10K
R0114 0662057A73 10K
R0115 0662057A73 10K
R0117 0662057A63 3.9K
R0121 0662057A97 100K
R0124 0662057B47 0
R0125 0662057A83 27K
R0126 0662057A83 27K
R0127 0662057B47 0
R0128 0662057B47 0
R0131 0662057B46 10MEG
R0132 0662057B10 330K
R0151 0662057A82 24K
R0152 0662057A82 24K
R0170 0662057A73 10K
R0171 0662057A65 4.7K
R0172 0662057A73 10K
R0173 0662057A65 4.7K
R0174 0662057A73 10K
R0175 0662057A73 10K
R0176 0662057A84 30K
R0177 0662057A65 4.7K
R0178 0662057A89 47K
R0179 0662057A89 47K
R0181 0662057A65 4.7K
R0182 0662057A89 47K
R0183 0662057A65 4.7K
R0184 0662057A89 47K
R0185 0662057A65 4.7K
R0186 0662057A89 47K
R0201 0662057A25 100
R0202 0662057A43 560
R0204 0662057A43 560
Circuit
Ref
Motorola
Part No.
Description
R0205 0662057A73 10K
R0206 0662057A73 10K
R0207 0662057A57 2.2K
R0208 0662057A57 2.2K
R0211 0660076E70 7.5K
R0212 0660076E70 7.5K
R0221 0662057A82 24K
R0222 0662057A82 24K
R0223 0662057A84 30K
R0224 0662057A71 8.2K
R0226 0662057B22 1MEG
R0227 0662057B22 1MEG
R0241 0662057A89 47K
R0242 0662057B47 0
R0251 0662057A89 47K
R0252 0662057A91 56K
R0253 0662057A97 100K
R0261 0662057A73 10K
R0262 0662057A97 100K
R0265 0662057A82 24K
R0267 0662057A89 47K
R0268 0662057A73 10K
R0269 0662057A41 470
R0273 0662057A82 24K
R0275 0662057A73 10K
R0276 0662057A77 15K
R0401 0662057A33 220
R0407 0662057M26 10
R0408 0662057A25 100
R0409 0662057M26 10
R0467 0662057M26 10
R0468 0662057M26 10
R0481 0662057B47 0
R0482 0662057B47 0
R0510 0662057A65 4.7K
R0511 0662057A97 100K
R0512 0662057A77 15K
R0523 0662057A33 220
Circuit
Ref
Motorola
Part No.
Description
R0524 0662057A33 220
R0525 0662057A97 100K
R0529 0662057A89 47K
R0530 0662057B47 0
R0531 0662057A43 560
R0533 0662057B47 0
R0535 0662057A49 1K
R0537 0662057A33 220
R0538 0662057A33 220
R0539 0662057A65 4.7K
R0541 0662057A83 27K
R0591 0662057A82 24K
R0592 0662057A01 10
R0611 0662057A91 56K
R0612 0662057A65 4.7K
R0621 0662057A82 24K
R0641 0662057A73 10K
R0642 0660076E70 7.5K
R0643 0660076E51 1.2K
R0651 0662057A01 10
R0652 0662057A01 10
R0661 0662057A49 1K
R0662 0662057B02 150K
R0671 0662057A84 30K
R0672 0662057A73 10K
R0681 0662057A79 18K
R0682 0662057A93 68K
U0101 5102226J56 MC68HC11FL0 100 PIN
* U0111 5102463J64 16KX8 SPI SERIAL
EEPROM
* U0121 5186137B01 512KX8 IC 120NS
U0122 5185963A21 32KX8 SRAM
U0125 5105625U34 IC CMOS ACIA SSOP
U0141 5113805A30 MC74HC138A DCDR/
DEMUX
U0211 5183222M49 MC3403 IC AMP
U0221 5185963A53 IC ASFIC CMP 48 PIN
U0251 5113806A20 MC14053B MUX/DEMUX,
TRIPLE 2CH
Circuit
Ref
Motorola
Part No.
Description
U0271 5109699X01 TDA1519C AUDIO PA
U0611 5183308X01 LM2941 TO DRPOUT
RGTR
U0641 5183308X01 LM2941 TO DRPOUT
RGTR
U0651 5113816A07 MC78M05BDTRK REG 5V
POS 500 MA
U0652 5113815A02 MC33064 UNDERVOLT
SENSING
U0653 4805921T02 NU
VR0151 4813830A15 5.6V
VR0501 4805656W09 20V
VR0503 4805656W09 20V
VR0504 4813830A40 33V
VR0505 4805656W09 20V
VR0509 4813830A40 33V
VR0510 4813830A40 33V
VR0521 4813830A15 5.6V
VR0522 4813830A15 5.6V
VR0537 4813830A15 5.6V
VR0541 4813830A27 14V
VR0601 4813832C77 24V
VR0621 4813830A15 5.6V
Y0131 4880113R19 XTAL
Circuit
Ref
Motorola
Part No.
Description
