Motorola V235

6809495A43-C April 03, 2006 49
Level 1 and 2 Service Manual Troubleshooting
Exploded View Parts List
Table 5. Exploded View Parts List
Item
Number
Motorola Part
Number
Description
1 0170388E04 Flip front housing assembly, silver
2 0171285A02 Flip cover, silver
3 1571202A02 Cover hinge, silver
4 8471229A01 Ta pe
5 0370303D02 Screw, Flip M1.6x3mm
6 0170388Z01 Bracket, Flip
7 0571206A01 Grommet, Camera
8 7289713Y01 CLI display
9 3771324A04 Gasket, CLI display
10 3271233A17 Gasket, Camera
11 9471280A01 Camera assembly
12 0102733J82 Flip PCB assembly
13 0171191A01 Flex assembly
14 7288988Y01 Main display assembly
15 0170388D02 Speaker
16 0170388B02 Flip housing assembly, Silver
17 6171204A02 Lens, main display
18 1371145A03 Escutcheon, TIM Silver
19 1571134A02 Front housing assembly, Silver
20
AAHN5648A
AAHN5675A
Battery door, Silver, PF4
Battery door, Silver, PF5
21 SNN5766A Battery
22 0571205A02 RF grommet, Silver
23 0370303A04
Screw, rear housing,
M1.6x4.8mm
24 8571190A04 Antenna
25 0170387P01 Rear housing assembly, Silver
26 7571369A03 Poron pad connector
27 3271163A02 Gasket, Alert
28 5088017N04 Alert speaker
29 3271164A01 Poron pad, Alert
30 3271165A02 Gasket, acoustic
31 4071154A01 Mylar
32 3871135A09 Keypad, English, Silver
33 1370316C05 Escutcheon connector
34 5570373B03 Hinge
-- 5987825N02 Magnet
