MSA PrimaX P User Manual

DescriptionMSA
PrimaX
GB
11
The enclosures vary depending on the particular version. The electrical parts and
interfaces have the same basic functionality.
The device has:
- a quick and easy pluggable sensor,
- a four digit liquid crystal display [LCD],
- a key pad with a cover
- a detachable backplate for installation on a wall or on a pipe
The device operate with a 4 – 20 mA output signal and an IP 67 ingress protection.
Fig. 2 Exploded View [PrimaX P]
1 Terminal for power connection 6 Sensor
2 Keypad with cover 7 red LED [PrimaX P only]
3 Connector for factory use 8 yellow LED [PrimaX P only]
4 Display 9 green LED [PrimaX P only]
5 bayonet joint with interlock 10 Identification plate
1
2
3
7
8
9
4
6
5
10

MSA PrimaX P Specifications

General

Brand	MSA
Model	PrimaX P
Category	Measuring Instruments
Language	English
