Power off Auto shut off saves battery life or
manual off by push button.
Operating
0 to 50 ℃.
Temperature
Operating Less than 85% R.H.
Humidity
Power Supply
Alkaline or heavy duty DC 1.5 V batter
( UM3, AA ) x 6 PCs, or equivalent.
DC 9V adapter input. ( AC/DC powe
adapter is optional ).
Power Current Normal operation ( w/o SD card save
data and LCD Backlight is OFF) :
Approx. DC 12 mA.
When SD card save the data but and
LCD Backlight is OFF) :
Approx. DC 51 mA.
If LCD backlight on, the powe
consumption will increase approx.
30 mA.
Weight 489 g/1.08 LB.
Dimension 245 x 68 x 45 mm.
( 9.6 x 2.7x 1.9 inch ).
Accessories
Instruction manual........................................ 1 PC
Included
Hard carrying case, CA-06........................... 1 PC
Optional
Sound calibrator ( 94 dB ), SC-941.
Accessories
Sound calibrator ( 94/114 dB ), SC-942.
Sound wind shield ball, SB-01
Data Acquisition software,
SW-U801-WIN.
Soft carrying case, CA-05A.
5
