Installation
FS-B35XX Series Start-up Guide 10
3.3.1 Ethernet Port Behavior (N1 & N2)
The N1 and N2 Ethernet ports share an Ethernet stack. Therefore, the IP addresses of N1 and N2 must be
on separate subnets and must be connected to separate networks.
There is only 1 Gateway IP Address in the FS-B35XX. This means that when using both N1 and N2 Ethernet
ports simultaneously, only 1 Ethernet port can connect to a larger network through the Gateway IP Address
while the other is limited to a local network.
In the configuration file of the FS-B35XX, the choice of N1 or N2 is irrelevant. As a server, the FS-B35XX
will accept messages from either N1 or N2 port. As a client, the FS-B35XX will choose the correct port to
transmit a message based on the IP address of the remote device.
