Level 1 and 2 Service Manual Disassembly
5. Slide the battery away from antenna and lift away from phone. See Figure 2.
6. To replace, Align the battery with the battery compartment so the contacts on
the battery match the battery contacts in the phone.
7. Insert the top end of the battery near the antenna, into the battery
compartment.
8. Insert the bottom end of the battery housing into the base of the phone.
9. Slide the battery cover onto the phone and snap it into place.
050474o
Figure 2. Removing the battery
E
There is a danger of explosion if the Lithium Ion battery is replaced incorrectly.
Replace only with the same type of battery or equivalent as recommended by the
battery manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
Battery
