PARTS BREAKDOWN
Description Quantity Part #
WARNING
!
Only use Powder Cable topcase US with 110V
vibrator motor.
615300-00 MS Topcase Control Unit S4 1
835069 MS Topcoat M4 manual gun 1
835015 Trolley Topcoater Single 1
835019 Trolley, Topcoater, Dual (Not Shown) 1
Four Power Cables are available (Included with Topcase):
460147 Power Cable topcase EU (Included in 615300-01) 1
460148 Power Cord CH (Included in 615300-04) 1
460150 Power Cable topcase CN (Included in 615300-03) 1
461881 Power Cord UK (Included in 615300-05) 1
PA-18-02-R0 (08/2018) 11 / 52 www.carlisleft.com
