MS Topcoater - Specifications

Dimension
Weight: 4.4 kg
Depth: 280 mm
Width: 200 mm
Height: 120 mm
Electrical data
Main: 100 - 240 VAC
Frequency: 50 - 60 Hz
Input power: 70 W (With vibrator 550W)
External voltage to gun: max.10Veff
External current to gun: max.1.4A
External frequency to gun: 40 kHz.
Output to vibrator: 100-240VAC/max.70W
Fuse: 2.5A
Permission
Protection class: IP 64
Interference suppression: FN
Temperature range: 0 °C … +40 °C (32 °F ... +104 °F)
PTB 16ATEX5004: EN50050-2:2013
Pneumatic data
Input air pressure: 6 bar
Compressed air quality according ISO 8573.1
Residual water content in compressed air: max.1.3g/m3withadewpointof7°C
Residual oil in the compressed air: max.0.1mg/m3
Air throughput: max.5-20m3/h
Regulated output air pressure: 0 – 5bar
SPECIFICATIONS
