MS Topcoater - Building and Installation Topcoater

BUILDING AND INSTALLATION TOPCOATER
1 Manual Gun
2 Injector
3 Control Module
4 Suction System
5 Holder Topcoat M4
6 Solid Tire
Item # Description
TOPCOATER - PARTS LIST
Item # Description
7 Rubber Bummper
8 Hose Bracket
10 Vibrator Motor
12 ExtensionHolder
14 Cleaning Unit
2
7
5
8
6
14
4
1
3
12
