MS Topcoater - Specifications

SPECIFICATIONS
Dimension:
Weight: 388 g (Without leads)
Length: 350 mm (Flat spray nozzle)
Electrical Data:
Frequency: 40 kHz
 Outputvoltage: 90kVDCMaximum
Output current: Regulated by 0 – 100 µA
Polarity: Negative
Building class: acc. EN 50050
Pneumatic Data:
Input air pressure (Sprayed air): 6 bar
Powder output quantity: Variable to 450 g/min
Compressed Air Quality According ISO 8573.1:
 Residualwatercontentincompressedair: max.1.3g/m3withadewpointof7°C
 Residualoilinthecompressedair: max.0.01mg/m3
 Airthroughput: max.5-20m3/h
Ambient Condition: When using low temperature powders may be necessary
an ambient temperature of below 30 ° C.
Workable Powder: Plastic powder Metallic-powder
Permission: PTB16 ATEX 5003
Protection class: IP 64
Ignition protection: Type A acc. EN 50177
Temperature range: 0 °C … +85 °C (32 °F ... +185 °F)
