SUCTION PIPE COMPONENTS - PARTS LIST
Part #Description Quantity Wear Part
SUCTION PIPE WITHOUT ELITE INJECTOR
1 O-Ring 1 417220
2 Inner Injector Pipe with O-Ring (1) 1 615127
3 O-Ring 1 417188
4 Outer Tube with O-Ring (3) 1 615128
5 Suction Intake with O-Ring (6) 1 615126
6 O-Ring 2 417186
7 Coupling Fitting 1 W 426633
WARNING
!
The wear parts marked in the spare parts list
with (W) must be checked regularly and replaced
if necessary.
