Annotation Description
3 Display
Provides alphanumeric text and images within 65,536 colors and 640 x 480 pixels
with backlighting and scalable fonts.
NOTE: Before using your radio for the first time, remove the plastic lens
protector from the display.
4 Soft key
Press Upper or Lower Soft key, to select the option that appears on the screen
next to it.
5 On/Off/End/Home Key
• Press and hold to turn on/off your radio.
•
Press to end calls.
• Press to return to the home screen.
6 Navigation key
Press Up, Down, Left, or Right Navigation key for list scrolling, while moving
around the menu hierarchy, or for alphanumeric text editing.
From the home screen, press to activate one of the following:
• Down Navigation key – enters Recent Calls menu item.
• Up Navigation key – changes My Groups talkgroup folder.
• Left and Right Navigation key – toggles through the talkgroups.
7 Alphanumeric Keypad
Use the keypad to enter alphanumeric characters for dialing, contact entries, and
text messages.
8 LED Status Indicator
9 Mobile Microphone Port
Provides connection for accessories such as a fist microphone with PTT.
10 Menu key
Press to enter the main menu and the context-sensitive menu.
11 Send key
• Press to initiate or answer duplex calls, or send messages.
• Press in home screen to enter Recent Dialed Calls.
12 FUNCTION key 1
By default:
• Short press – activates/deactivates the horn and lights feature.
• Long press – adjusts the backlight.
13 FUNCTION key 2
By default:
• Short press – turns the speaker on/off.
• Long press – activates/deactivates the screen saver.
14 FUNCTION key 3
68015000180-MR
Chapter 2 : Getting Started
22
