FUNCTION
Upon actuation of the trigger (1) (controller is turned on),
the (2) is activated in the spray gun. Simultaneously, the
powder (3) - as well as the air supply (4) is switched to the
spray gun. The powder moves along the gun and comes
into contact with the high voltage.
The high voltage differential between the grounded work
piece and the electrode of the coating gun generates an
electric eld, which transmits a negative charge on the
individual powder particles.
Since these particles have the same charge as the spray
gun,theyarerepelled,distributedinanecloudandde-
posited evenly on the grounded work piece. Powder that
does not initially make contact with the work piece is caught
intheelectricaleldandwrapsaroundtothebacksideof
the work piece. This powder coating technology provides
more effective material utilization, time savings, greatly
improved coating quality, minimal cleaning effort and a
healthy working environment.
3
4
1
2
PA-18-02-R0 (08/2018) 43 / 52 www.carlisleft.com
EN
INSTALLATION
