Accessories
PrimaX
64
GB
8.5 Duct Mounting Kit
Fig. 17 Duct mounting kit
Gas monitoring in air ducts can be performed by means of this duct mounting kit.
When installing, the direction of flow inside the duct must be towards the baffles.
The sensor can be calibrated via the gas calibration port, provided the duct is free
of all gases to which the sensor will respond. If the duct cannot be gas free, the sen-
sor must be removed from the duct during calibration.
The calibration port must be sealed again with the locking cap after calibration has
been carried out.
Calibration should only be carried out with the calibration port if the air velocity is
< 5 m/s in the air duct.
Using the flow through adapter will extend the response time, depend-
ing on the gas flow rate.
The performance of the duct mounting kit depends on various parame-
ters and has to be checked before usage. The kit was not part of the
compliance test.
