Disassembly/Assembly
38
Battery
Attach
the Battery 1. With the radio off, fit the three extensions at the bottom of the battery into the bottom
slots on the radio.
2. Press the top of the battery against the radio until both latches click into place.
Remove the Battery 1. With the radio off, slide down the latches on the sides of the battery.
2. Pull the top of the battery away from the radio.
Figure 17. Step 1, Attaching the Battery
Figure 18. Step 2, Attaching the Battery
Figure 19. Step 1, Removing the Battery
Figure 20. Step 2, Removing the Battery
