Equipment Setup
FS-B35XX Series Start-up Guide 6
2 Equipment Setup
2.1 Supplied Equipment
FS-B35XX Series FieldServer
• Preloaded with Modbus RTU driver, SMT Ethernet driver and any other drivers ordered. A sample
configuration file is also pre-loaded onto the FieldServer.
• All instruction manuals, driver manuals, configuration manuals and support utilities are available on
the USB drive provided in the optional accessory kit, or on the MSA Safety website.
USB Flash Drive loaded with:
o FS-B35XX Series Start-up Guide
o FieldServer Configuration Manual
o All FieldServer Driver Manuals
o Support Utilities
o Any additional folders related to special files configured
for a specific FieldServer
o Additional components as required - see Driver Manual Supplement for details
Accessories:
o DB9F/RJ45 Connection Adapter (Part # FS-8917-02)
o Adapter for hyperterminal connection to the Sys Port (Part # FS8917-26)
o Power Supply (Part # 69196)
o Detachable Power Cord (Part # 53029)
o 7 pin mini connector (RS-485) (Part # 59232)
o 5 pin mini connector (Power) (Part # 59231)
o 2 pin mini connector – High Temp (LonWorks
®
connection) (Part # 59230)
o Self-Adhesive feet (Part # 69178)
o Small accessory kit containing four unpinned DB9 connectors (Part # 8915-11)
