Motorola XTS 2500

XTS 2500/XTS 1500/MT 1500 Exploded View and Parts List
34
XTS 2500 Model II Exploded View
18
5
13
39
16
4
17
9
8
7
2
6
14
3
11
10
12
19
28
22
21
20
36
1
29
15
27 25
24
MAEPF-27250-O
33
34
23
26
35
37
38
32
30
31
Table 14. Model II Exploded View Parts List
Item
Number
Motorola Part
Number
Description
Item
Number
Motorola Part
Number
Description
1 1585746D02 Cover, Front Assembly Kit 30 Typical Antenna
2 0185947D01 Board, Model II 31 1505579Z01 Dust Cover, Universal Conn.
3 8485939D01 Assembly, Speaker/Microphone/
Universal Connector Flex
32 8485268D01 Board, Jumper Flex
4 1385149D01 Bezel, PTT 33 7585737D01 Spacer Pad
5 7585959C01 Keypad, PTT/Side Controls 34 2685785C01 Main Shield
6 7285726C01 Display Module 35 Typical Main Board
7 7585776C02 Keypad, Limited 36 4385665D01 Adaptor, Remote Speaker Mic.
8 7585915C01 Pad, Shock LCD 37 Typical Battery
9 4285214D01 Retainer, Keypad 38 Typical Belt Clip
10 4285446D01 Retainer, Speaker 39 0485667D01 Washer, Teflon
11 4285632D01 Retainer, Microphone Boot
12 4385717D01 Spacer, Plastic 13 3585469D01 Microphone Felt 14 1485218D01 Boot, Microphone 15 1385855C01 Label, ABC 16 3385466D01 Nameplate, Front 17 3385511D01 Label, Bottom 18 3585339D01 Speaker Mesh 19 0385563D01 Screw 20 1585405D01 Shroud 21 2785787C01 Chassis Cover, Rear 22 3285270D01 Seal, Main O-ring 23 4285633D01 Retaining Clip 24 3680529Z01 Knob, Volume 25 3685779C01 Knob, Frequency (W/D-Clip) 26 6003710K08 Battery, Backup 27 4585782C01 Lever, Concentric Switch 28 7585382D01 Pad, Thermal 29 3280534Z01 Seal, Contact
