6 Technical Data
6.1 Specifications
Relay nominal switching capacity [resistive load]:
Measuring Methods
PrimaX P PrimaX I
Enclosure
aluminium enclosure
flameproof
IP 67 ingress protection
plastic enclosure
intrinsically safe
IP 66 ingress protection
Dimensions in mm
[Height X Width X Depth]
220 X 162 X 100 220 X 162 X 81
Weight 1.6 kg 1.2 kg
Humidity 15 % to 90 % rel. humidity 15 % to 90 % rel. humidity
Power supply 19.2 V - 28.0 V 19.2 V - 28.0 V
Power consumption 3W 0.7W
Temperature range
[instrument]
Temperature range
[sensor]
-40 to +70 °C
see sensor
-40 to +70 °C
see sensor
Signal output
HART [option]
Relay [option]
4 – 20 mA
yes
yes
4 – 20 mA
yes
no
Signal output tolerance 1 % 1 %
Pressure 80 – 120 kPa 80 – 120 kPa
Max. load resistance 300 Ohm 300 Ohm
Air velocity 0 – 6 m/s 0 – 6 m/s
Alarm Relay 2A / 30V DC
Failure Relay 2A / 30V DC
Oxygen Electrochemical sensor
Toxic gases Electrochemical sensor
Combustible gases Thermo-catalytic sensor
