MSA PrimaX P - Page 36

MSA
Maintenance
PrimaX
36
GB
Remove Interlock
(1) Unscrew the socket head screw.
(2) Remove the interlock.
Remove Bayonet Joint
(3) Turn the bayonet ring counter-clock-
wise.
(4) Remove the bayonet ring by pulling it
down.
Replace Sensor
(5) Unplug the sensor carefully.
(6) Plug in the new sensor carefully.
(7) Replace the bayonet ring.
(8) Replace the interlock.
