Level 1 and 2 Service Manual Tools and Test Equipment
Tools and Test Equipment
The following table lists tools and test equipment recommended for disassembly
and reassembly of V235 telephones. Use either the listed items or equivalents.
Table 1. General Test Equipment and Tools
Motorola Part Number
1
Description Application
RSX4043-A Torque Driver Used to remove and replace screws
—
Torque Driver Bit T-6 Plus, Apex 440-
6IP Torx Plus or equivalent Used with torque driver
See Table 7
Rapid Charger
Used to charge battery and to power
device
0180386A82
Antistatic Mat Kit (includes 66-
80387A95 antistatic mat, 66-80334B36
ground cord, and 42-80385A59 wrist
band)
Provides protection from damage to
device caused by electrostatic
discharge (ESD)
6680388B67
Disassembly tool, plastic with flat and
pointed ends (manual opening tool)
Used during assembly/disassembly of
device
6680388B01 Tweezers, plastic Used during assembly/disassembly
— Digital Multimeter, HP34401A
2
Used to measure battery voltage
1. To order in North America, contact Motorola Aftermarket and Accessories Division (AAD) at (800) 422-4210 or
FAX (800) 622-6210; Internationally, AAD can be reached by calling (847) 538-8023 or faxing (847) 576-3023.
2. Not available from Motorola. To order, contact Hewlett Packard at (800) 452-4844.
1 and 2
V235 GSM
6809495A43-C
