6809509A89-O March 01, 2007 5
Level 1 and 2 Service Manual
Specifications
General Function Specification
Frequency Range GSM 850 824-848 MHz Tx
869-893 MHz Rx
Frequency Range GSM 900 880-915 MHz Tx (with EGSM)
925-960 MHz Rx
Frequency Range DCS 1800 1710-1785 MHz Tx
1805-1880 MHz Rx
Frequency Range PCS 1900 1850-1910 MHz Tx
1930-1990 MHz Rx
Channel Spacing 200 KHz
Channels 174 EGSM, 374 DCS, 299 PCS, 124 GSM 850 carriers with 8 channels per carrier
Modulation GMSK at BT=0.3
Transmitter Phase Accuracy 5 Degrees RMS, 20 Degrees peak
Duplex Spacing 45MHz (GSM 850, GSM 900), 95MHz (DCS 1800), 80MHz (PCS 1900)
Frequency Stability +/-0.10 ppm of the downlink frequency (Rx)
Operating Voltage +3.35Vdc to +4.35Vdc (Battery)
+5.00Vdc max (external connector)
Transmit Current Drain 80-290 mA average talk current drain
Standby Current Drain ~3 mA (DRX2), 2 mA (DRX9) typical
Temperature Range -10 degC to +55 degC (+15 deg F to +130 deg F)
Dimensions, with 880 mAh Li-Ion battery 45mm x 99mm x 17.5mm
(1.77 inches x 3.90 inches x 0.69 inches)
Size (Volume) 70 cc (4.27 in
3)
Weight 106 grams (3.74 oz) with battery
Battery Life, with standard 880 mAh Li-
Ion Battery
GSM
Voice Call - 215 mins to 450 mins
Standby DRX5 = ~500 hrs
All talk and standby times are approximate and depend on network configuration,
signal strength, and features selected. Standby times are quoted at DRX=5.
Talk times are quoted with DTX ON.
Battery Charge Time 4 hours to 90% of 880 mAh capacity
Alert Volume Max 95dB @ 5cm, 0.5 Watts input
Transmitter Functions Specification
RF Power Output 31.8dBm nominal (GSM 850)
32.0dBm nominal (GSM 900)
29.0dBm nominal (DCS 1800/PCS 1900)
Output Impedance 50 ohms nominal
Spurious Emissions -36dBm from 0.1 to 1 GHz, -30dBm from 1 to 4 GHz
Receiver Functions Specification
Receive Sensitivity Better than -103dBm
Rx Bit Error Rate (100k bits) Type II < 2%
