PrimaX
GB
19
4.1 Startup
During startup a self-test is performed and the output signal is set to the service cur-
rent [default 3.0 mA]. The following information is displayed:
Display Test
The display shows all segments.
Note: The PrimaX P also shows all LEDs and afterwards the yellow LED is flash-
ing during the startup procedure.
Software Version
The display shows the firmware version.
Sensor
The display shows the configured type of sensor operating with each individual de-
tector, e.g.: COMB [combustible], CO, H
2
S.
Range
The display shows the measuring range predefined for the gas detector, e.g.:
100% LEL.
Countdown
The countdown for sensor stability is displayed.
Normal Operation
After countdown, the gas concentration [ppm, Vol%, % LEL, % UEG, mg/m
3
] is
displayed. The heart symbol flashes to indicate alive status.
